Basic information Technical Specifications Gallery

Toyota Aygo

Date of manufacture

5/2014 – 2018 (Three-door hatchback)

5/2014 – 2018 (Five-door hatchback)

Platform

Manufacturing locations

Kolín, Czechia

Designer

Nobuo Nakamura

Car body style

Three-door hatchback

Date of manufacture

5/2014 – 2018

Internal designation

AB40

Engine size

1.0 VVT-i

Five-door hatchback

Date of manufacture

5/2014 – 2018

Internal designation

AB40

Engine size

1.0 VVT-i

Euro NCAP

Technical data

Three-door hatchback

	1.0 VVT-i	1.0 VVT-i
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	998	998
Maximum output / speed [kW/min-1]	51/6000	51/6000
Maximum torque [Nm/min-1]	95/4300	95/4300
Bore and stroke [mm x mm]	71,0 x 84,0	71,0 x 84,0
Compression ratio	11,5:1	11,5:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake valves VVT‐i

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear robotic manual
Drive specifications	-	robotic gearbox x‐shift (automatic or manual mode)

Top speed [km/h]	160	160
Acceleration 0–100 km/h [s]	14.2	15.5
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	5.0	5.0
Out of town [l]	3.6	3.8
Combined [l]	4.1	4.2
CO2 emissions [g/km]	95	97

Emission standard	EU5-EU6	EU5-EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	915-930	935
Overall weight [kg]	1240	1240
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	50/-	50/-

Boot volume [l]	168	168
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/812	-/812
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	3
Number of seats	4	4
Fuel tank volume [l]	35	35
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.29	0.29
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/65 R14	165/60 R15
Tyre dimensions rear	165/65 R14	165/60 R15
Wheel size front	4.5J x 14	4.5J x 15
Wheel size rear	4.5J x 14	4.5J x 15
Brake dimensions front	247x20	247x20
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/10.2	9.6/10.2

Overall length [mm]	3455	3455
Overall width without/including mirrors [mm]	1615/-	1615/-
Overall height [mm]	1460	1460
Wheelbase [mm]	2340	2340
Front wheel track [mm]	1425	1430
Rear wheel track [mm]	1420	1420
Forward overhang [mm]	675	675
Rear overhang [mm]	440	440
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Five-door hatchback

	1.0 VVT-i	1.0 VVT-i
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	998	998
Maximum output / speed [kW/min-1]	51/6000	51/6000
Maximum torque [Nm/min-1]	95/4300	95/4300
Bore and stroke [mm x mm]	71,0 x 84,0	71,0 x 84,0
Compression ratio	11,5:1	11,5:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT‐i	variable timing of intake valves VVT‐i

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear robotic manual
Drive specifications	-	robotic gearbox x‐shift (automatic or manual mode)

Top speed [km/h]	160	160
Acceleration 0–100 km/h [s]	14.2	15.5
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	5.0	5.0
Out of town [l]	3.6	3.8
Combined [l]	4.1	4.2
CO2 emissions [g/km]	95	97

Emission standard	EU5-EU6	EU5-EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	915-930	935
Overall weight [kg]	1240	1240
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	50/-	50/-

Boot volume [l]	168	168
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/812	-/812
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	4	4
Fuel tank volume [l]	35	35
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.29	0.29
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/65 R14	165/60 R15
Tyre dimensions rear	165/65 R14	165/60 R15
Wheel size front	4.5J x 14	4.5J x 15
Wheel size rear	4.5J x 14	4.5J x 15
Brake dimensions front	247x20	247x20
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/10.2	9.6/10.2

Overall length [mm]	3455	3455
Overall width without/including mirrors [mm]	1615/-	1615/-
Overall height [mm]	1460	1460
Wheelbase [mm]	2340	2340
Front wheel track [mm]	1425	1430
Rear wheel track [mm]	1420	1420
Forward overhang [mm]	675	675
Rear overhang [mm]	440	440
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Toyota Aygo AB40 2015 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
