Toyota Aygo

Date of manufacture

2018 – 2021 (Three-door hatchback)

2018 – 2021 (Five-door hatchback)

Platform

Manufacturing locations

Kolín, Czechia

Designer

Car body style

Three-door hatchback

after upgrade (facelift)

Date of manufacture

2018 – 2021

Internal designation

AB40

Engine size

1.0 VVT-i

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2018 – 2021

Internal designation

AB40

Engine size

1.0 VVT-i

Euro NCAP

Test year 2017

pre-facelift version (2017)

pre-facelift version (2017, safety pack)

Technical data

Three-door hatchback

	1.0 VVT-i	1.0 VVT-i
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	998	998
Maximum output / speed [kW/min-1]	53/6000	53/6000
Maximum torque [Nm/min-1]	95/4300	95/4300
Bore and stroke [mm x mm]	71,0 x 84,0	71,0 x 84,0
Compression ratio	11,8:1	11,8:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake valves VVT‐i

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear robotic manual
Drive specifications	-	robotic gearbox x‐shift (automatic or manual mode)

Top speed [km/h]	160	160
Acceleration 0–100 km/h [s]	13.8-14.2	15.2-15.5
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	4.9	4.9
Out of town [l]	3.6	3.8
Combined [l]	4.1	4.2
CO2 emissions [g/km]	93	95

Low speed [l]	-	-
Medium speed [l]	-	-
High speed [l]	-	-
Extra high speed [l]	-	-
Combined speed [l]	5.0	5.2
CO2 emissions [g/km]	114-112	118

Emission standard	Euro 6d-TEMP	Euro 6d-TEMP
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	915-985	915-985
Overall weight [kg]	1240	1240
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	50/-	50/-

Boot volume [l]	168	168
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/812	-/812
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	3
Number of seats	4	4
Fuel tank volume [l]	35	35
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.28	0.28
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/65 R14	165/60 R15
Tyre dimensions rear	165/65 R14	165/60 R15
Wheel size front	4.5J x 14	4.5J x 15
Wheel size rear	4.5J x 14	4.5J x 15
Brake dimensions front	247x20	247x20
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/10.2	9.6/10.2

Overall length [mm]	3465	3465
Overall width without/including mirrors [mm]	1615/-	1615/-
Overall height [mm]	1460	1460
Wheelbase [mm]	2340	2340
Front wheel track [mm]	1430	1430
Rear wheel track [mm]	1420	1420
Forward overhang [mm]	685	685
Rear overhang [mm]	440	440
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Five-door hatchback

	1.0 VVT-i	1.0 VVT-i
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	998	998
Maximum output / speed [kW/min-1]	53/6000	53/6000
Maximum torque [Nm/min-1]	95/4300	95/4300
Bore and stroke [mm x mm]	71,0 x 84,0	71,0 x 84,0
Compression ratio	11,8:1	11,8:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake valves VVT‐i

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear robotic manual
Drive specifications	-	robotic gearbox x‐shift (automatic or manual mode)

Top speed [km/h]	160	160
Acceleration 0–100 km/h [s]	13.8-14.2	15.2-15.5
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	4.9	4.9
Out of town [l]	3.6	3.8
Combined [l]	4.1	4.2
CO2 emissions [g/km]	93	95

Low speed [l]	-	-
Medium speed [l]	-	-
High speed [l]	-	-
Extra high speed [l]	-	-
Combined speed [l]	5.0	5.2
CO2 emissions [g/km]	114-112	118

Emission standard	Euro 6d-TEMP	Euro 6d-TEMP
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	915-985	915-985
Overall weight [kg]	1240	1240
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	50/-	50/-

Boot volume [l]	168	168
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/812	-/812
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	4	4
Fuel tank volume [l]	35	35
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.28	0.28
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/65 R14	165/60 R15
Tyre dimensions rear	165/65 R14	165/60 R15
Wheel size front	4.5J x 14	4.5J x 15
Wheel size rear	4.5J x 14	4.5J x 15
Brake dimensions front	247x20	247x20
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/10.2	9.6/10.2

Overall length [mm]	3465	3465
Overall width without/including mirrors [mm]	1615/-	1615/-
Overall height [mm]	1460	1460
Wheelbase [mm]	2340	2340
Front wheel track [mm]	1430	1430
Rear wheel track [mm]	1420	1420
Forward overhang [mm]	685	685
Rear overhang [mm]	440	440
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Toyota Aygo AB40 facelift 2019 front seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
