Volkswagen Scirocco
Date of manufacture
2014 – 2017 (Coupé)
Platform
Volkswagen Group A5
Manufacturing locations
Palmela, Portugal
Designer
Walter de Silva
Marc Lichte
Tags
S-segment
German cars
The Volkswagen Scirocco is a coupe produced since 2014. The car is built on the Volkswagen Group A5 platform and is exported from Portugal. The engine range includes petrol and diesel units, the most powerful of which, the 2.0 TSI R, produces 206 kW and has a top speed of 250 km/h. The most economical version, the 2.0 TDI, has a combined fuel consumption of 4.2 l/100 km and CO2 emissions of 109 g/km. The Scirocco's luggage compartment has a capacity of 292 l. In terms of safety, this model was tested in 2009 and achieved a total rating of 5 out of 5 according to EURONCAP.
Car body style
Technical data
Coupé
| 1.4 TSI | 2.0 TSI | 2.0 TSI | 2.0 TSI GTS | 2.0 TSI GTS | 2.0 TSI R | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1395 | 1984 | 1984 | 1984 | 1984 | 1984 |
| Maximum output / speed [kW/min-1] | 92/5000-6000 | 132/4200-6200 | 132/4200-6200 | 162/4500-6200 | 162/4500-6200 | 206/6000 |
| Maximum torque [Nm/min-1] | 200/1400-4000 | 280/1250-4400 | 280/1250-4400 | 350/1500-4400 | 350/1500-4400 | 350/2500-5000 |
| Bore and stroke [mm x mm] | 74,5 x 80,0 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 |
| Compression ratio | 10,5:1 | 9,6:1 | 9,6:1 | 9,6:1 | 9,6:1 | 9,3:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 203 | 227 | 225 | 246 | 244 | 250 |
| Acceleration 0–100 km/h [s] | 9.3 | 7.4 | 7.4 | 6.5 | 6.5 | 5.7 |
| Acceleration 0–80 km/h [s] | 6.3 | 5.2 | 5.2 | 5.0 | 5.0 | - |
| Acceleration 80–120 km/h [s] | 9.0 (11.5 (4th/5th gear) | 6.0 (8.0 (4th/5th gear) | - | 5.0 (6.0 (4th/5th gear) | - | - |
| City [l] | 6.8 | 7.5 | 8.1 | 7.5 | 8.1 | 11.1 |
| Out of town [l] | 4.5 | 5.1 | 5.3 | 5.1 | 5.3 | 6.2 |
| Combined [l] | 5.4 | 6.0 | 6.4 | 6.0 | 6.4 | 8.0 |
| CO2 emissions [g/km] | 125 | 139 | 148 | 139 | 148 | 187 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1280 | 1346 | 1387 | 1369 | 1394 | 1426 |
| Overall weight [kg] | 1680 | 1750 | 1770 | 1750 | 1780 | 1770 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 292 | 292 | 292 | 292 | 292 | 292 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1006 | -/1006 | -/1006 | -/1006 | -/1006 | -/1006 |
| Boot length [mm] | 707 | 707 | 707 | 707 | 707 | 707 |
| Boot length with rear seats folded [mm] | 1523 | 1523 | 1523 | 1523 | 1523 | 1523 |
| Boot width between wheels/max [mm] | 1005/1181 | 1005/1181 | 1005/1181 | 1005/1181 | 1005/1181 | 1005/1181 |
| Boot height to headliner/ceiling [mm] | 730/750 | 730/750 | 730/750 | 730/750 | 730/750 | 730/742 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1867 | 1867 | 1867 | 1867 | 1867 | 1859 |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 55 | 55 | 55 | 55 | 55 | 55 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | four-link |
| Tyre dimensions front | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 235/40 R18 |
| Tyre dimensions rear | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 235/40 R18 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 8.0J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- |
| Overall length [mm] | 4256 | 4256 | 4256 | 4256 | 4256 | 4248 |
| Overall width without/including mirrors [mm] | 1810/2080 | 1810/2080 | 1810/2080 | 1810/2080 | 1810/2080 | 1810/2080 |
| Overall height [mm] | 1406 | 1406 | 1406 | 1406 | 1406 | 1398 |
| Wheelbase [mm] | 2578 | 2578 | 2578 | 2578 | 2578 | 2578 |
| Front wheel track [mm] | 1569 | 1569 | 1569 | 1569 | 1569 | 1553 |
| Rear wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1575 | 1561 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 129 | 129 | 129 | 129 | 129 | 121 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 11.6 | 11.6 | 11.6 | 11.6 | 11.6 | 12.4 |
| Approach angle rear [°] | 15.8 | 15.8 | 15.8 | 15.8 | 15.8 | 15.1 |
| Transition angle [°] | 9.4 | 9.4 | 9.4 | 9.4 | 9.4 | 10.5 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 953 | 953 | 953 | 953 | 953 | 953 |
| Headroom rear [mm] | 924 | 924 | 924 | 924 | 924 | 924 |
| Front elbow/shoulder width [mm] | 1443/- | 1443/- | 1443/- | 1443/- | 1443/- | 1443/- |
| Rear elbow/shoulder width [mm] | 1272/- | 1272/- | 1272/- | 1272/- | 1272/- | 1272/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.0 TSI R | 2.0 TDI | 2.0 TDI | 2.0 TDI | 2.0 TDI | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | |
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | |
| Engine displacement [cm³] | 1984 | 1968 | 1968 | 1968 | 1968 | |
| Maximum output / speed [kW/min-1] | 206/6000 | 110/3500-4000 | 110/3500-4000 | 135/3500-4000 | 135/3500-4000 | |
| Maximum torque [Nm/min-1] | 350/2500-5000 | 340/1750-3000 | 340/1750-3000 | 380/1750-3250 | 380/1750-3250 | |
| Bore and stroke [mm x mm] | 82,5 x 92,8 | 81,0 x 95,9 | 81,0 x 95,9 | 81,0 x 95,9 | 81,0 x 95,9 | |
| Compression ratio | 9,3:1 | 16,2:1 | 16,2:1 | 15,8:1 | 15,8:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Front | Front | Front | Front | Front | |
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | |
| Drive specifications |
| - |
| - |
| |
| Top speed [km/h] | 250 | 215 | 213 | 230 | 228 | |
| Acceleration 0–100 km/h [s] | 5.5 | 8.6 | 8.6 | 7.5 | 7.5 | |
| Acceleration 0–80 km/h [s] | - | 6.2 | 6.2 | 5.6 | 5.6 | |
| Acceleration 80–120 km/h [s] | - | 7.0 (9.0 (4th/5th gear) | - | 6.0 (7.5 (4th/5th gear) | - | |
| City [l] | 10.8 | 5.0 | 5.5-5.4 | 5.7-5.4 | 5.7-5.6 | |
| Out of town [l] | 6.2 | 3.8 | 4.1 | 4.2-3.8 | 4.3 | |
| Combined [l] | 7.9 | 4.2 | 4.6-4.5 | 4.7-4.4 | 4.8 | |
| CO2 emissions [g/km] | 185 | 109 | 120-119 | 124-115 | 126-125 | |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1450 | 1375 | 1395 | 1395 | 1418 | |
| Overall weight [kg] | 1800 | 1780 | 1800 | 1800 | 1820 | |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | |
| Boot volume [l] | 292 | 292 | 292 | 292 | 292 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1006 | -/1006 | -/1006 | -/1006 | -/1006 | |
| Boot length [mm] | 707 | 707 | 707 | 707 | 707 | |
| Boot length with rear seats folded [mm] | 1523 | 1523 | 1523 | 1523 | 1523 | |
| Boot width between wheels/max [mm] | 1005/1181 | 1005/1181 | 1005/1181 | 1005/1181 | 1005/1181 | |
| Boot height to headliner/ceiling [mm] | 730/742 | 730/750 | 730/750 | 730/750 | 730/750 | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | 1859 | 1867 | 1867 | 1867 | 1867 | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 3 | 3 | 3 | 3 | 3 | |
| Number of seats | 4 | 4 | 4 | 4 | 4 | |
| Fuel tank volume [l] | 55 | 55 | 55 | 55 | 55 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | - | - | - | - | - | |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | |
| Tyre dimensions front | 235/40 R18 | 225/45 R17 | 225/45 R17 | 225/45 R17 | 225/45 R17 | |
| Tyre dimensions rear | 235/40 R18 | 225/45 R17 | 225/45 R17 | 225/45 R17 | 225/45 R17 | |
| Wheel size front | 8.0J x 18 | 8.0J x 17 | 8.0J x 17 | 8.0J x 17 | 8.0J x 17 | |
| Wheel size rear | 8.0J x 18 | 8.0J x 17 | 8.0J x 17 | 8.0J x 17 | 8.0J x 17 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- | |
| Overall length [mm] | 4248 | 4256 | 4256 | 4256 | 4256 | |
| Overall width without/including mirrors [mm] | 1810/2080 | 1810/2080 | 1810/2080 | 1810/2080 | 1810/2080 | |
| Overall height [mm] | 1398 | 1406 | 1406 | 1406 | 1406 | |
| Wheelbase [mm] | 2578 | 2578 | 2578 | 2578 | 2578 | |
| Front wheel track [mm] | 1553 | 1569 | 1569 | 1569 | 1569 | |
| Rear wheel track [mm] | 1561 | 1575 | 1575 | 1575 | 1575 | |
| Forward overhang [mm] | - | - | - | - | - | |
| Rear overhang [mm] | - | - | - | - | - | |
| Clearance [mm] | 121 | 129 | 129 | 129 | 129 | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | 12.4 | 11.6 | 11.6 | 11.6 | 11.6 | |
| Approach angle rear [°] | 15.1 | 15.8 | 15.8 | 15.8 | 15.8 | |
| Transition angle [°] | 10.5 | 9.4 | 9.4 | 9.4 | 9.4 | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 953 | 953 | 953 | 953 | 953 | |
| Headroom rear [mm] | 924 | 924 | 924 | 924 | 924 | |
| Front elbow/shoulder width [mm] | 1443/- | 1443/- | 1443/- | 1443/- | 1443/- | |
| Rear elbow/shoulder width [mm] | 1272/- | 1272/- | 1272/- | 1272/- | 1272/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
