Basic information Technical Specifications Gallery

Toyota Avensis

Date of manufacture

6/2015 – 2018 (Sedan)

6/2015 – 2018 (Estate)

Platform

Toyota New MC platform

Manufacturing locations

Burnaston, United Kingdom

Designer

Car body style

Sedan

after upgrade (facelift) (II.)

Date of manufacture

6/2015 – 2018

Internal designation

T270

Engine size

Petrol

Diesel

Estate (Touring Sports)

after upgrade (facelift) (II.)

Date of manufacture

6/2015 – 2018

Internal designation

T270

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Sedan

	1.6 Valvematic	1.8 Valvematic	1.8 Valvematic	2.0 Valvematic	1.6 D-4D	2.0 D-4D
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1598	1798	1798	1987	1598	1995
Maximum output / speed [kW/min-1]	97/6400	108/6400	108/6400	112/6200	82/4000	105/4000
Maximum torque [Nm/min-1]	160/4400	180/4000	180/4000	196/4000	270/1750-2250	320/1750-2250
Bore and stroke [mm x mm]	80,5 x 78,5	80,5 x 88,3	80,5 x 88,3	80,5 x 97,6	78,0 x 83,6	84,0 x 90,0
Compression ratio	10,7:1	10,5:1	10,5:1	10,0:1	16,5:1	16,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear manual	1 gear automatic	1 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	-	automatic gearbox Multidrive S with one variable ratio	automatic gearbox Multidrive S with one variable ratio	-	-

Top speed [km/h]	200	200	200	205	185	200
Acceleration 0–100 km/h [s]	10.4	9.4	10.4	10.0	11.4	9.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	8.0	8.1	8.1	8.4	5.1	5.7
Out of town [l]	5.1	4.9	4.9	5.0	3.6	3.8
Combined [l]	6.1	6.0	6.1	6.2	4.2	4.5
CO2 emissions [g/km]	142	139	138	144	108	119

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1355-1415	1365-1440	1385-1460	1420-1485	1485-1565	1460-1535
Overall weight [kg]	1970	2000	2020	2050	2040	2100
Maximum trailer weight unbraked/braked [kg]	500/1400	500/1500	500/1600	500/1800	500/1600	500/1800
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	75	75	75	75	75	75
Maximum load on roof/carrier [kg]	78/-	78/-	78/-	78/-	78/-	78/-

Boot volume [l]	509	509	509	509	509	509
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	960	960	960	960	960	960
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-/1470	-/1470	-/1470	-/1470	-/1470	-/1470
Boot height to headliner/ceiling [mm]	-/530	-/530	-/530	-/530	-/530	-/530
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	60	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.28	0.28	0.28	0.28	0.28	0.28
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Tyre dimensions front	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Tyre dimensions rear	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Wheel size front	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Wheel size rear	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-/10.8	-/10.8	-/10.8	-/10.8	-/10.8	-/10.8

Overall length [mm]	4750	4750	4750	4750	4750	4750
Overall width without/including mirrors [mm]	1810/-	1810/-	1810/-	1810/-	1810/-	1810/-
Overall height [mm]	1480	1480	1480	1480	1480	1480
Wheelbase [mm]	2700	2700	2700	2700	2700	2700
Front wheel track [mm]	1550	1550	1550	1550	1550	1550
Rear wheel track [mm]	1540	1540	1540	1540	1540	1540
Forward overhang [mm]	1015	1015	1015	1015	1015	1015
Rear overhang [mm]	1034	1034	1034	1034	1034	1034
Clearance [mm]	140	140	140	140	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Estate (Touring Sports)

	1.6 Valvematic	1.8 Valvematic	1.8 Valvematic	2.0 Valvematic	1.6 D-4D	2.0 D-4D
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1598	1798	1798	1987	1598	1995
Maximum output / speed [kW/min-1]	97/6400	108/6400	108/6400	112/6200	82/4000	105/4000
Maximum torque [Nm/min-1]	160/4400	180/4000	180/4000	196/4000	270/1750-2250	320/1750-2250
Bore and stroke [mm x mm]	80,5 x 78,5	80,5 x 88,3	80,5 x 88,3	80,5 x 97,6	78,0 x 83,6	84,0 x 90,0
Compression ratio	10,7:1	10,5:1	10,5:1	10,0:1	16,5:1	16,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	variable timing of intake and exhaust valves variable lift of intake valves Valvematic	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter DPF start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear manual	1 gear automatic	1 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	-	automatic gearbox Multidrive S with one variable ratio	automatic gearbox Multidrive S with one variable ratio	-	-

Top speed [km/h]	195	200	200	200	185	200
Acceleration 0–100 km/h [s]	10.6	9.7	10.7	10.3	11.7	9.8
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	8.0	8.1	8.3	8.7	5.1	5.7
Out of town [l]	5.1	4.9	4.8	5.1	3.7	4.0
Combined [l]	6.2	6.1	6.0	6.4	4.2	4.6
CO2 emissions [g/km]	143	140	142	148	109	120

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1385-1455	1395-1510	1415-1530	1450-1550	1485-1565	1490-1600
Overall weight [kg]	1970	2000	2020	2050	2040	2100
Maximum trailer weight unbraked/braked [kg]	500/1400	500/1500	500/1600	500/1800	500/1600	500/1800
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	75	75	75	75	75	75
Maximum load on roof/carrier [kg]	103/-	103/-	103/-	103/-	103/-	103/-

Boot volume [l]	543	543	543	543	543	543
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1690	-/1690	-/1690	-/1690	-/1690	-/1690
Boot length [mm]	1105	1105	1105	1105	1105	1105
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-/1550	-/1550	-/1550	-/1550	-/1550	-/1550
Boot height to headliner/ceiling [mm]	-/765	-/765	-/765	-/765	-/765	-/765
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	60	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.29	0.29	0.29	0.29	0.29	0.29
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Tyre dimensions front	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Tyre dimensions rear	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Wheel size front	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Wheel size rear	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-/10.8	-/10.8	-/10.8	-/10.8	-/10.8	-/10.8

Overall length [mm]	4820	4820	4820	4820	4820	4820
Overall width without/including mirrors [mm]	1810/-	1810/-	1810/-	1810/-	1810/-	1810/-
Overall height [mm]	1480	1480	1480	1480	1480	1480
Wheelbase [mm]	2700	2700	2700	2700	2700	2700
Front wheel track [mm]	1550	1550	1550	1550	1550	1550
Rear wheel track [mm]	1540	1540	1540	1540	1540	1540
Forward overhang [mm]	1015	1015	1015	1015	1015	1015
Rear overhang [mm]	1105	1105	1105	1105	1105	1105
Clearance [mm]	140	140	140	140	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Toyota Avensis T270 Touring Sports facelift 2015 wagon

Toyota Avensis T270 Touring Sports facelift 2016 wagon

Toyota Avensis T270 Touring Sports facelift 2017 wagon

Toyota Avensis T270 Touring Sports facelift 2018 wagon

Toyota Avensis T270 Touring Sports facelift 2015 rear folding seats

Toyota Avensis T270 facelift 2015 interior

Toyota Avensis T270 facelift 2016 front seats

Toyota Avensis T270 facelift 2017 rear seats

Toyota Avensis T270 facelift 2018 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
