Suzuki Vitara

Date of manufacture

2018 – to this day (Small SUV)

Platform

Manufacturing locations

Esztergom, Hungary

Chongqing, People's Republic of China

Designer

Kosei Iwasaki

Toshinobu Ishida

Kanae Ito

Kazuhisa Takayanagi

Yoshitaka Uchiyama

Car body style

Small SUV

after upgrade (facelift)

Date of manufacture

2018 – to this day

Internal designation

Engine size

1.0 Boosterjet

1.4 Boosterjet Hybrid

1.4 Boosterjet

Euro NCAP

Test year 2015

pre-facelift version (2015)

Technical data

Small SUV

	1.0 Boosterjet	1.0 Boosterjet	1.0 Boosterjet	1.0 Boosterjet	1.4 Boosterjet Hybrid	1.4 Boosterjet Hybrid
Date of sale	from to 2020	from to 2020	from to 2020	from to 2020	from 2020 to	from 2020 to
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	4/16	4/16
Engine displacement [cm³]	998	998	998	998	1373	1373
Maximum output / speed [kW/min-1]	82/5500	82/5500	82/5500	82/5500	95/5500	95/5500
Maximum torque [Nm/min-1]	170/2000-3500	160/1800-4000	170/2000-3500	160/1800-4000	235/2000-3000	235/2000-3000
Bore and stroke [mm x mm]	73,0 x 79,5	73,0 x 79,5	73,0 x 79,5	73,0 x 79,5	73,0 x 82,0	73,0 x 82,0
Compression ratio	10,0:1	10,0:1	10,0:1	10,0:1	10.9:1	10.9:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	Mild Hybrid SHVS direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	Mild Hybrid SHVS direct injection turbo-supercharged variable valve timing sacích VVT start&stop system

Drive axle	Front	Front	4x4	4x4	Front	Front
Gearbox	5 gear manual	6 gear automatic	5 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	-	automatic gearbox	automatically controlled all-wheel drive AllGrip	automatically controlled all-wheel drive AllGrip six-speed automatic gearbox	-	six-speed automatic gearbox

Top speed [km/h]	180	170	175	165	190	190
Acceleration 0–100 km/h [s]	11.5	12.5	12.0	13.0	9.5	9.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.2	6.6	6.6	7.0	-	-
Out of town [l]	4.8	5.1	5.2	5.3	-	-
Combined [l]	5.3	5.7	5.7	6.0	-	-
CO2 emissions [g/km]	121	129	129	135	-	-

Low speed [l]	-	-	-	-	6.0	6.9
Medium speed [l]	-	-	-	-	4.8	5.3
High speed [l]	-	-	-	-	4.7	4.9
Extra high speed [l]	-	-	-	-	6.1	6.2
Combined speed [l]	-	-	-	-	5.4	5.7
CO2 emissions [g/km]	-	-	-	-	121	129

Emission standard	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	-	-	-	-	48	48
Battery type and capacity	-	-	-	-	Lithium-Ionen-Akkumulator, 8 A⋅h	Lithium-Ionen-Akkumulator, 8 A⋅h
Range with fully charged battery [km]	-	-	-	-	-	-
Charging time	-	-	-	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1121-1160	1140-1205	1194-1230	11215	1240	1275
Overall weight [kg]	1730	1730	1730	1730	1770	1710
Maximum trailer weight unbraked/braked [kg]	400/1200	400/1200	400/1200	400/1200	600/1500	600/1500
Maximum front/rear axle load [kg]	-	-	-	-	1040/920	1040/920
Maximum vertical load on the tow bar [kg]	75	75	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	375	375	375	375	375	375
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	710/1120	710/1120	710/1120	710/1120	710/1120	710/1120
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	47	47	47	47	47	47
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	215/60 R16	215/55 R17	215/55 R17	215/55 R17	215/60 R16 95 H	215/55 R17 94 V
Tyre dimensions rear	215/60 R16	215/55 R17	215/55 R17	215/55 R17	215/60 R16 95 H	215/55 R17 94 V
Wheel size front	6.5J x 16	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 16	6.5J x 17
Wheel size rear	6.5J x 16	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 16	6.5J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4175	4175	4175	4175	4175	4175
Overall width without/including mirrors [mm]	1775/-	1775/-	1775/-	1775/-	1775/-	1775/-
Overall height [mm]	1610	1610	1610	1610	1610	1610
Wheelbase [mm]	2500	2500	2500	2500	2500	2500
Front wheel track [mm]	1535	1535	1535	1535	1535	1535
Rear wheel track [mm]	1505	1505	1505	1505	1505	1505
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	185	185	185	185	185	185
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Rating		-	-	-	-	-
Clean Air Index	3.3/10	-	-	-	-	-
Energy Efficiency Index	4.9/10	-	-	-	-	-
GHG index	4.2/10	-	-	-	-	-

	1.4 Boosterjet Hybrid	1.4 Boosterjet Hybrid	1.4 Boosterjet	1.4 Boosterjet	1.4 Boosterjet	1.4 Boosterjet
Date of sale	from 2020 to	from 2020 to	from to 2020	from to 2020	from to 2020	from to 2020
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1373	1373	1373	1373	1373	1373
Maximum output / speed [kW/min-1]	95/5500	95/5500	103/5500	103/5500	103/5500	103/5500
Maximum torque [Nm/min-1]	235/2000-3000	235/2000-3000	220/1500-4000	220/1500-4000	220/1500-4000	220/1500-4000
Bore and stroke [mm x mm]	73,0 x 82,0	73,0 x 82,0	73,0 x 82,0	73,0 x 82,0	73,0 x 82,0	73,0 x 82,0
Compression ratio	10.9:1	10.9:1	9,9:1	9,9:1	9,9:1	9,9:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	Mild Hybrid SHVS direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	Mild Hybrid SHVS direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system

Drive axle	4x4	4x4	Front	Front	4x4	4x4
Gearbox	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	automatically controlled all-wheel drive AllGrip	automatically controlled all-wheel drive AllGrip automatic gearbox	-	six-speed automatic gearbox	automatically controlled all-wheel drive AllGrip	automatically controlled all-wheel drive AllGrip automatic gearbox

Top speed [km/h]	190	190	200	200	200	200
Acceleration 0–100 km/h [s]	10.2	10.2	9.5	9.5	10.2	10.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	-	-	6.9	7.1	7.0	7.5
Out of town [l]	-	-	5.2-5.1	5.1	5.5	5.6
Combined [l]	-	-	5.8	5.9	6.1	6.3
CO2 emissions [g/km]	-	-	132-131	133	139	143

Low speed [l]	6.6	7.6	-	-	-	-
Medium speed [l]	5.4	5.9	-	-	-	-
High speed [l]	5.1	5.4	-	-	-	-
Extra high speed [l]	6.5	6.8	-	-	-	-
Combined speed [l]	5.9	6.3	-	-	-	-
CO2 emissions [g/km]	132	142	-	-	-	-

Emission standard	Euro 6d	Euro 6d	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	48	48	-	-	-	-
Battery type and capacity	Lithium-Ionen-Akkumulator, 8 A⋅h	Lithium-Ionen-Akkumulator, 8 A⋅h	-	-	-	-
Range with fully charged battery [km]	-	-	-	-	-	-
Charging time	-	-	-	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1320	1345	1195	1220	1205-1270	1230-1295
Overall weight [kg]	1770	1780	1730	1730	1730	1730
Maximum trailer weight unbraked/braked [kg]	600/1500	600/1500	400/1200	400/1200	400/1200	400/1200
Maximum front/rear axle load [kg]	1040/920	1040/920	-	-	-	-
Maximum vertical load on the tow bar [kg]	75	75	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	375	375	375	375	375	375
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	710/1120	710/1120	710/1120	710/1120	710/1120	710/1120
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	47	47	47	47	47	47
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	215/55 R17 94 V	215/55 R17 94 V	215/55 R17	215/55 R17	215/55 R17	215/55 R17
Tyre dimensions rear	215/55 R17 94 V	215/55 R17 94 V	215/55 R17	215/55 R17	215/55 R17	215/55 R17
Wheel size front	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17
Wheel size rear	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4175	4175	4175	4175	4175	4175
Overall width without/including mirrors [mm]	1775/-	1775/-	1775/-	1775/-	1775/-	1775/-
Overall height [mm]	1610	1610	1610	1610	1610	1610
Wheelbase [mm]	2500	2500	2500	2500	2500	2500
Front wheel track [mm]	1535	1535	1535	1535	1535	1535
Rear wheel track [mm]	1505	1505	1505	1505	1505	1505
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	185	185	185	185	185	185
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Suzuki Vitara LY facelift 2019 infotainment

Suzuki Vitara LY facelift 2018 front seats

Suzuki Vitara LY facelift 2019 rear seats

Suzuki Vitara LY facelift 2021 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
