Volvo C70
Date of manufacture
3/2006 – 12/2009 (Convertible)
Platform
Volvo P1
Manufacturing locations
Uddevalla, Sweden
Designer
Steve Mattin
Fedde Talsma
John Kinsey
Tags
Convertible
Swedish cars
Volvo C70, manufactured in Sweden, was first produced in 2006. It offers a Kabriolet version based on the Volvo P1 platform and can boast various engine options, currently the strongest T5 with a power of 169 kW; this model reaches the highest speeds of 240 km/h. The most efficient engine option is the 2.0 D with combined fuel consumption of 6 l/100 km and emissions of CO2 161 g/km. The passenger space totals 200 - 404 l.
Technical data
Convertible
| 2.4 | 2.4 | 2.4 | 2.4 | T5 | T5 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 5/20 | 5/20 | 5/20 | 5/20 | 5/20 | 5/20 |
| Engine displacement [cm³] | 2435 | 2435 | 2435 | 2435 | 2521 | 2521 |
| Maximum output / speed [kW/min-1] | 103/5000 | 103/5000 | 125/6000 | 125/6000 | 169/5000 | 169/5000 |
| Maximum torque [Nm/min-1] | 220/4000 | 220/4000 | 230/4400 | 230/4400 | 320/1500-5000 | 320/1500-5000 |
| Bore and stroke [mm x mm] | 83,0 x 90,0 | 83,0 x 90,0 | 83,0 x 90,0 | 83,0 x 90,0 | 83,0 x 93,2 | 83,0 x 93,2 |
| Compression ratio | 10.3:1 | 10.3:1 | 10.3:1 | 10.3:1 | 9.0:1 | 9.0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear automatic | 5 gear manual | 5 gear automatic | 6 gear manual | 5 gear automatic |
| Drive specifications | - |
| - |
| - |
|
| Top speed [km/h] | 205 | 200 | 220 | 215 | 240 | 235 |
| Acceleration 0–100 km/h [s] | 11,0 | 11,8 | 9,1 | 10,0 | 7,6 | 8,0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 12,8 | 13,8 | 12.9 | 13,6 | 13,1 | 14,7 |
| Out of town [l] | 6,7 | 7,0 | 6,7 | 7,0 | 6,2 | 7,0 |
| Combined [l] | 8,9 | 9,6 | 9,0 | 9,6 | 9,1 | 9,8 |
| CO2 emissions [g/km] | 212 | 229 | 215 | 229 | 217 | 234 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1685 | 1685 | 1683 | 1683 | 1711 | 1711 |
| Overall weight [kg] | 2070 | 2070 | 2070 | 2070 | 2090 | 2090 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | 750/1500 | 750/1500 | 750/1500 | 750/1500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 200-404 | 200-404 | 200-404 | 200-404 | 200-404 | 200-404 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 680 | 680 | 680 | 680 | 680 | 680 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 62 | 62 | 62 | 62 | 62 | 62 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 215/55 R16 | 215/55 R16 | 215/55 R16 | 215/55 R16 | 235/50 R17 | 235/50 R17 |
| Tyre dimensions rear | 215/55 R16 | 215/55 R16 | 215/55 R16 | 215/55 R16 | 235/50 R17 | 235/50 R17 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 300 or 320 | 300 or 320 | 300 or 320 | 300 or 320 | 300 or 320 | 300 or 320 |
| Brake dimensions rear | 280 | 280 | 280 | 280 | 280 | 280 |
| Steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering |
| Number of steering wheel turns | 2.58 | 2.58 | 2.58 | 2.58 | 2.58 | 2.58 |
| Turning diameter track/circumference [m] | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 |
| Overall length [mm] | 4582 | 4582 | 4582 | 4582 | 4582 | 4582 |
| Overall width without/including mirrors [mm] | 1836/2025 | 1836/2025 | 1836/2025 | 1836/2025 | 1836/2025 | 1836/2025 |
| Overall height [mm] | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 |
| Wheelbase [mm] | 2640 | 2640 | 2640 | 2640 | 2640 | 2640 |
| Front wheel track [mm] | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 |
| Rear wheel track [mm] | 1560 | 1560 | 1560 | 1560 | 1560 | 1560 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 970 | 970 | 970 | 970 | 970 | 970 |
| Headroom rear [mm] | 924 | 924 | 924 | 924 | 924 | 924 |
| Front elbow/shoulder width [mm] | 1361/- | 1361/- | 1361/- | 1361/- | 1361/- | 1361/- |
| Rear elbow/shoulder width [mm] | 1194/- | 1194/- | 1194/- | 1194/- | 1194/- | 1194/- |
| Legroom front knees/total [mm] | -/1074 | -/1074 | -/1074 | -/1074 | -/1074 | -/1074 |
| Legroom rear knees/total [mm] | -/862 | -/862 | -/862 | -/862 | -/862 | -/862 |
| 2.0 D | 2.0 D | D5 | D5 | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 4/16 | 5/20 | 5/20 | ||
| Engine displacement [cm³] | 1997 | 1997 | 2400 | 2400 | ||
| Maximum output / speed [kW/min-1] | 100/4000 | 100/4000 | 132/4000 | 132/4000 | ||
| Maximum torque [Nm/min-1] | 320/2000 | 320/2000 | 400/1750-3250 | 400/1750-3250 | ||
| Bore and stroke [mm x mm] | 85,0 x 88,0 | 85,0 x 88,0 | 81,0 x 93,15 | 81,0 x 93,15 | ||
| Compression ratio | 18.3:1 | 18.3:1 | 17.3:1 | 17.3:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 5 gear automatic | ||
| Drive specifications | - |
| - |
| ||
| Top speed [km/h] | 205 | 205 | 225 | 220 | ||
| Acceleration 0–100 km/h [s] | 11,0 | 11,1 | 9,0 | 9,5 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 8,1 | 8,2 | 8,7 | 10,1 | ||
| Out of town [l] | 4,9 | 5,3 | 5,4 | 5,7 | ||
| Combined [l] | 6,0 | 6,3 | 6,6 | 7,3 | ||
| CO2 emissions [g/km] | 161 | 167 | 174 | 193 | ||
| Emission standard | EU4 | EU4 | EU4 | EU4 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1702 | 1702 | 1747 | 1747 | ||
| Overall weight [kg] | 2090 | 2090 | 2130 | 2130 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | 750/1500 | 750/1500 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | - | - | - | - | ||
| Boot volume [l] | 200-404 | 200-404 | 200-404 | 200-404 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | 680 | 680 | 680 | 680 | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 2 | 2 | 2 | 2 | ||
| Number of seats | 4 | 4 | 4 | 4 | ||
| Fuel tank volume [l] | 52 | 52 | 60 | 60 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 215/55 R16 | 215/55 R16 | 215/55 R16 | 215/55 R16 | ||
| Tyre dimensions rear | 215/55 R16 | 215/55 R16 | 215/55 R16 | 215/55 R16 | ||
| Wheel size front | - | - | - | - | ||
| Wheel size rear | - | - | - | - | ||
| Brake dimensions front | 300 or 320 | 300 or 320 | 300 or 320 | 300 or 320 | ||
| Brake dimensions rear | 280 | 280 | 280 | 280 | ||
| Steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering | Electro-hydraulic power steering | ||
| Number of steering wheel turns | 2.58 | 2.58 | 2.58 | 2.58 | ||
| Turning diameter track/circumference [m] | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 | 11.8/11.95 | ||
| Overall length [mm] | 4582 | 4582 | 4582 | 4582 | ||
| Overall width without/including mirrors [mm] | 1836/2025 | 1836/2025 | 1836/2025 | 1836/2025 | ||
| Overall height [mm] | 1400 | 1400 | 1400 | 1400 | ||
| Wheelbase [mm] | 2640 | 2640 | 2640 | 2640 | ||
| Front wheel track [mm] | 1550 | 1550 | 1550 | 1550 | ||
| Rear wheel track [mm] | 1560 | 1560 | 1560 | 1560 | ||
| Forward overhang [mm] | - | - | - | - | ||
| Rear overhang [mm] | - | - | - | - | ||
| Clearance [mm] | 140 | 140 | 140 | 140 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 970 | 970 | 970 | 970 | ||
| Headroom rear [mm] | 924 | 924 | 924 | 924 | ||
| Front elbow/shoulder width [mm] | 1361/- | 1361/- | 1361/- | 1361/- | ||
| Rear elbow/shoulder width [mm] | 1194/- | 1194/- | 1194/- | 1194/- | ||
| Legroom front knees/total [mm] | -/1074 | -/1074 | -/1074 | -/1074 | ||
| Legroom rear knees/total [mm] | -/862 | -/862 | -/862 | -/862 |
Gallery
