Suzuki Jimny

Date of manufacture

2018 – to this day (Small SUV)

Platform

Manufacturing locations

Kosai, Japan

Gurgaon, India

Designer

Hiroyuki Yonezawa

Car body style

Small SUV

Date of manufacture

2018 – to this day

Internal designation

Engine size

1.5

Euro NCAP

Technical data

Small SUV

	1.5	1.5
Date of sale	-	from to 2020
Engine type	Petrol	Petrol
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	1462	1462
Maximum output / speed [kW/min-1]	75/6000	75/6000
Maximum torque [Nm/min-1]	130/4000	130/4000
Bore and stroke [mm x mm]	74.0 x 85.0	74.0 x 85.0
Compression ratio	10.0:1	10.0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable valve timing VVT	variable valve timing VVT

Drive axle	4x4	4x4
Gearbox	5 gear manual	4 gear automatic
Drive specifications	permanent rear axle drive AllGrip with connectable front axle	permanent rear axle drive AllGrip with connectable front axle four-speed automatic gearbox

Top speed [km/h]	145	140
Acceleration 0–100 km/h [s]	-	-
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	7.7	8.4
Out of town [l]	6.2	6.9
Combined [l]	6.8	7.5
CO2 emissions [g/km]	154	170

Low speed [l]	8.1	-
Medium speed [l]	6.7	-
High speed [l]	6.8	-
Extra high speed [l]	8.9	-
Combined speed [l]	7.7	-
CO2 emissions [g/km]	173	-

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1165	1185
Overall weight [kg]	1435	1435
Maximum trailer weight unbraked/braked [kg]	350/1300	350/1300
Maximum front/rear axle load [kg]	680/880	680/880
Maximum vertical load on the tow bar [kg]	75/-	75/-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	85	85
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	377/830	377/830
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	3
Number of seats	2-4	4
Fuel tank volume [l]	40	40
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	rigid	rigid
Rear suspension	rigid	rigid
Tyre dimensions front	195/80 R15 96S	195/80 R15 96S
Tyre dimensions rear	195/80 R15 96S	195/80 R15 96S
Wheel size front	5,5J x 15	5,5J x 15
Wheel size rear	5,5J x 15	5,5J x 15
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.8/-	9.8/-

Overall length [mm]	3645	3645
Overall width without/including mirrors [mm]	1645/-	1645/-
Overall height [mm]	1705	1705
Wheelbase [mm]	2250	2250
Front wheel track [mm]	1395	1395
Rear wheel track [mm]	1405	1405
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	210	210
Wading depth [mm]	-	-
Approach angle front [°]	37.0	37.0
Approach angle rear [°]	49.0	49.0
Transition angle [°]	28.0	28.0
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
