	1.6 VVT	2.4 VVT	2.4 VVT	1.9 DDiS
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/8
Engine displacement [cm³]	1586	2393	2393	1870
Maximum output / speed [kW/min-1]	78/5900	124/6000	124/6000	95/4000
Maximum torque [Nm/min-1]	145/4100	227/3800	227/3800	300/1750-2500
Bore and stroke [mm x mm]	78,0 x 83,0	92,0 x 90,0	92,0 x 90,0	80,0 x 93,0
Compression ratio	11,0:1	10,0:1	10,0:1	16,6:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable timing of intake valves VVT	variable timing of intake valves VVT	variable timing of intake valves VVT	direct injection Common Rail turbo-supercharged particulate filter

Drive axle	4x4	4x4	4x4	4x4
Gearbox	5 gear manual	5 gear manual	4 gear automatic	5 gear manual
Drive specifications	permanent all-wheel drive 4H	automatically controlled all-wheel drive 4‐mode	automatically controlled all-wheel drive 4‐mode automatic gearbox	automatically controlled all-wheel drive 4‐mode

Top speed [km/h]	160	185	175	170
Acceleration 0–100 km/h [s]	14.4	11.7	12.0	13.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	10.1	11.2	12.1	7.8
Out of town [l]	7.1	7.5	8.1	6.0
Combined [l]	8.2	8.8	9.6	6.6
CO2 emissions [g/km]	189	204	221	174

Emission standard	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1407-1470	1569-1643	1584-1658	1654-1728
Overall weight [kg]	1830	2100	2100	2170
Maximum trailer weight unbraked/braked [kg]	550/1600	750/1850	750/1700	750/2000
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	184	398	398	398
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/964	-/1386	-/1386	-/1386
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	3	5	5	5
Number of seats	4	5	5	5
Fuel tank volume [l]	55	66	66	66
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	225/70 R16	225/65 R17	225/65 R17	225/65 R17
Tyre dimensions rear	225/70 R16	225/65 R17	225/65 R17	225/65 R17
Wheel size front	-	-	-	-
Wheel size rear	-	-	-	-
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.2/-	11.0/-	11.0/-	11.0/-

Overall length [mm]	4035	4300	4300	4300
Overall width without/including mirrors [mm]	1810/-	1810/-	1810/-	1810/-
Overall height [mm]	1695	1695	1695	1695
Wheelbase [mm]	2440	2640	2640	2640
Front wheel track [mm]	1540	1540	1540	1540
Rear wheel track [mm]	1570	1570	1570	1570
Forward overhang [mm]	-	785	785	785
Rear overhang [mm]	-	875	875	875
Clearance [mm]	200	200	200	190
Wading depth [mm]	-	-	-	-
Approach angle front [°]	29	29	29	29
Approach angle rear [°]	36	27	27	27
Transition angle [°]	20	19	19	19
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Suzuki Grand Vitara facelift JT 2013 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
