Toyota Proace Verso
Date of manufacture
2016 – to this day (VAN)
Platform
PSA EMP2
Manufacturing locations
Lieu-Saint-Amand, France
Designer
-
Tags
Minivan
Japanese cars
The Toyota Proace Verso is a vehicle built on the PSA EMP2 platform, first manufactured in France in 2016. The Proace Verso model is available as a VAN and offers a wide range of power units, from electric motors to the fastest 2.0 D-4D L2 model with a maximum power of 130 kW. The top speed of this car reaches 175 km/h, while the most economical variant 1.6 D-4D City has a combined consumption of 5 l/100 km and CO2 emissions of 133 g/km. The trunk volume is 1200 l and the Toyota Proace Verso earned a 5 out of 5 rating in the EURONCAP safety tests according to the 2015 methodology.
Car body style
VAN
Date of manufacture
2016 – to this dayInternal designation
-Engine size
ElectricDiesel
Technical data
VAN
| 50kWh L1 | 75 kWh L1 | 50 kWh L2 | 75 kWh L2 | 1.5 D-4D 100 Compact | 1.6 D-4D Compact | |
|---|---|---|---|---|---|---|
| Date of sale | from 2020 to | from 2020 to | from 2020 to | from 2020 to | from 2018 to | from to 2018 |
| Engine type | Electric | Electric | Electric | Electric | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | - | - | - | - | 4/16 | 4/8 |
| Engine displacement [cm³] | - | - | - | - | 1499 | 1560 |
| Maximum output / speed [kW/min-1] | 100 | 100 | 100 | 100 | 75/3500 | 85/3500 |
| Maximum torque [Nm/min-1] | 260 | 260 | 260 | 260 | 270/1600 | 300/1750 |
| Bore and stroke [mm x mm] | - | - | - | - | 75 x 84,8 | 75,0 x 88,3 |
| Compression ratio | - | - | - | - | - | 17,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 1 gear automatic | 1 gear automatic | 1 gear automatic | 1 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications |
|
|
|
| - | - |
| Top speed [km/h] | 130 | 130 | 130 | 130 | 160 | 160 |
| Acceleration 0–100 km/h [s] | - | - | - | - | 13.5 | 13.4 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | - | - | - | 6.3-5.9 | - |
| Out of town [l] | - | - | - | - | 5.2-4.8 | - |
| Combined [l] | - | - | - | - | 5.6-5.2 | 5.2-5.0 |
| CO2 emissions [g/km] | - | - | - | - | 138-137 | 137-133 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 26.6-25.3 kWh | 28.0-26.9 kWh | 26.6-25.3 kWh | 28.0-26.9 kWh | - | - |
| CO2 emissions [g/km] | - | - | - | - | - | - |
| Emission standard | - | - | - | - | Euro 6d-TEMP | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | Lithium-Ionen-Akkumulator, 50 kWh | Lithium-Ionen-Akkumulator, 75 kWh | Lithium-Ionen-Akkumulator, 50 kWh | Lithium-Ionen-Akkumulator, 75 kWh | - | - |
| Range with fully charged battery [km] | 219 | 314 | 219 | 314 | - | - |
| Charging time |
|
|
|
| - | - |
| Number of modules/cells | 18/216 | - | 18/216 | - | - | - |
| Battery weight [kg] | 383 | 534 | 383 | 534 | - | - |
| Charger | 100 kW fast charging, 11 kW on-board charger | 100 kW fast charging, 11 kW on-board charger | 100 kW fast charging, 11 kW on-board charger | 100 kW fast charging, 11 kW on-board charger | - | - |
| Standby weight [kg] | - | - | - | - | 1707 | - |
| Overall weight [kg] | - | - | - | - | 2625 | - |
| Maximum trailer weight unbraked/braked [kg] | -/1000 | -/1000 | -/1000 | -/1000 | 750/1800 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | 1500/1500 | - |
| Maximum vertical load on the tow bar [kg] | 60 | 60 | 60 | 60 | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 1600 | 1600 | 2000 | 2000 | 1200 | 1200 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 3061/3968 | 3061/3968 | 3497/4554 | 3497/4554 | 2625/3397 | 2625/3397 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 192 | 192 | 192 | 192 | 192 | 192 |
| Boot length with rear seats folded [mm] | 2413 | 2413 | 2763 | 2763 | 2063 | 2063 |
| Boot width between wheels/max [mm] | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 |
| Boot height to headliner/ceiling [mm] | -/1337 | -/1337 | -/1339 | -/1339 | -/1334 | -/1334 |
| Loading edge height [mm] | 584-653 | 584-653 | 584-664 | 584-664 | 587-610 | 587-610 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1181 | 1181 | 1181 | 1181 | 1177 | 1177 |
| Boot opening width min/max [mm] | -/1212 | -/1212 | -/1212 | -/1212 | -/1229 | -/1229 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 |
| Fuel tank volume [l] | - | - | - | - | 69 | 69 |
| AdBlue tank volume [l] | - | - | - | - | 20.6 | 20.6 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Tyre dimensions rear | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 11.3/11.8 | 11.3/11.8 |
| Overall length [mm] | 4959 | 4959 | 5309 | 5309 | 4609 | 4609 |
| Overall width without/including mirrors [mm] | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 |
| Overall height [mm] | 1890 | 1890 | 1890 | 1890 | 1905 | 1905 |
| Wheelbase [mm] | 3275 | 3275 | 3275 | 3275 | 2925 | 2925 |
| Front wheel track [mm] | 1630 | 1630 | 1630 | 1630 | 1630 | 1630 |
| Rear wheel track [mm] | 1618 | 1618 | 1618 | 1618 | 1618 | 1618 |
| Forward overhang [mm] | 881 | 881 | 881 | 881 | 881 | 881 |
| Rear overhang [mm] | 803 | 803 | 1153 | 1153 | 803 | 803 |
| Clearance [mm] | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 |
| Rear elbow/shoulder width [mm] | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | - | - | - | - | - | - |
| Third row elbow/shoulder width [mm] | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- |
| 1.5 D-4D 120 Compact | 2.0 D-4D 140 Compact | 2.0 D-4D 140 Compact | 2.0 D-4D 150 Compact | 2.0 D-4D 180 Compact | 2.0 D-4D 180 Compact | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | from 2020 to | from 2020 to | from to 2020 | from to 2018 | from 2018 to |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1499 | 1997 | 1997 | 1997 | 1997 | 1997 |
| Maximum output / speed [kW/min-1] | 88/3500 | 106/3700 | 106/3700 | 110/4000 | 130/3750 | 130/3750 |
| Maximum torque [Nm/min-1] | 300/1750 | 370/2000 | 370/2000 | 370/2000 | 400/2000 | 400/2000 |
| Bore and stroke [mm x mm] | 75 x 84,8 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 8 gear automatic | 6 gear manual | 6 gear automatic | 8 gear automatic |
| Drive specifications | - | - |
| - |
|
|
| Top speed [km/h] | 160-172 | 175 | 175 | 170-185 | 170 | 175-185 |
| Acceleration 0–100 km/h [s] | 12.0 | - | - | 11.0-13.0 | 10.1 | 10.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.8-5.2 | 5.8-5.6 | 5.5 | 6.6-6.1 | - | 7.7-5.4 |
| Out of town [l] | 5.0-4.4 | 5.0-4.8 | 4.8 | 5.4-5.0 | - | 5.7-4.8 |
| Combined [l] | 5.3-4.8 | 5.3-5.1 | 5.1-5.0 | 5.8-5.3 | 5.9-5.7 | 6.4-5.0 |
| CO2 emissions [g/km] | 141-127 | 139-135 | 134-133 | 154-139 | 155-151 | 160-133 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 7.2-6.8 | 7.3-6.9 | 5.7-5.3 | - | - | 5.8-5.6 |
| CO2 emissions [g/km] | 163-153 | 164-156 | 149-140 | - | - | 152-146 |
| Emission standard | Euro 6d-TEMP - Euro 6d | Euro 6d | Euro 6d | EU6 - Euro 6d-TEMP | EU6 | Euro 6d-TEMP - Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1709 | - | - | 1735 | - | 1845 |
| Overall weight [kg] | 2650 | - | - | 2675 | - | 2850 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/1900 | 750/1900 | 750/2300-2500 | 750/2200 | 750/2200 |
| Maximum front/rear axle load [kg] | 1500/1500 | - | - | 1500/1500 | - | 1500/1500 |
| Maximum vertical load on the tow bar [kg] | - | 84 | 84 | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 2625/3397 | 2625/3397 | 2625/3397 | 2625/3397 | 2625/3397 | 2625/3397 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 192 | 192 | 192 | 192 | 192 | 192 |
| Boot length with rear seats folded [mm] | 2063 | 2063 | 2063 | 2063 | 2063 | 2063 |
| Boot width between wheels/max [mm] | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 |
| Boot height to headliner/ceiling [mm] | -/1334 | -/1334 | -/1334 | -/1334 | -/1334 | -/1334 |
| Loading edge height [mm] | 587-610 | 587-610 | 587-610 | 587-610 | 587-610 | 587-610 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1177 | 1177 | 1177 | 1177 | 1177 | 1177 |
| Boot opening width min/max [mm] | -/1229 | -/1229 | -/1229 | -/1229 | -/1229 | -/1229 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 |
| Fuel tank volume [l] | 69 | 69 | 69 | 69 | 69 | 69 |
| AdBlue tank volume [l] | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Tyre dimensions rear | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.3/11.8 | 11.3/11.8 | 11.3/11.8 | 11.3/11.8 | 11.3/11.8 | 11.3/11.8 |
| Overall length [mm] | 4609 | 4609 | 4609 | 4609 | 4609 | 4609 |
| Overall width without/including mirrors [mm] | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 |
| Overall height [mm] | 1905 | 1905 | 1905 | 1905 | 1905 | 1905 |
| Wheelbase [mm] | 2925 | 2925 | 2925 | 2925 | 2925 | 2925 |
| Front wheel track [mm] | 1630 | 1630 | 1630 | 1630 | 1630 | 1630 |
| Rear wheel track [mm] | 1618 | 1618 | 1618 | 1618 | 1618 | 1618 |
| Forward overhang [mm] | 881 | 881 | 881 | 881 | 881 | 881 |
| Rear overhang [mm] | 803 | 803 | 803 | 803 | 803 | 803 |
| Clearance [mm] | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 |
| Rear elbow/shoulder width [mm] | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | - | - | - | - | - | - |
| Third row elbow/shoulder width [mm] | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- |
| 1.5 D-4D L1 | 1.6 D-4D L1 | 1.5 D-4D L1 | 2.0 D-4D L1 | 2.0 D-4D L1 | 2.0 D-4D L1 | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | from to 2018 | from 2018 to | from 2020 to | from 2020 to | from to 2020 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/8 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1499 | 1560 | 1499 | 1997 | 1997 | 1997 |
| Maximum output / speed [kW/min-1] | 75/3500 | 85/3500 | 88/3500 | 106/3700 | 106/3700 | 110/4000 |
| Maximum torque [Nm/min-1] | 270/1600 | 300/1750 | 300/1750 | 370/2000 | 370/2000 | 370/2000 |
| Bore and stroke [mm x mm] | 75 x 84,8 | 75,0 x 88,3 | 75 x 84,8 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | - | 17,0:1 | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic | 6 gear manual |
| Drive specifications | - | - | - | - |
| - |
| Top speed [km/h] | 160 | 160 | 160-172 | 175 | 175 | 170-185 |
| Acceleration 0–100 km/h [s] | 13.5 | 13.4 | 12.0 | - | - | 11.0-13.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.3-5.9 | - | 6.8-5.2 | 5.8-5.6 | 5.5 | 6.6-6.1 |
| Out of town [l] | 5.2-4.8 | - | 5.0-4.4 | 5.0-4.8 | 4.8 | 5.4-5.0 |
| Combined [l] | 5.6-5.2 | 5.2-5.0 | 5.3-4.8 | 5.3-5.1 | 5.1-5.0 | 5.8-5.3 |
| CO2 emissions [g/km] | 138-137 | 137-133 | 141-127 | 139-135 | 134-133 | 154-139 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | - | 6.7-6.3 | 7.4-6.9 | 7.2 | - |
| CO2 emissions [g/km] | - | - | 176-165 | 195-182 | 190-189 | - |
| Emission standard | Euro 6d-TEMP | EU6 | Euro 6d-TEMP - Euro 6d | Euro 6d | Euro 6d | EU6 - Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | - | - | - | - | - | - |
| Overall weight [kg] | - | - | - | - | - | - |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/2000 | 750/1800 | 750/1900 | 750/1900 | 750/2300-2500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | 84 | 84 | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 1600 | 1600 | 1600 | 1600 | 1600 | 1600 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 3061/3968 | 3061/3968 | 3061/3968 | 3061/3968 | 3061/3968 | 3061/3968 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 192 | 192 | 192 | 192 | 192 | 192 |
| Boot length with rear seats folded [mm] | 2413 | 2413 | 2413 | 2413 | 2413 | 2413 |
| Boot width between wheels/max [mm] | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 |
| Boot height to headliner/ceiling [mm] | -/1337 | -/1337 | -/1337 | -/1337 | -/1337 | -/1337 |
| Loading edge height [mm] | 584-653 | 584-653 | 584-653 | 584-653 | 584-653 | 584-653 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1181 | 1181 | 1181 | 1181 | 1181 | 1181 |
| Boot opening width min/max [mm] | -/1212 | -/1212 | -/1212 | -/1212 | -/1212 | -/1212 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 |
| Fuel tank volume [l] | 69 | 69 | 69 | 69 | 69 | 69 |
| AdBlue tank volume [l] | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Tyre dimensions rear | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 |
| Overall length [mm] | 4959 | 4959 | 4959 | 4959 | 4959 | 4959 |
| Overall width without/including mirrors [mm] | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 |
| Overall height [mm] | 1890 | 1890 | 1890 | 1890 | 1890 | 1890 |
| Wheelbase [mm] | 3275 | 3275 | 3275 | 3275 | 3275 | 3275 |
| Front wheel track [mm] | 1630 | 1630 | 1630 | 1630 | 1630 | 1630 |
| Rear wheel track [mm] | 1618 | 1618 | 1618 | 1618 | 1618 | 1618 |
| Forward overhang [mm] | 881 | 881 | 881 | 881 | 881 | 881 |
| Rear overhang [mm] | 803 | 803 | 803 | 803 | 803 | 803 |
| Clearance [mm] | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 |
| Rear elbow/shoulder width [mm] | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | - | - | - | - | - | - |
| Third row elbow/shoulder width [mm] | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- |
| 2.0 D-4D L1 | 2.0 D-4D L1 | 1.6 D-4D L2 | 1.5 D-4D L2 | 2.0 D-4D L2 | 2.0 D-4D L2 | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from 2018 to | from to 2018 | from 2018 to | from 2020 to | from 2020 to |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/8 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1997 | 1997 | 1560 | 1499 | 1997 | 1997 |
| Maximum output / speed [kW/min-1] | 130/3750 | 130/3750 | 85/3500 | 88/3500 | 106/3700 | 106/3700 |
| Maximum torque [Nm/min-1] | 400/2000 | 400/2000 | 300/1750 | 300/1750 | 370/2000 | 370/2000 |
| Bore and stroke [mm x mm] | 85,0 x 88,0 | 85,0 x 88,0 | 75,0 x 88,3 | 75 x 84,8 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | - | - | 17,0:1 | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic |
| Drive specifications |
|
| - | - | - |
|
| Top speed [km/h] | 170 | 175-185 | 160 | 160-172 | 175 | 175 |
| Acceleration 0–100 km/h [s] | 10.1 | 10.1 | 13.4 | 12.0 | - | - |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | 7.7-5.4 | - | 6.8-5.2 | 5.8-5.6 | 5.5 |
| Out of town [l] | - | 5.7-4.8 | - | 5.0-4.4 | 5.0-4.8 | 4.8 |
| Combined [l] | 5.9-5.7 | 6.4-5.0 | 5.2-5.0 | 5.3-4.8 | 5.3-5.1 | 5.1-5.0 |
| CO2 emissions [g/km] | 155-151 | 170-133 | 137-133 | 141-127 | 139-135 | 134-133 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | 7.7-7.0 | - | 6.7-6.3 | 7.4-6.9 | 7.2 |
| CO2 emissions [g/km] | - | 201-182 | - | 176-165 | 195-182 | 190-189 |
| Emission standard | EU6 | Euro 6d-TEMP - Euro 6d | EU6 | Euro 6d-TEMP - Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | - | - | - | - | - | - |
| Overall weight [kg] | - | - | - | - | - | - |
| Maximum trailer weight unbraked/braked [kg] | 750/2200 | 750/2000-2200 | 750/2000 | 750/1800 | 750/1900 | 750/1900 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | 84 | 84 |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 1600 | 1600 | 2000 | 2000 | 2000 | 2000 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 3061/3968 | 3061/3968 | 3497/4554 | 3497/4554 | 3497/4554 | 3497/4554 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 192 | 192 | 192 | 192 | 192 | 192 |
| Boot length with rear seats folded [mm] | 2413 | 2413 | 2763 | 2763 | 2763 | 2763 |
| Boot width between wheels/max [mm] | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 | 1288/1618 |
| Boot height to headliner/ceiling [mm] | -/1337 | -/1337 | -/1339 | -/1339 | -/1339 | -/1339 |
| Loading edge height [mm] | 584-653 | 584-653 | 584-664 | 584-664 | 584-664 | 584-664 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1181 | 1181 | 1181 | 1181 | 1181 | 1181 |
| Boot opening width min/max [mm] | -/1212 | -/1212 | -/1212 | -/1212 | -/1212 | -/1212 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 | 5-9 |
| Fuel tank volume [l] | 69 | 69 | 69 | 69 | 69 | 69 |
| AdBlue tank volume [l] | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 | 20.6 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Tyre dimensions rear | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C | 215/65 R16C |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 |
| Overall length [mm] | 4959 | 4959 | 5309 | 5309 | 5309 | 5309 |
| Overall width without/including mirrors [mm] | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 | 1920/2204 |
| Overall height [mm] | 1890 | 1890 | 1890 | 1890 | 1890 | 1890 |
| Wheelbase [mm] | 3275 | 3275 | 3275 | 3275 | 3275 | 3275 |
| Front wheel track [mm] | 1630 | 1630 | 1630 | 1630 | 1630 | 1630 |
| Rear wheel track [mm] | 1618 | 1618 | 1618 | 1618 | 1618 | 1618 |
| Forward overhang [mm] | 881 | 881 | 881 | 881 | 881 | 881 |
| Rear overhang [mm] | 803 | 803 | 1153 | 1153 | 1153 | 1153 |
| Clearance [mm] | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 | 150-175 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 | 1515/1712 |
| Rear elbow/shoulder width [mm] | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- | 1586/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | - | - | - | - | - | - |
| Third row elbow/shoulder width [mm] | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- | 1570/- |
| 2.0 D-4D L2 | 2.0 D-4D L2 | 2.0 D-4D L2 | ||||
|---|---|---|---|---|---|---|
| Date of sale | from to 2020 | from to 2018 | from 2018 to | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1997 | 1997 | 1997 | |||
| Maximum output / speed [kW/min-1] | 110/4000 | 130/3750 | 130/3750 | |||
| Maximum torque [Nm/min-1] | 370/2000 | 400/2000 | 400/2000 | |||
| Bore and stroke [mm x mm] | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | |||
| Compression ratio | - | - | - | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | Front | |||
| Gearbox | 6 gear manual | 6 gear automatic | 8 gear automatic | |||
| Drive specifications | - |
|
| |||
| Top speed [km/h] | 170-185 | 170 | 175-185 | |||
| Acceleration 0–100 km/h [s] | 11.0-13.0 | 10.1 | 10.1 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 6.6-6.1 | - | 7.7-5.4 | |||
| Out of town [l] | 5.4-5.0 | - | 5.3-4.8 | |||
| Combined [l] | 5.8-5.3 | 5.9-5.7 | 6.4-5.0 | |||
| CO2 emissions [g/km] | 154-139 | 155-151 | 170-133 | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | - | - | 7.7-7.0 | |||
| CO2 emissions [g/km] | - | - | 201-182 | |||
| Emission standard | EU6 - Euro 6d-TEMP | EU6 | Euro 6d-TEMP - Euro 6d | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | - | - | - | |||
| Overall weight [kg] | - | - | - | |||
| Maximum trailer weight unbraked/braked [kg] | 750/2300-2500 | 750/2200 | 750/2000-2200 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | - | - | - | |||
| Boot volume [l] | 2000 | 2000 | 2000 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 3497/4554 | 3497/4554 | 3497/4554 | |||
| Boot volume, third row of seats [l] | - | - | - | |||
| Boot volume, third row seats folded [l] | - | - | - | |||
| Boot length [mm] | 192 | 192 | 192 | |||
| Boot length with rear seats folded [mm] | 2763 | 2763 | 2763 | |||
| Boot width between wheels/max [mm] | 1288/1618 | 1288/1618 | 1288/1618 | |||
| Boot height to headliner/ceiling [mm] | -/1339 | -/1339 | -/1339 | |||
| Loading edge height [mm] | 584-664 | 584-664 | 584-664 | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | 1181 | 1181 | 1181 | |||
| Boot opening width min/max [mm] | -/1212 | -/1212 | -/1212 | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5-9 | 5-9 | 5-9 | |||
| Fuel tank volume [l] | 69 | 69 | 69 | |||
| AdBlue tank volume [l] | 20.6 | 20.6 | 20.6 | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 215/65 R16C | 215/65 R16C | 215/65 R16C | |||
| Tyre dimensions rear | 215/65 R16C | 215/65 R16C | 215/65 R16C | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | - | - | - | |||
| Brake dimensions rear | - | - | - | |||
| Steering | - | - | - | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 12.4/12.9 | 12.4/12.9 | 12.4/12.9 | |||
| Overall length [mm] | 5309 | 5309 | 5309 | |||
| Overall width without/including mirrors [mm] | 1920/2204 | 1920/2204 | 1920/2204 | |||
| Overall height [mm] | 1890 | 1890 | 1890 | |||
| Wheelbase [mm] | 3275 | 3275 | 3275 | |||
| Front wheel track [mm] | 1630 | 1630 | 1630 | |||
| Rear wheel track [mm] | 1618 | 1618 | 1618 | |||
| Forward overhang [mm] | 881 | 881 | 881 | |||
| Rear overhang [mm] | 1153 | 1153 | 1153 | |||
| Clearance [mm] | 150-175 | 150-175 | 150-175 | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | - | - | - | |||
| Headroom rear [mm] | - | - | - | |||
| Front elbow/shoulder width [mm] | 1515/1712 | 1515/1712 | 1515/1712 | |||
| Rear elbow/shoulder width [mm] | 1586/- | 1586/- | 1586/- | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - | |||
| Third row of seats, headroom [mm] | - | - | - | |||
| Third row elbow/shoulder width [mm] | 1570/- | 1570/- | 1570/- |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
