Suzuki Jimny

Date of manufacture

2006 – 2012 (SUV)

Platform

Manufacturing locations

Linares, Spain

Iwata, Japan

Designer

Car body style

SUV

after upgrade (facelift) (I.)

Date of manufacture

2006 – 2012

Internal designation

Engine size

Petrol

1.3 VVT

Diesel

1.5 DDiS

Technical data

SUV

	1.3 VVT	1.3 VVT	1.5 DDiS
Date of sale	-	-	-
Engine type	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/8
Engine displacement [cm³]	1328	1328	1461
Maximum output / speed [kW/min-1]	62,5/6000	62,5/6000	63/3750
Maximum torque [Nm/min-1]	110/4100	110/4100	200/1750
Bore and stroke [mm x mm]	78,0 x 69,5	78,0 x 69,5	76,0 x 80,5
Compression ratio	9,5:1	9,5:1	18,0:1
Oil volume [l]	-	-	-
Coolant volume [l]	-	-	-
Technical specifications	variable valve timing VVT	variable valve timing VVT	direct injection Common Rail turbo-supercharged

Drive axle	4x4	4x4	4x4
Gearbox	5 gear manual	4 gear automatic	5 gear manual
Drive specifications	connectable all-wheel drive Drive Action	connectable all-wheel drive Drive Action automatic gearbox	connectable all-wheel drive Drive Action

Top speed [km/h]	140	135	145
Acceleration 0–100 km/h [s]	14.1	17.2	17.0
Acceleration 0–80 km/h [s]	-	-	-
Acceleration 80–120 km/h [s]	-	-	-

City [l]	8.9-9.1	9.9	7.0
Out of town [l]	6.0-6.1	6.6	5.6
Combined [l]	7.1-7.2	7.8	6.1
CO2 emissions [g/km]	162-171	184	162

Emission standard	EU4-EU5	EU4	EU4
Standard for fuel consumption measurement	-	-	-
Energy class	-	-	-
Stationary vehicle noise [dB]	-	-	-
Driving noise [dB]	-	-	-

Standby weight [kg]	1060	1075	1155
Overall weight [kg]	1420	1420	1500
Maximum trailer weight unbraked/braked [kg]	350/1300	-	-
Maximum front/rear axle load [kg]	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-
Maximum load on roof/carrier [kg]	-	-	-

Boot volume [l]	133	133	133
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/816	-/816	-/816
Boot length [mm]	-	-	-
Boot length with rear seats folded [mm]	-	-	-
Boot width between wheels/max [mm]	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-
Loading edge height [mm]	-	-	-
Height of the open boot door [mm]	-	-	-
Boot opening height [mm]	-	-	-
Boot opening width min/max [mm]	-	-	-

Number of doors	3	3	3
Number of seats	4	4	4
Fuel tank volume [l]	40	40	40
AdBlue tank volume [l]	-	-	-
Air resistance [Cd]	-	-	-
Front suspension	rigid	rigid	rigid
Rear suspension	rigid	rigid	rigid
Tyre dimensions front	205/70 R15	205/70 R15	205/70 R15
Tyre dimensions rear	205/70 R15	205/70 R15	205/70 R15
Wheel size front	-	-	-
Wheel size rear	-	-	-
Brake dimensions front	-	-	-
Brake dimensions rear	-	-	-
Steering	Hydraulic power steering	Hydraulic power steering	Hydraulic power steering
Number of steering wheel turns	-	-	-
Turning diameter track/circumference [m]	9.8/-	9.8/-	9.8/-

Overall length [mm]	3645	3645	3645
Overall width without/including mirrors [mm]	1600/-	1600/-	1600/-
Overall height [mm]	1705	1705	1705
Wheelbase [mm]	2250	2250	2250
Front wheel track [mm]	1355	1355	1355
Rear wheel track [mm]	1365	1365	1365
Forward overhang [mm]	-	-	-
Rear overhang [mm]	-	-	-
Clearance [mm]	190	190	190
Wading depth [mm]	-	-	-
Approach angle front [°]	37	37	37
Approach angle rear [°]	46	46	46
Transition angle [°]	31	31	31
Climbing rate [°]	-	-	-
Maximum side tilt [°]	-	-	-

Headroom front [mm]	-	-	-
Headroom rear [mm]	-	-	-
Front elbow/shoulder width [mm]	-	-	-
Rear elbow/shoulder width [mm]	-	-	-
Legroom front knees/total [mm]	-	-	-
Legroom rear knees/total [mm]	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
