Basic information Technical Specifications Gallery

Toyota Land Cruiser

Date of manufacture

2017 – 2020 (SUV)

Platform

Manufacturing locations

Tahara, Japan

Sichuan, People's Republic of China

Designer

Car body style

SUV

after upgrade (facelift) (II.)

Date of manufacture

2017 – 2020

Internal designation

J150

Engine size

2.8 D-4D

Technical data

SUV

	2.8 D-4D	2.8 D-4D	2.8 D-4D	2.8 D-4D
Date of sale	-	-	-	-
Engine type	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2755	2755	2755	2755
Maximum output / speed [kW/min-1]	130/3400	130/3400	130/3400	130/3400
Maximum torque [Nm/min-1]	420-450/1400-3000	420-450/1400-3000	420-450/1400-3000	420-450/1400-3000
Bore and stroke [mm x mm]	92,0 x 103,6	92,0 x 103,6	92,0 x 103,6	92,0 x 103,6
Compression ratio	15,6:1	15,6:1	15,6:1	15,6:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry SCR catalytic converter with AdBlue additive injection

Drive axle	4x4	4x4	4x4	4x4
Gearbox	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	automatically controlled all-wheel drive s mezinápravovým diferenciálem Torsen LSD	automatically controlled all-wheel drive s mezinápravovým diferenciálem Torsen LSD	automatically controlled all-wheel drive s mezinápravovým diferenciálem Torsen LSD	automatically controlled all-wheel drive s mezinápravovým diferenciálem Torsen LSD

Top speed [km/h]	175	175	175	175
Acceleration 0–100 km/h [s]	12.1	12.7	12.1	12.7
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.6	8.6	8.6	8.6
Out of town [l]	6.5	6.5	6.5	6.5
Combined [l]	7.4	7.4	7.4	7.4
CO2 emissions [g/km]	190	190	190	190

Emission standard	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	2140	2140	2265	2265
Overall weight [kg]	2600	2600	2930-2990	2930-2990
Maximum trailer weight unbraked/braked [kg]	750/3000	750/3000	750/3000	750/3000
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	120	120	120	120
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-

Boot volume [l]	381	381	621	621
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	827/1434	827/1434	-/1934	-/1934
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	3	3	5	5
Number of seats	5	5	5-7	5-7
Fuel tank volume [l]	87	87	87	87
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.35	0.35	0.35	0.35
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	rigid	rigid	rigid	rigid
Tyre dimensions front	265/65 R17	265/65 R17	265/65 R17	265/65 R17
Tyre dimensions rear	265/65 R17	265/65 R17	265/65 R17	265/65 R17
Wheel size front	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17
Wheel size rear	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.4/10.4	10.4/10.4	11.6/11.8	11.6/11.8

Overall length [mm]	4395	4395	4840	4840
Overall width without/including mirrors [mm]	1885/-	1885/-	1885/-	1885/-
Overall height [mm]	1830	1830	1845	1845
Wheelbase [mm]	2450	2450	2790	2790
Front wheel track [mm]	1585	1585	1585	1585
Rear wheel track [mm]	1585	1585	1585	1585
Forward overhang [mm]	915	915	915	915
Rear overhang [mm]	1140	1140	1075	1075
Clearance [mm]	205	205	215	215
Wading depth [mm]	700	700	700	700
Approach angle front [°]	32	32	32	32
Approach angle rear [°]	26	26	25	25
Transition angle [°]	25	25	22	22
Climbing rate [°]	42	42	42	42
Maximum side tilt [°]	42	42	42	42

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Toyota Land Cruiser J150 facelift 2017 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
