Suzuki Swift

Date of manufacture

9/2010 – 2017 (Three-door hatchback)

9/2010 – 2017 (Five-door hatchback)

Platform

Manufacturing locations

Esztergom, Hungary

Makinohara, Japan

Manesar, India

Rayong, Thailand

Designer

Car body style

Three-door hatchback

Date of manufacture

9/2010 – 2017

Internal designation

AZG

Engine size

1.2 VVT

1.6 VVT Sport

Five-door hatchback

Date of manufacture

9/2010 – 2017

Internal designation

AZG

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Three-door hatchback

	1.2 VVT	1.6 VVT Sport
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	1242	1586
Maximum output / speed [kW/min-1]	69/6000	100/6900
Maximum torque [Nm/min-1]	118/4800	160/4400
Bore and stroke [mm x mm]	73,0 x 74,2	78,0 x 83,0
Compression ratio	11,0:1	11,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake and exhaust valves Dual VVT	variable valve timing VVT

Drive axle	Front	Front
Gearbox	5 gear manual	6 gear manual
Drive specifications	-	-

Top speed [km/h]	165	195
Acceleration 0–100 km/h [s]	12.3	8.7
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	6.1	8.4
Out of town [l]	4.4	5.2
Combined [l]	5.0	6.4
CO2 emissions [g/km]	116	147

Emission standard	EU5-EU6	EU5-EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1020	1120
Overall weight [kg]	1480	1480
Maximum trailer weight unbraked/braked [kg]	400/1000	400/1000
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	211	211
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/892	-/892
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	3
Number of seats	4	4
Fuel tank volume [l]	42	42
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar
Tyre dimensions front	175/65 R15	195/45 R17
Tyre dimensions rear	175/65 R15	195/45 R17
Wheel size front	5.0J x 15	6.5J x 17
Wheel size rear	5.0J x 15	6.5J x 17
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/-	9.6/-

Overall length [mm]	3850	3890
Overall width without/including mirrors [mm]	1695/-	1695/-
Overall height [mm]	1510	1510
Wheelbase [mm]	2430	2430
Front wheel track [mm]	1490	1470
Rear wheel track [mm]	1495	1475
Forward overhang [mm]	820	820
Rear overhang [mm]	600	600
Clearance [mm]	140	140
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Five-door hatchback

	1.2 Dualjet ECO+	1.2 VVT	1.2 VVT	1.2 VVT	1.6 VVT Sport	1.3 DDiS
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1242	1242	1242	1242	1586	1248
Maximum output / speed [kW/min-1]	66/6000	69/6000	69/6000	69/6000	100/6900	55/4000
Maximum torque [Nm/min-1]	120/4400	118/4800	118/4800	118/4800	160/4400	190/1750
Bore and stroke [mm x mm]	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2	78,0 x 83,0	69,6 x 82,0
Compression ratio	12,0:1	11,0:1	11,0:1	11,0:1	11,0:1	16,8:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves start&stop system	variable timing of intake and exhaust valves Dual VVT	variable timing of intake and exhaust valves Dual VVT	variable timing of intake and exhaust valves Dual VVT	variable valve timing VVT	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front	4x4	Front	Front
Gearbox	5 gear manual	5 gear manual	4 gear automatic	5 gear manual	6 gear manual	5 gear manual
Drive specifications	-	-	automatic gearbox	electronically controlled all-wheel drive	-	-

Top speed [km/h]	165	165	160	165	195	165
Acceleration 0–100 km/h [s]	12.3	12.3	13.5	13.4	8.7	12.7
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	4.9	6.1	6.6-6.8	6.5	8.4	4.7-5.1
Out of town [l]	3.9	4.4	4.8-4.9	4.9	5.2	3.4-3.9
Combined [l]	4.3	5.0	5.5-5.6	5.5	6.4	3.9-4.2
CO2 emissions [g/km]	99	116	126-128	126	147	101-109

Emission standard	EU6	EU5-EU6	EU5-EU6	EU5-EU6	EU5-EU6	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1045	1035	1065	1110	1135	1140
Overall weight [kg]	1480	1480	1480	1560	1480	1560
Maximum trailer weight unbraked/braked [kg]	400/1000	400/1000	200/200	400/1000	400/1000	400/900
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	211	211	211	211	211	211
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/902	-/902	-/902	-/900	-/902	-/902
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	42	42	42	40	42	42
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	185/55 R16	175/65 R15	175/65 R15	175/65 R15	195/45 R17	185/55 R16
Tyre dimensions rear	185/55 R16	175/65 R15	175/65 R15	175/65 R15	195/45 R17	185/55 R16
Wheel size front	6.0J x 16	5.0J x 15	5.0J x 15	5.0J x 15	6.5J x 17	6.0J x 16
Wheel size rear	6.0J x 16	5.0J x 15	5.0J x 15	5.0J x 15	6.5J x 17	6.0J x 16
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	9.6/-	9.6/-	9.6/-	9.6/-	10.4/-

Overall length [mm]	3850	3850	3850	3850	3890	3850
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1500	1510	1510	1535	1510	1510
Wheelbase [mm]	2430	2430	2430	2430	2430	2430
Front wheel track [mm]	1480	1490	1490	1490	1470	1480
Rear wheel track [mm]	1485	1495	1495	1495	1475	1485
Forward overhang [mm]	820	820	820	820	820	820
Rear overhang [mm]	600	600	600	600	600	600
Clearance [mm]	130	140	140	160	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Suzuki Swift AZG 2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
