Toyota Mirai

Date of manufacture

12/2020 – to this day (Sedan)

Platform

TNGA: GA-L

Manufacturing locations

Toyota, Japan

Designer

Car body style

Sedan

Date of manufacture

12/2020 – to this day

Internal designation

JPD20

Engine size

Mirai

Euro NCAP

Technical data

Sedan

	Mirai
Date of sale	-
Engine type	Electric
Number of cylinders/valves	-
Engine displacement [cm³]	-
Maximum output / speed [kW/min-1]	134
Maximum torque [Nm/min-1]	300
Bore and stroke [mm x mm]	-
Compression ratio	-
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	electric synchronous motor with permanent magnet Hydrogen fuel cells

Drive axle	Rear
Gearbox	1 gear automatic
Drive specifications	constant ratio gearbox

Top speed [km/h]	175
Acceleration 0–100 km/h [s]	9.0
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	-
Out of town [l]	-
Combined [l]	-
CO2 emissions [g/km]	-

Low speed [l]	-
Medium speed [l]	-
High speed [l]	-
Extra high speed [l]	-
Combined speed [l]	0.89-0.79 kg
CO2 emissions [g/km]	-

Emission standard	-
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	-
Battery type and capacity	Lithium-Ionen-Akkumulator, 1.24 kWh
Range with fully charged battery [km]	-
Charging time	-
Number of modules/cells	-
Battery weight [kg]	-
Charger	-

Standby weight [kg]	1900-1950
Overall weight [kg]	2415
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	273
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	4
Number of seats	5
Fuel tank volume [l]	5.6 kg
AdBlue tank volume [l]	-
Air resistance [Cd]	0.29
Front suspension	multilink
Rear suspension	multilink
Tyre dimensions front	235/55 R19
Tyre dimensions rear	235/55 R19
Wheel size front	8.0J x 19
Wheel size rear	8.0J x 19
Brake dimensions front	-
Brake dimensions rear	-
Steering	Rack & pinion with electric power steering
Number of steering wheel turns	-
Turning diameter track/circumference [m]	11.6/12.6

Overall length [mm]	4975
Overall width without/including mirrors [mm]	1885/-
Overall height [mm]	1480
Wheelbase [mm]	2920
Front wheel track [mm]	1610
Rear wheel track [mm]	1605
Forward overhang [mm]	965
Rear overhang [mm]	1090
Clearance [mm]	150
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
