Toyota Urban Cruiser

Urban Cruiser XP110 2009

Date of manufacture

2008 – 2014 (MPV)

Platform

Toyota B

Manufacturing locations

Kanegasaki, Japan

Designer

Junho Kim
Masaaki Yagi

Tags

B-segment
Japanese cars
The Toyota Urban Cruiser is an MPV that was first released in 2008. It is from Japan and is built on the Toyota B platform. It offers a range of petrol and diesel engines, the most powerful of which is the 1.33 Dual VVT-i with a maximum output of 74 kW and a top speed of 175 km/h. The most fuel-efficient engine is the 1.4 D-4D with a consumption of 4.5 l/100 km and emissions of 118 g/km. The luggage compartment volume is 314 l. In terms of safety, the model achieved a rating of 3 out of 5 according to EURONCAP in 2009.

Car body style

MPV

Date of manufacture
2008 – 2014
Internal designation
XP110
Engine size
PetrolDiesel

Euro NCAP

Test year 2009
Rating
star iconstar iconstar iconstar iconstar icon
Adults
58 %
Adults
Children
71 %
Children
Pedestrians
53 %
Pedestrians
Assist systems
86 %
Assist systems

Technical data

MPV

1.33 Dual VVT-i 1.4 D-4D 1.4 D-4D
Date of sale---
Engine typePetrolDiesel superchargedDiesel supercharged
Number of cylinders/valves4/164/84/8
Engine displacement [cm³]132913641364
Maximum output / speed [kW/min-1]
74/6000
66/3800
66/3800
Maximum torque [Nm/min-1]
132/3800
205/1800-2800
205/1800-2800
Drive axleFrontFront4x4
Gearbox6 gear manual6 gear manual6 gear manual
Top speed [km/h]175175175
Acceleration 0–100 km/h [s]12.511.712.5
City [l]6.65.35.8
Out of town [l]4.94.04.4
Combined [l]5.54.54.9
CO2 emissions [g/km]129118130
Emission standardEU4-EU5EU4-EU5EU4-EU5
Standby weight [kg]1195-12251250-12751315-1345
Overall weight [kg]159016251700
Maximum trailer weight unbraked/braked [kg]550/800550/800550/800
Boot volume [l]314314230
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/749-/749-/673
Number of doors555
Number of seats555
Fuel tank volume [l]424242
AdBlue tank volume [l]---
Overall length [mm]393039303930
Overall width without/including mirrors [mm]1725/-1725/-1725/-
Overall height [mm]152515251540
Wheelbase [mm]245024502450
Headroom front [mm]---
Headroom rear [mm]---
Front elbow/shoulder width [mm]---
Rear elbow/shoulder width [mm]---

Gallery

Toyota Urban Cruiser XP110 interiorToyota Urban Cruiser XP110 2011 bootToyota Urban Cruiser XP110 2009 rear folding seats
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
