Volkswagen Sharan
Date of manufacture
2010 – 2015 (Large MPV)
Platform
Volkswagen Group A6 PQ46
Manufacturing locations
Palmela, Portugal
Designer
-
Tags
Large MPV
German cars
The Volkswagen Sharan is a large MPV that was first manufactured in Portugal in 2010. It is built on the Volkswagen Group A6 PQ46 platform and offers a wide range of petrol and diesel engines. The most powerful model is the 2.0 TSI with 147 kW (218 km/h top speed) and the most fuel-efficient engine is the 2.0 TDI BMT (5.5 l/100 km fuel consumption and 143 g/km emissions). The car's boot has a capacity of 885 litres. In 2010, the Volkswagen Sharan achieved a EURONCAP safety rating of 5 out of 5 in tests.
Car body style
Large MPV
Date of manufacture
2010 – 2015Internal designation
7N
Technical data
Large MPV
| 1.4 TSI BMT | 1.4 TSI BMT | 2.0 TSI | 2.0 TDI BMT | 2.0 TDI BMT | 2.0 TDI BMT | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | from 2011 to | from 2011 to | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1390 | 1390 | 1984 | 1968 | 1968 | 1968 |
| Maximum output / speed [kW/min-1] | 110/5800 | 110/5800 | 147/5100 | 85/4200 | 103/4200 | 103/4200 |
| Maximum torque [Nm/min-1] | 240/1750-4000 | 240/1750-4000 | 280/1700-5000 | 280/1750-2750 | 320/1750-2500 | 320/1750-2500 |
| Bore and stroke [mm x mm] | 76,5 x 75,6 | 76,5 x 75,6 | 82,5 x 92,8 | 81,0 x 95,5 | 81,0 x 95,5 | 81,0 x 95,5 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,3:1 | 16,0:1 | 16,0:1 | 16,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic |
| Drive specifications | - |
|
| - | - |
|
| Top speed [km/h] | 197 | 197 | 218 | 183 | 194 | 191 |
| Acceleration 0–100 km/h [s] | 10,7 | 9,9 | 8,3 | 12.6 | 10,9 | 10,9 |
| Acceleration 0–80 km/h [s] | 6,9 | 6,6 | 5,8 | 8.4 | 7.7 | 7.7 |
| Acceleration 80–120 km/h [s] | 10.0 (13.5 (4th/5th gear) | - | - | 11.0 (14.0 (4th/5th gear) | 9.5 (12.0 (4th/5th gear) | - |
| City [l] | 9,2 | 9.4 | 11.5 | 6.8 | 6,8 | 6,9 |
| Out of town [l] | 6,1 | 6.6 | 6.6 | 4.8 | 4,8 | 5,0 |
| Combined [l] | 7,2 | 7,6 | 8,4 | 5.5 | 5,5 | 5,7 |
| CO2 emissions [g/km] | 167 | 178 | 196 | 143 | 143 | 149 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1723 | 1742 | 1790 | 1772 | 1774-1822 | 1803-1851 |
| Overall weight [kg] | 2290-2480 | 2310 | 2360 | 2360 | 2340-2510 | 2370-2470 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/1800 | 750/2000 | 750/2000 | 750/2200 | 750/2200 |
| Maximum front/rear axle load [kg] | 1220/1120-1220 | 1240/1120 | 1260/1150 | 1260/1150 | 1210-1250/1150-1310 | 1240-1280/1150-1310 |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 885 | 885 | 885 | 885 | 885 | 885 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2430 [- | -/2430 [- | -/2430 [- | -/2430 [- | -/2430 [- | -/2430 [- |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1329 | 1329 | 1329 | 1329 | 1329 | 1329 |
| Boot length with rear seats folded [mm] | 2088 | 2088 | 2088 | 2088 | 2088 | 2088 |
| Boot width between wheels/max [mm] | 1088/- | 1088/- | 1088/- | 1088/- | 1088/- | 1088/- |
| Boot height to headliner/ceiling [mm] | 659/1099 | 659/1099 | 659/1099 | 659/1099 | 659/1099 | 659/1099 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | four-link |
| Tyre dimensions front | 205/60 R16 | 205/60 R16 | 215/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 |
| Tyre dimensions rear | 205/60 R16 | 205/60 R16 | 215/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 |
| Wheel size front | 6.5J x 16 | 7.0J x 17 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 |
| Wheel size rear | 6.5J x 16 | 7.0J x 17 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- |
| Overall length [mm] | 4854 | 4854 | 4854 | 4854 | 4854 | 4854 |
| Overall width without/including mirrors [mm] | 1904/2081 | 1904/2081 | 1904/2081 | 1904/2081 | 1904/2081 | 1904/2081 |
| Overall height [mm] | 1720 | 1720 | 1720 | 1720 | 1720 | 1720 |
| Wheelbase [mm] | 2919 | 2919 | 2919 | 2919 | 2919 | 2919 |
| Front wheel track [mm] | 1569 | 1569 | 1569 | 1569 | 1569 | 1569 |
| Rear wheel track [mm] | 1617 | 1617 | 1617 | 1617 | 1617 | 1617 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 163 | 163 | 163 | 163 | 163 | 163 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 13.7 | 13.7 | 13.7 | 13.7 | 13.7 | 13.7 |
| Approach angle rear [°] | 14.0 | 14.0 | 14.0 | 14.0 | 14.0 | 14.0 |
| Transition angle [°] | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1021 | 1021 | 1021 | 1021 | 1021 | 1021 |
| Headroom rear [mm] | 973 | 973 | 973 | 973 | 973 | 973 |
| Front elbow/shoulder width [mm] | 1507/- | 1507/- | 1507/- | 1507/- | 1507/- | 1507/- |
| Rear elbow/shoulder width [mm] | 1578/- | 1578/- | 1578/- | 1578/- | 1578/- | 1578/- |
| Legroom front knees/total [mm] | -/989 | -/989 | -/989 | -/989 | -/989 | -/989 |
| Legroom rear knees/total [mm] | -/947 | -/947 | -/947 | -/947 | -/947 | -/947 |
| Third row of seats, headroom [mm] | 945 | 945 | 945 | 945 | 945 | 945 |
| Third row elbow/shoulder width [mm] | 1254/- | 1254/- | 1254/- | 1254/- | 1254/- | 1254/- |
| 2.0 TDI BMT 4MOTION | 2.0 TDI BMT | 2.0 TDI BMT | 2.0 TDI BMT | 2.0 TDI BMT | ||
|---|---|---|---|---|---|---|
| Date of sale | from 2012 to | from to 2012 | from to 2012 | from 2012 to | from 2012 to | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | |
| Engine displacement [cm³] | 1968 | 1968 | 1968 | 1968 | 1968 | |
| Maximum output / speed [kW/min-1] | 103/4200 | 125/4200 | 125/4200 | 130/4200 | 130/4200 | |
| Maximum torque [Nm/min-1] | 320/1750-2500 | 350/1750-2500 | 350/1750-2500 | 380/1750-2500 | 380/1750-2500 | |
| Bore and stroke [mm x mm] | 81,0 x 95,5 | 81,0 x 95,5 | 81,0 x 95,5 | 81,0 x 95,5 | 81,0 x 95,5 | |
| Compression ratio | 16,0:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | 4x4 | Front | Front | Front | Front | |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | |
| Drive specifications |
| - |
| - |
| |
| Top speed [km/h] | 191 | 210 | 204 | 208 | 206 | |
| Acceleration 0–100 km/h [s] | 11.4 | 9.5 | 9,5 | 9.3 | 9.6 | |
| Acceleration 0–80 km/h [s] | 7.5 | 6.7 | 6.7 | 6.7 | 6.6 | |
| Acceleration 80–120 km/h [s] | 10.0 (12.5 (4th/5th gear) | - | - | 7.5 (10.0 (4th/5th gear) | - | |
| City [l] | 7.4 | - | 6,7 | 7.3 | 6.7 | |
| Out of town [l] | 5.2 | - | 5,4 | 5.0 | 5.4 | |
| Combined [l] | 6.2-6.0 | 5.8 | 5,9 | 5.8 | 5.9 | |
| CO2 emissions [g/km] | 162-158 | 154 | 154 | 152 | 154 | |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1891-1942 | 1794-1844 | 1803-1851 | 1800 | 1804 | |
| Overall weight [kg] | 2530-2580 | 2360-2530 | 2370-2540 | 2370 | 2370 | |
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | 750/2200 | 750/2200 | 750/2200 | 750/2200 | |
| Maximum front/rear axle load [kg] | 1290-1300/1280-1340 | 1230-1270/1150-1210 | 1240-1280/1150-1310 | 1270/1150 | 1270/1150 | |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | |
| Boot volume [l] | 885 | 885 | 885 | 885 | 885 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2430 [- | -/2430 [- | -/2430 [- | -/2430 [- | -/2430 [- | |
| Boot volume, third row of seats [l] | - | - | - | - | - | |
| Boot volume, third row seats folded [l] | - | - | - | - | - | |
| Boot length [mm] | 1329 | 1329 | 1329 | 1329 | 1329 | |
| Boot length with rear seats folded [mm] | 2088 | 2088 | 2088 | 2088 | 2088 | |
| Boot width between wheels/max [mm] | 1088/- | 1088/- | 1088/- | 1088/- | 1088/- | |
| Boot height to headliner/ceiling [mm] | 659/1099 | 659/1099 | 659/1099 | 659/1099 | 659/1099 | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | - | - | - | - | - | |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | |
| Tyre dimensions front | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | |
| Tyre dimensions rear | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | |
| Wheel size front | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | |
| Wheel size rear | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | 6.5J x 16 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- | |
| Overall length [mm] | 4854 | 4854 | 4854 | 4854 | 4854 | |
| Overall width without/including mirrors [mm] | 1904/2081 | 1904/2081 | 1904/2081 | 1904/2081 | 1904/2081 | |
| Overall height [mm] | 1720 | 1720 | 1720 | 1720 | 1720 | |
| Wheelbase [mm] | 2919 | 2919 | 2919 | 2919 | 2919 | |
| Front wheel track [mm] | 1569 | 1569 | 1569 | 1569 | 1569 | |
| Rear wheel track [mm] | 1617 | 1617 | 1617 | 1617 | 1617 | |
| Forward overhang [mm] | - | - | - | - | - | |
| Rear overhang [mm] | - | - | - | - | - | |
| Clearance [mm] | 163 | 163 | 163 | 163 | 163 | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | 13.7 | 13.7 | 13.7 | 13.7 | 13.7 | |
| Approach angle rear [°] | 14.0 | 14.0 | 14.0 | 14.0 | 14.0 | |
| Transition angle [°] | 9.6 | 9.6 | 9.6 | 9.6 | 9.6 | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 1021 | 1021 | 1021 | 1021 | 1021 | |
| Headroom rear [mm] | 973 | 973 | 973 | 973 | 973 | |
| Front elbow/shoulder width [mm] | 1507/- | 1507/- | 1507/- | 1507/- | 1507/- | |
| Rear elbow/shoulder width [mm] | 1578/- | 1578/- | 1578/- | 1578/- | 1578/- | |
| Legroom front knees/total [mm] | -/989 | -/989 | -/989 | -/989 | -/989 | |
| Legroom rear knees/total [mm] | -/947 | -/947 | -/947 | -/947 | -/947 | |
| Third row of seats, headroom [mm] | 945 | 945 | 945 | 945 | 945 | |
| Third row elbow/shoulder width [mm] | 1254/- | 1254/- | 1254/- | 1254/- | 1254/- |
