Suzuki Baleno

Date of manufacture

9/2015 – 2019 (Five-door hatchback)

Platform

Manufacturing locations

Manesar, India

Designer

Yoshio Takeuchi

Car body style

Five-door hatchback

Date of manufacture

9/2015 – 2019

Internal designation

WB/EW

Engine size

1.2 Dualjet

1.2 Dualjet SHVS

1.0 Boosterjet

Euro NCAP

Technical data

Five-door hatchback

	1.2 Dualjet	1.2 Dualjet	1.2 Dualjet SHVS	1.0 Boosterjet	1.0 Boosterjet
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	4/16	4/16	3/12	3/12
Engine displacement [cm³]	1242	1242	1242	998	998
Maximum output / speed [kW/min-1]	66/6000	66/6000	66/6000	82/5500	82/5500
Maximum torque [Nm/min-1]	120/4400	120/4400	120/4400	170/2000-3500	160/1500-4000
Bore and stroke [mm x mm]	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2	73,0 x 79,5	73,0 x 79,5
Compression ratio	12,5:1	12,5:1	12,5:1	10,0:1	10,0:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves	multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves	Mild Hybrid SHVS multipoint injection Dualjet (eight injectors) variable timing of intake and exhaust valves start&stop system brake energy recuperation	direct injection turbo-supercharged variable valve timing sacích VVT	direct injection turbo-supercharged variable valve timing sacích VVT

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	1 gear automatic	5 gear manual	5 gear manual	6 gear automatic
Drive specifications	-	automatic gearbox with one variable ratio CVT s jedním proměnným převodem	-	-	automatic gearbox

Top speed [km/h]	180	175	180	200	190
Acceleration 0–100 km/h [s]	12.3	12.3	12.3	11.4	11.0
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	5.8-5.3	5.9-5.2	4.9-4.7	6.1-5.4	6.9-6.1
Out of town [l]	4.0-3.6	4.2-3.7	4.0-3.6	4.4-3.9	4.6-3.9
Combined [l]	4.7-4.2	4.9-4.2	4.3-4.0	5.0-4.4	5.5-4.7
CO2 emissions [g/km]	107-98	111-99	99-94	114-103	124-109

Emission standard	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

System voltage [V]	-	-	-	-	-
Battery type and capacity	-	-	Lithium-Ionen-Akkumulator, 3 A⋅h	-	-
Range with fully charged battery [km]	-	-	-	-	-
Charging time	-	-	-	-	-
Number of modules/cells	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-
Charger	-	-	-	-	-

Standby weight [kg]	940-995	980-1025	990-1010	980-1025	1010-1055
Overall weight [kg]	1405	1405	1405	1430	1430
Maximum trailer weight unbraked/braked [kg]	400/1000	400/1000	400/1000	400/1000	400/1000
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	60	60	60	60	60
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	355	355	355	355	355
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1085	-/1085	-/1085	-/1085	-/1085
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	37	37	37	37	37
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	175/65 R15 84H	185/55 R16 83V	185/55 R16 83V	185/55 R16 83V	185/55 R16 83V
Tyre dimensions rear	175/65 R15 84H	185/55 R16 83V	185/55 R16 83V	185/55 R16 83V	185/55 R16 83V
Wheel size front	5.0J x 15	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Wheel size rear	5.0J x 15	6.0J x 16	6.0J x 16	6.0J x 16	6.0J x 16
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	9.8/-	10.0/-	10.0/-	10.0/-	10.0/-

Overall length [mm]	3995	3995	3995	3995	3995
Overall width without/including mirrors [mm]	1745/-	1745/-	1745/-	1745/-	1745/-
Overall height [mm]	1470	1470	1460	1470	1470
Wheelbase [mm]	2520	2520	2520	2520	2520
Front wheel track [mm]	1530	1520	1520	1520	1520
Rear wheel track [mm]	1530	1520	1520	1520	1520
Forward overhang [mm]	805	805	805	805	805
Rear overhang [mm]	670	670	670	670	670
Clearance [mm]	120	120	110	120	120
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Suzuki Baleno WB EW 2017 rear folding seats
