Toyota Yaris Cross

Date of manufacture

8/2020 – to this day (Small SUV)

Platform

TNGA: GA-B

Manufacturing locations

Kanegasaki, Japan

Valenciennes, France

Designer

Hideaki Iida

Jun Takahashi

Maki Kobayashi

Yoshikazu Shoji

Car body style

Small SUV

Date of manufacture

8/2020 – to this day

Internal designation

XP210

Engine size

Petrol

1.5 Dynamic Force

Petrol + Electric

1.5 Hybrid

Euro NCAP

Technical data

Small SUV

	1.5 Dynamic Force	1.5 Dynamic Force	1.5 Hybrid	1.5 Hybrid
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol + Electric	Petrol + Electric
Number of cylinders/valves	3/12	3/12	3/12	3/12
Engine displacement [cm³]	1490	1490	1490	1490
Maximum output / speed [kW/min-1]	92/6600	92/6600	68/5500 combustion 59 el. 85 total	68/5500 combustion 59 el. 3.9 el. in the rear 85 total
Maximum torque [Nm/min-1]	153/4800-5000	153/4800-5000	120/3600-4800 combustion 141 el.	120/3600-4800 combustion 141 el. 51 el. in the rear
Bore and stroke [mm x mm]	80.5 x 97.6	80.5 x 97.6	80.5 x 97.6	80.5 x 97.6
Compression ratio	14.0:1	14.0:1	14.0:1	14.0:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection D-4 engine operation in the Atkinson cycle variable timing of intake valves VVT-iW variable exhaust valve timing VVT-i	direct injection D-4 engine operation in the Atkinson cycle variable timing of intake valves VVT-iW variable exhaust valve timing VVT-i	Full Hybrid electric synchronous motor with permanent magnet engine operation in the Atkinson cycle variable timing of intake valves VVT-iE variable exhaust valve timing VVT-i	Full Hybrid electric synchronous motor with permanent magnet Asynchronous electric motor engine operation in the Atkinson cycle variable timing of intake valves VVT-iE variable exhaust valve timing VVT-i

Drive axle	Front	Front	Front	4x4
Gearbox	6 gear manual	1 gear automatic	1 gear automatic	1 gear automatic
Drive specifications	-	automatic gearbox W-CVT with one variable ratio	automatic gearbox e-CVT with one variable ratio	automatically controlled all-wheel drive AWD-i automatic gearbox e-CVT with one variable ratio

Top speed [km/h]	180	180	170	170
Acceleration 0–100 km/h [s]	10.9	11.7	11.2	11.8
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	-	-	-	-
Out of town [l]	-	-	-	-
Combined [l]	-	-	-	-
CO2 emissions [g/km]	-	-	-	-

Low speed [l]	-	-	-	-
Medium speed [l]	-	-	-	-
High speed [l]	-	-	-	-
Extra high speed [l]	-	-	-	-
Combined speed [l]	6.2-5.7	6.4-5.9	5.0-4.4	5.1-4.7
CO2 emissions [g/km]	140-130	144-134	113-100	115-106

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

System voltage [V]	-	-	-	-
Battery type and capacity	-	-	Lithium-Ionen-Akkumulator, 0.76 kWh	Lithium-Ionen-Akkumulator, 0.76 kWh
Range with fully charged battery [km]	-	-	-	-
Charging time	-	-	-	-
Number of modules/cells	-	-	-/48	-/48
Battery weight [kg]	-	-	-	-
Charger	-	-	-	-

Standby weight [kg]	1110-1225	1130-1240	1170-1290	1260-1360
Overall weight [kg]	1625	1640	1690	1775
Maximum trailer weight unbraked/braked [kg]	550/1350	550/1350	550/750	550/750
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	397	397	397	320
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1097	-/1097	-/1097	-/1038
Boot length [mm]	785	785	785	785
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	1047/1402	1047/1402	1047/1402	1047/1402
Boot height to headliner/ceiling [mm]	-/852	-/852	-/852	-/852
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	42	42	36	36
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.35	0.35	0.35	0.36
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	double wishbone
Tyre dimensions front	205/65 R16	205/65 R16	205/65 R16	205/65 R16
Tyre dimensions rear	205/65 R16	205/65 R16	205/65 R16	205/65 R16
Wheel size front	-	-	-	-
Wheel size rear	-	-	-	-
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	2.65	2.65	2.65	2.65
Turning diameter track/circumference [m]	10.6/11.2	10.6/11.2	10.6/11.2	10.6/11.2

Overall length [mm]	4180	4180	4180	4180
Overall width without/including mirrors [mm]	1765/-	1765/-	1765/-	1765/-
Overall height [mm]	1595	1595	1595	1595
Wheelbase [mm]	2560	2560	2560	2560
Front wheel track [mm]	1527	1527	1527	1514
Rear wheel track [mm]	1527	1527	1527	1514
Forward overhang [mm]	860	860	860	860
Rear overhang [mm]	760	760	760	760
Clearance [mm]	170	170	170	170
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	1291/1342	1291/1342	1291/1342	1291/1342
Rear elbow/shoulder width [mm]	1273/1316	1273/1316	1273/1316	1273/1316
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Toyota Yaris Cross XP210 2021 front seats

Toyota Yaris Cross XP210 2022 rear seats

Toyota Yaris Cross XP210 2022 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
