Toyota Yaris

Date of manufacture

6/2014 – 2017 (Three-door hatchback)

6/2014 – 2017 (Five-door hatchback)

Platform

Toyota B platform

Manufacturing locations

Ōbu, Japan

Kanegasaki, Japan

Valenciennes, France

Designer

Car body style

Three-door hatchback

after upgrade (facelift) (I.)

Date of manufacture

6/2014 – 2017

Internal designation

XP130

Engine size

1.0 VVT-i

Five-door hatchback

after upgrade (facelift) (I.)

Date of manufacture

6/2014 – 2017

Internal designation

XP130

Engine size

Petrol

1.0 VVT-i

1.33 Dual VVT-i

Petrol + Electric

1.5 VVT-i Hybrid

Diesel

1.4 D-4D

Euro NCAP

Test year 2011

pre-facelift version (2011)

Technical data

Three-door hatchback

	1.0 VVT-i
Date of sale	-
Engine type	Petrol
Number of cylinders/valves	3/12
Engine displacement [cm³]	998
Maximum output / speed [kW/min-1]	51/6000
Maximum torque [Nm/min-1]	95/4300
Bore and stroke [mm x mm]	71,0 x 84,0
Compression ratio	11,5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	variable timing of intake valves VVT‐i

Drive axle	Front
Gearbox	5 gear manual
Drive specifications	-

Top speed [km/h]	155
Acceleration 0–100 km/h [s]	15.3
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	5.2
Out of town [l]	3.8
Combined [l]	4.3
CO2 emissions [g/km]	99

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1065
Overall weight [kg]	1450
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	286
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/710
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	3
Number of seats	5
Fuel tank volume [l]	42
AdBlue tank volume [l]	-
Air resistance [Cd]	0.287
Front suspension	MacPherson
Rear suspension	torsion bar
Tyre dimensions front	175/70 R14
Tyre dimensions rear	175/70 R14
Wheel size front	5J x 14
Wheel size rear	5J x 14
Brake dimensions front	258
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	9.6/10.2

Overall length [mm]	3950
Overall width without/including mirrors [mm]	1695/-
Overall height [mm]	1510
Wheelbase [mm]	2510
Front wheel track [mm]	1485
Rear wheel track [mm]	1470
Forward overhang [mm]	810
Rear overhang [mm]	630
Clearance [mm]	135
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	998
Headroom rear [mm]	954
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Five-door hatchback

	1.0 VVT-i	1.33 Dual VVT-i	1.33 Dual VVT-i	1.5 VVT-i Hybrid	1.4 D-4D
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol + Electric	Diesel supercharged
Number of cylinders/valves	3/12	4/16	4/16	4/16	4/8
Engine displacement [cm³]	998	1329	1329	1497	1364
Maximum output / speed [kW/min-1]	51/6000	73/6000	73/6000	55/4800 combustion 45 el. 74 total	66/380
Maximum torque [Nm/min-1]	95/4300	125/4000	125/4000	111/3600-4400 combustion 169 el.	205/1800-2800
Bore and stroke [mm x mm]	71,0 x 84,0	72,5 x 80,5	72,5 x 80,5	75,0 x 84,7	73,0 x 81,5
Compression ratio	11,5:1	11,5:1	11,5:1	13,4:1	16,5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake and exhaust valves Dual VVT‐i	variable timing of intake and exhaust valves Dual VVT‐i	Full Hybrid variable timing of intake valves VVT‐i electric synchronous motor with permanent magnet	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	1 gear automatic	1 gear automatic	6 gear manual
Drive specifications	-	-	automatic gearbox Multidrive S with one variable ratio	automatic gearbox with one variable ratio e‐CVT	-

Top speed [km/h]	155	175	175	165	175
Acceleration 0–100 km/h [s]	15.3	11.7	12.6	11.8	10.8
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	5.2	6.4	6.2	3.1	4.2-4.6
Out of town [l]	3.8	4.1	4.2	3.3	3.1-3.3
Combined [l]	4.3	4.9	4.9	3.3	3.5-3.8
CO2 emissions [g/km]	99	114	114	75	91-99

Emission standard	EU6	EU5-EU6	EU5-EU6	EU6	EU5-EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

System voltage [V]	-	-	-	-	-
Battery type and capacity	-	-	-	Nickel metal hydride, 6.5 Ah	-
Range with fully charged battery [km]	-	-	-	-	-
Charging time	-	-	-	-	-
Number of modules/cells	-	-	-	-/120	-
Battery weight [kg]	-	-	-	-	-
Charger	-	-	-	-	-

Standby weight [kg]	1065	1107-1117	1127	1170-1180	1170
Overall weight [kg]	1450	1490	1500	1565	1545
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	286	286	286	286	286
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/710	-/710	-/710	-/710	-/710
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	42	42	42	36	42
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.287	0.287	0.287	0.286	0.287
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	175/70 R14	175/70 R14	175/65 R15	175/70 R14	175/64 R15
Tyre dimensions rear	175/70 R14	175/70 R14	175/65 R15	175/70 R14	175/64 R15
Wheel size front	5J x 14	5J x 14	5J x 15	5J x 14	5J x 15
Wheel size rear	5J x 14	5J x 14	5J x 15	5J x 14	5J x 15
Brake dimensions front	258	258	258	258	258
Brake dimensions rear	-	-	-	-	-
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	9.6/10.2	9.6/10.2	9.6/10.2	9.6/10.2	9.6/10.2

Overall length [mm]	3950	3950	3950	3950	3950
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1510	1510	1510	1510	1510
Wheelbase [mm]	2510	2510	2510	2510	2510
Front wheel track [mm]	1485	1485	1470	1485	1470
Rear wheel track [mm]	1470	1470	1460	1470	1460
Forward overhang [mm]	810	810	810	810	810
Rear overhang [mm]	630	630	630	630	630
Clearance [mm]	135	135	135	135	135
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	998	998	998	998	998
Headroom rear [mm]	954	954	954	954	954
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Toyota Yaris XP130 facelift 2014 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
