Suzuki Ignis

Date of manufacture

2016 – 2019 (SUV)

Platform

HEARTECT

Manufacturing locations

Makinohara, Japan

Designer

Yoshio Takeuchi

Car body style

SUV

Date of manufacture

2016 – 2019

Internal designation

Engine size

1.2 Dualjet

1.2 Dualjet SHVS

Euro NCAP

Technical data

SUV

	1.2 Dualjet	1.2 Dualjet	1.2 Dualjet SHVS	1.2 Dualjet SHVS
Date of sale	-	-	from 2017 to	from 2017 to
Engine type	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1242	1242	1242	1242
Maximum output / speed [kW/min-1]	66/6000	66/6000	66/6000	66/6000
Maximum torque [Nm/min-1]	120/4400	120/4400	120/4400	120/4400
Bore and stroke [mm x mm]	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2
Compression ratio	12,5:1	12,5:1	12,5:1	12,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves	multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves	Mild Hybrid SHVS multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves start&stop system	Mild Hybrid SHVS multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves start&stop system

Drive axle	Front	4x4	Front	4x4
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual
Drive specifications	-	automatically controlled all-wheel drive AllGrip AUTO	-	automatically controlled all-wheel drive AllGrip AUTO

Top speed [km/h]	170	165	170	165
Acceleration 0–100 km/h [s]	12.2	11.9	11.8	11.5
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5.7-5.5	6.2-5.9	4.7	5.0
Out of town [l]	4.2-4.1	4.6-4.5	4.1	4.4
Combined [l]	4.7-4.6	5.2-5.0	4.3	4.6
CO2 emissions [g/km]	125-104	135-114	98	105

Emission standard	EU6	EU6	EU6 - Euro 6d-TEMP	EU6 - Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

System voltage [V]	-	-	-	-
Battery type and capacity	-	-	Lithium-Ionen-Akkumulator, A⋅h	Lithium-Ionen-Akkumulator, A⋅h
Range with fully charged battery [km]	-	-	-	-
Charging time	-	-	-	-
Number of modules/cells	-	-	-	-
Battery weight [kg]	-	-	-	-
Charger	-	-	-	-

Standby weight [kg]	822-885	897-945	867	917
Overall weight [kg]	1330	1330	1330	1330
Maximum trailer weight unbraked/braked [kg]	400/1000	400/1000	400/1000	400/1000
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	50	50	50	50
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	260	204	260	204
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1097	-/1056	-/1097	-/1056
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	4-5	4	4-5	4
Fuel tank volume [l]	32	30	32	30
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	rigid	torsion bar	rigid
Tyre dimensions front	175/65 R15 84H	175/60 R16 82H	175/65 R15 84H	175/60 R16 82H
Tyre dimensions rear	175/65 R15 84H	175/60 R16 82H	175/65 R15 84H	175/60 R16 82H
Wheel size front	5.0J x 15	5.0J x 16	5.0J x 15	5.0J x 16
Wheel size rear	5.0J x 15	5.0J x 16	5.0J x 15	5.0J x 16
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	9.4/-	9.4/-	9.4/-	9.4/-

Overall length [mm]	3700	3700	3700	3700
Overall width without/including mirrors [mm]	1660/-	1690/-	1660/-	1690/-
Overall height [mm]	1595	1595	1595	1595
Wheelbase [mm]	2435	2435	2435	2435
Front wheel track [mm]	1460	1460	1460	1460
Rear wheel track [mm]	1470	1460	1470	1460
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	180	180	180	180
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
