	1.3 16V	1.3 16V	1.5 VVT	1.5 VVT	1.6 VVT Sport	1.25 DDiS
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1328	1328	1490	1490	1586	1248
Maximum output / speed [kW/min-1]	68/5800	68/5800	75/5900	75/5900	92/6800	51/4000
Maximum torque [Nm/min-1]	116/4200	116/4200	133/4100	133/4100	148/4800	170/2000
Bore and stroke [mm x mm]	78,0 x 69,5	78,0 x 69,5	78,0 x 78,0	78,0 x 78,0	78,0 x 83,0	69,6 x 82,0
Compression ratio	9,5:1	9,5:1	9,5:1	9,5:1	9,5:1	17,6:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	-	variable timing of intake valves	variable timing of intake valves	variable timing of intake valves	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear robotic manual	5 gear manual	4 gear automatic	5 gear manual	5 gear manual
Drive specifications	-	robotic manual gearbox MTA	-	automatic gearbox	-	-

Top speed [km/h]	175	175	185	180	200	165
Acceleration 0–100 km/h [s]	11.0	12.5	10.0	11.7	8.9	14.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	7.4	7.2	7.9	8.7	8.7	5.6
Out of town [l]	4.9	5.0	5.0	5.2	6.0	3.9
Combined [l]	5.8	5.8	6.1	6.5	7.0	4.5
CO2 emissions [g/km]	140	139	143	153	165	119

Emission standard	EU4	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	970	980	980	1000	1030	1045
Overall weight [kg]	1485	1485	1485	1485	1485	1525
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	201	201	201	201	201	201
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/494	-/494	-/494	-/494	-/494	-/494
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	3	3	3	3	3	3
Number of seats	4	4	4	4	4	4
Fuel tank volume [l]	45	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/70 R14	165/70 R14	185/60 R15	185/60 R15	195/45 R17	165/70 R14
Tyre dimensions rear	165/70 R14	165/70 R14	185/60 R15	185/60 R15	195/45 R17	165/70 R14
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0

Overall length [mm]	3760	3760	3760	3760	3760	3760
Overall width without/including mirrors [mm]	1690/-	1690/-	1690/-	1690/-	1690/-	1690/-
Overall height [mm]	1500	1500	1500	1500	1500	1500
Wheelbase [mm]	2380	2380	2380	2380	2380	2380
Front wheel track [mm]	1470	1470	1470	1470	1460	1470
Rear wheel track [mm]	1480	1480	1480	1480	1470	1480
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	140	140	140	140	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Five-door hatchback

	1.3 16V	1.3 16V	1.3 16V	1.5 VVT	1.5 VVT	1.25 DDiS
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1328	1328	1328	1490	1490	1248
Maximum output / speed [kW/min-1]	68/5800	68/5800	68/5800	75/5900	75/5900	51/4000
Maximum torque [Nm/min-1]	116/4200	116/4200	116/4200	133/4100	133/4100	170/2000
Bore and stroke [mm x mm]	78,0 x 69,5	78,0 x 69,5	78,0 x 69,5	78,0 x 78,0	78,0 x 78,0	69,6 x 82,0
Compression ratio	9,5:1	9,5:1	9,5:1	9,5:1	9,5:1	17,6:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	-	-	variable timing of intake valves	variable timing of intake valves	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	4x4	Front	Front	Front
Gearbox	5 gear manual	5 gear robotic manual	5 gear manual	5 gear manual	4 gear automatic	5 gear manual
Drive specifications	-	robotic manual gearbox MTA	electronically controlled all-wheel drive	-	automatic gearbox	-

Top speed [km/h]	175	175	167	185	180	165
Acceleration 0–100 km/h [s]	11.0	12.5	12.8	10.0	11.7	14.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	7.4	7.2	7.9	7.9	8.7	5.6
Out of town [l]	4.9	5.0	5.3	5.0	5.2	3.9
Combined [l]	5.8	5.8	6.2	6.1	6.5	4.5
CO2 emissions [g/km]	140	139	147	143	153	119

Emission standard	EU4	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	980	1000	1135	1000	1020	1065
Overall weight [kg]	1485	1485	1485	1485	1485	1525
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	201	201	201	201	201	201
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/494	-/494	-/494	-/494	-/494	-/494
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	45	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/70 R14	165/70 R14	165/70 R14	185/60 R15	185/60 R15	165/70 R14
Tyre dimensions rear	165/70 R14	165/70 R14	165/70 R14	185/60 R15	185/60 R15	165/70 R14
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0	9.4/10.0

Overall length [mm]	3760	3760	3760	3760	3760	3760
Overall width without/including mirrors [mm]	1690/-	1690/-	1690/-	1690/-	1690/-	1690/-
Overall height [mm]	1500	1500	1535	1500	1500	1500
Wheelbase [mm]	2380	2380	2380	2380	2380	2380
Front wheel track [mm]	1470	1470	1470	1470	1470	1470
Rear wheel track [mm]	1480	1480	1480	1480	1480	1480
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	140	140	145	140	140	140
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Suzuki Swift facelift RS 2007 front seats

Suzuki Swift Sport facelift RS 2007 interior
