Toyota RAV4

RAV4 XA40 2015

Date of manufacture

2015 – 11/2018 (SUV)

Platform

Toyota New MC platform

Manufacturing locations

Ōbu, Japan
Toyota, Japan
Woodstock, Canada
Changchun, People's Republic of China
Saint Petersburg, Russia

Designer

Masaki Okue
Akira Kubota
Takuya Watabe

Tags

Compact SUV
Japanese cars
The Toyota RAV4 is an SUV that has been manufactured since 2015. The vehicle is built on the Toyota New MC platform and can be purchased in gasoline, diesel or hybrid engine versions. The highest power is achieved by the 2.5 Hybrid (145 kW), the fastest version is the 2.0 D-4D (195 km/h). The fuel consumption of this model is 4.7 l/100 km and the emissions are 123 g/km. The size of the luggage compartment is 547 l. During EURONCAP safety tests, this model received a rating of 5 out of 5 according to the 2013 methodology. The vehicle is manufactured in several countries, including Japan, Canada, the People's Republic of China and Russia.

Car body style

SUV

after upgrade (facelift)
Date of manufacture
2015 – 11/2018
Internal designation
XA40
Engine size
PetrolPetrol + ElectricDiesel

Euro NCAP

Test year 2013
pre-facelift version (2013)
Rating
star iconstar iconstar iconstar iconstar icon
Adults
89 %
Adults
Children
82 %
Children
Pedestrians
66 %
Pedestrians
Assist systems
66 %
Assist systems

Technical data

SUV

2.0 Valvematic 2.0 Valvematic 2.5 Hybrid 2.5 Hybrid 2.0 D-4D
Date of sale-----
Engine typePetrolPetrolPetrol + ElectricPetrol + ElectricDiesel supercharged
Number of cylinders/valves4/164/164/164/164/16
Engine displacement [cm³]19871987249424941995
Maximum output / speed [kW/min-1]
112/6200
112/6200
114/5700 combustion
105 el.
145 total
114/5700 combustion
105 el.
50 el. in the rear
145 total
105/4000
Maximum torque [Nm/min-1]
196/4000
196/4000
210/4200-4400 combustion
270 el.
210/4200-4400 combustion
270 el.
139 el. in the rear
320/1750-2250
Drive axle4x44x4Front4x4Front
Gearbox6 gear manual1 gear automatic1 gear automatic1 gear automatic6 gear manual
Top speed [km/h]185185180180195
Acceleration 0–100 km/h [s]9.910.78.38.39.6
City [l]8.8-8.58.5-8.25.1-4.95.1-4.95.5-5.4
Out of town [l]6.0-5.75.9-5.65.15.4-4.94.3
Combined [l]7.0-6.76.8-6.55.1-4.95.2-5.04.7
CO2 emissions [g/km]162-155157-149118-115118-115123
Emission standardEU6EU6EU6EU6EU6
System voltage [V]--650650-
Battery type and capacity--Nickel metal hydride, 1.59 kWhNickel metal hydride, 1.59 kWh-
Range with fully charged battery [km]-----
Charging time-----
Standby weight [kg]15651595170017651610
Overall weight [kg]21002110220522702135
Maximum trailer weight unbraked/braked [kg]750/2000750/1500750/800750/1650750/2000
Boot volume [l]547547501501547
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/1735-/1735-/1633-/1633-/1735
Number of doors55555
Number of seats55555
Fuel tank volume [l]6060565660
AdBlue tank volume [l]-----
Overall length [mm]46054605460546054605
Overall width without/including mirrors [mm]1845/-1845/-1845/-1845/-1845/-
Overall height [mm]16751675167516751675
Wheelbase [mm]26602660266026602660
Headroom front [mm]-----
Headroom rear [mm]-----
Front elbow/shoulder width [mm]-----
Rear elbow/shoulder width [mm]-----

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
