Volkswagen Taigo

Date of manufacture

2020 – to this day (Small SUV)

Platform

Volkswagen Group MQB A0

Manufacturing locations

Pamplona, Spain

São Bernardo do Campo, Brazil

Designer

José Carlos Pavone

Car body style

Small SUV

Date of manufacture

2020 – to this day

Internal designation

Engine size

1.0 TSI

1.5 TSI

Euro NCAP

Technical data

Small SUV

	1.0 TSI	1.0 TSI	1.0 TSI	1.5 TSI
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	4/16
Engine displacement [cm³]	999	999	999	1498
Maximum output / speed [kW/min-1]	70/5000-5500	81/5500	81/5500	110/5000-6000
Maximum torque [Nm/min-1]	175/1600-3500	200/2000-3000	200/2000-3000	250/1500-3500
Bore and stroke [mm x mm]	74,5 x 76,4	74,5 x 76,4	74,5 x 76,4	74,5 x 85,9
Compression ratio	11.5:1	11.5:1	11.5:1	10,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection operation of engine in the Miller cycle turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection operation of engine in the Miller cycle turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection operation of engine in the Miller cycle turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	7 gear automatic	7 gear automatic
Drive specifications	-	-	dual-clutch automatic gearbox DSG	dual-clutch automatic gearbox DSG

Top speed [km/h]	183	191	191	212
Acceleration 0–100 km/h [s]	11.1	10.4	10.9	8.3
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	6.0	5.9	6.0	6.4
Out of town [l]	4.0	4.1	4.2	4.3
Combined [l]	4.7	4.8	4.9	5.1
CO2 emissions [g/km]	108	109	111	116

Low speed [l]	6.6	6.9	7.5	8.2
Medium speed [l]	5.1	5.2	5.7	5.9
High speed [l]	4.7	4.6	5.1	5.2
Extra high speed [l]	5.8	5.7	6.0	6.1
Combined speed [l]	5.4	5.4	5.8	6.1
CO2 emissions [g/km]	123	123	133	138

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1220	1242	1260	1304
Overall weight [kg]	1680	1700	1720	1750
Maximum trailer weight unbraked/braked [kg]	610/1000	620/1100	620/1100	650/1200
Maximum front/rear axle load [kg]	870/860	900/850	920/850	940/860
Maximum vertical load on the tow bar [kg]	55	55	55	55
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-

Boot volume [l]	440	440	440	440
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1222	-/1222	-/1222	-/1222
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	1002/-	1002/-	1002/-	1002/-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	2084	2084	2084	2084
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	40	40	40	40
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	multilink, stabiliser bar
Tyre dimensions front	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Tyre dimensions rear	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Wheel size front	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Wheel size rear	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.9/-	10.9/-	10.9/-	10.9/-

Overall length [mm]	4266	4266	4266	4266
Overall width without/including mirrors [mm]	1757/1995	1757/1995	1757/1995	1757/1995
Overall height [mm]	1515	1515	1515	1515
Wheelbase [mm]	2554	2554	2554	2554
Front wheel track [mm]	1523	1523	1523	1523
Rear wheel track [mm]	1508	1508	1508	1508
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	16.6	16.6	16.6	16.6
Approach angle rear [°]	16.6	16.6	16.6	16.6
Transition angle [°]	14.5	14.5	14.5	14.5
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	1019	1019	1019	1019
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Volkswagen VW Taigo 2022 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
