	1.0 VVT-i	1.33 Dual VVT-i
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	4/16
Engine displacement [cm³]	998	1329
Maximum output / speed [kW/min-1]	51/6000	74/6000
Maximum torque [Nm/min-1]	93/3600	132/3800
Bore and stroke [mm x mm]	71,0 x 84,0	72,5 x 80,5
Compression ratio	10,5:1	11,5:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake and exhaust valves Dual VVT‐i start&stop system

Drive axle	Front	Front
Gearbox	5 gear manual	6 gear manual
Drive specifications	-	-

Top speed [km/h]	155	175
Acceleration 0–100 km/h [s]	15.7	11.7
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	6.0	6.2
Out of town [l]	4.4	4.5
Combined [l]	5.0	5.1
CO2 emissions [g/km]	118	120

Emission standard	EU4-EU5	EU4-EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1065-1105	1115-1155
Overall weight [kg]	1440	1480
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	272-363	272-363
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/738	-/738
Boot length [mm]	535	535
Boot length with rear seats folded [mm]	1325	1325
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-/910	-/910
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	3
Number of seats	5	5
Fuel tank volume [l]	42	42
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar
Tyre dimensions front	165/70 R14	185/60 R15
Tyre dimensions rear	165/70 R14	185/60 R15
Wheel size front	5.0J x 14	5.5J x 15
Wheel size rear	5.0J x 14	5.5J x 15
Brake dimensions front	258	258
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-/8.8	-/9.4

Overall length [mm]	3785	3785
Overall width without/including mirrors [mm]	1695/-	1695/-
Overall height [mm]	1530	1530
Wheelbase [mm]	2460	2460
Front wheel track [mm]	1480	1470
Rear wheel track [mm]	1470	1460
Forward overhang [mm]	755	755
Rear overhang [mm]	570	570
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	1000	1000
Headroom rear [mm]	963	963
Front elbow/shoulder width [mm]	-/1300	-/1300
Rear elbow/shoulder width [mm]	-/1269	-/1269
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Five-door hatchback

	1.0 VVT-i	1.33 Dual VVT-i	1.33 Dual VVT-i	1.4 D-4D	1.4 D-4D	1.4 D-4D
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	3/12	4/16	4/16	4/8	4/8	4/8
Engine displacement [cm³]	998	1329	1329	1364	1364	1364
Maximum output / speed [kW/min-1]	51/6000	74/6000	74/6000	66/3800	66/3800	66/3800
Maximum torque [Nm/min-1]	93/3600	132/3800	132/3800	190/1800-3000	190/1800-3000	190/1800-3000
Bore and stroke [mm x mm]	71,0 x 84,0	72,5 x 80,5	72,5 x 80,5	73,0 x 81,5	73,0 x 81,5	73,0 x 81,5
Compression ratio	10,5:1	11,5:1	11,5:1	18,0:1	18,0:1	18,0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake and exhaust valves Dual VVT‐i start&stop system	variable timing of intake and exhaust valves Dual VVT‐i	direct injection Common Rail turbocharger with variable blade geometry	direct injection Common Rail turbocharger with variable blade geometry	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	6 gear robotic manual	6 gear manual	6 gear robotic manual	6 gear manual
Drive specifications	-	-	robotic gearbox MultiMode	-	robotic gearbox MultiMode	-

Top speed [km/h]	155	175	175	175	175	175
Acceleration 0–100 km/h [s]	15.7	11.7	13.4	10.7	11.9	10.7
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.0	6.2	6.2	5.1	5.1	5.1
Out of town [l]	4.4	4.5	4.4	3.6	3.6	3.6
Combined [l]	5.0	5.1	5.1	4.1	4.2	4.1
CO2 emissions [g/km]	118	120	119	109	110	109

Emission standard	EU4-EU5	EU4-EU5	EU4-EU5	EU4	EU4	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1065-1105	1115-1155	1115-1145	1130-1185	1135-1190	1130-1185
Overall weight [kg]	1440	1480	1480	1525	1525	1525
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	272-363	272-363	272-363	272-363	272-363	272-363
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/738	-/738	-/738	-/738	-/738	-/738
Boot length [mm]	535	535	535	535	535	535
Boot length with rear seats folded [mm]	1325	1325	1325	1325	1325	1325
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-/910	-/910	-/910	-/910	-/910	-/910
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	42	42	42	42	42	42
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	165/70 R14	185/60 R15	185/60 R15	185/60 R15	185/60 R15	185/60 R15
Tyre dimensions rear	165/70 R14	185/60 R15	185/60 R15	185/60 R15	185/60 R15	185/60 R15
Wheel size front	5.0J x 14	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15
Wheel size rear	5.0J x 14	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15
Brake dimensions front	258	258	258	258	258	258
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-/8.8	-/9.4	-/9.4	-/9.4	-/9.4	-/9.4

Overall length [mm]	3785	3785	3785	3785	3785	3785
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1530	1530	1530	1530	1530	1530
Wheelbase [mm]	2460	2460	2460	2460	2460	2460
Front wheel track [mm]	1480	1470	1470	1470	1470	1470
Rear wheel track [mm]	1470	1460	1460	1460	1460	1460
Forward overhang [mm]	755	755	755	755	755	755
Rear overhang [mm]	570	570	570	570	570	570
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1000	1000	1000	1000	1000	1000
Headroom rear [mm]	963	963	963	963	963	963
Front elbow/shoulder width [mm]	-/1300	-/1300	-/1300	-/1300	-/1300	-/1300
Rear elbow/shoulder width [mm]	-/1269	-/1269	-/1269	-/1269	-/1269	-/1269
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.4 D-4D
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	4/8
Engine displacement [cm³]	1364
Maximum output / speed [kW/min-1]	66/3800
Maximum torque [Nm/min-1]	190/1800-3000
Bore and stroke [mm x mm]	73,0 x 81,5
Compression ratio	18,0:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF

Drive axle	Front
Gearbox	6 gear robotic manual
Drive specifications	robotic gearbox MultiMode

Top speed [km/h]	175
Acceleration 0–100 km/h [s]	11.9
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	5.1
Out of town [l]	3.6
Combined [l]	4.2
CO2 emissions [g/km]	110

Emission standard	EU5
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1135-1190
Overall weight [kg]	1525
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	272-363
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/738
Boot length [mm]	535
Boot length with rear seats folded [mm]	1325
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-/910
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	42
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	torsion bar
Tyre dimensions front	185/60 R15
Tyre dimensions rear	185/60 R15
Wheel size front	5.5J x 15
Wheel size rear	5.5J x 15
Brake dimensions front	258
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	-/9.4

Overall length [mm]	3785
Overall width without/including mirrors [mm]	1695/-
Overall height [mm]	1530
Wheelbase [mm]	2460
Front wheel track [mm]	1470
Rear wheel track [mm]	1460
Forward overhang [mm]	755
Rear overhang [mm]	570
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	1000
Headroom rear [mm]	963
Front elbow/shoulder width [mm]	-/1300
Rear elbow/shoulder width [mm]	-/1269
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Toyota Yaris XP90 facelift 2009 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
