Subaru Impreza

Date of manufacture

2015 – 2016 (Five-door hatchback)

Platform

Manufacturing locations

Ōta, Japan

Designer

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2015 – 2016

Internal designation

Engine size

1.6

2.0

Technical data

Five-door hatchback

	1.6	1.6	2.0	2.0
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1600	1600	1995	1995
Maximum output / speed [kW/min-1]	84/5600	84/5600	110/6200	110/6200
Maximum torque [Nm/min-1]	150/4000	150/4000	196/4200	196/4200
Bore and stroke [mm x mm]	78,8 x 82,0	78,8 x 82,0	84,0x90,0	84,0x90,0
Compression ratio	10,5:1	10,5:1	10,5:1	10,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system

Drive axle	4x4	4x4	4x4	4x4
Gearbox	5 gear manual	1 gear automatic	6 gear manual	1 gear automatic
Drive specifications	all-wheel drive with inter-axle viscous coupling Symmetrical AWD reduction gearbox Dual Range	automatic gearbox with one variable ratio Lineartronic all-wheel drive Symmetrical AWD with active torque distribution system MPT	all-wheel drive with inter-axle viscous coupling Symmetrical AWD	all-wheel drive Symmetrical AWD with active torque distribution system MPT automatic gearbox with one variable ratio Lineartronic steering wheel paddles for gearbox control

Top speed [km/h]	185	179	193	193
Acceleration 0–100 km/h [s]	12.3	12.6	10.5	11.1
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.0	7.4	9.0	8.5
Out of town [l]	5.3	5.0	5.7	5.3
Combined [l]	6.2	5.9	6.9	6.5
CO2 emissions [g/km]	144	136	159	149

Emission standard	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1315	1350	1325	1365-1380
Overall weight [kg]	1850	1870	1890	1920
Maximum trailer weight unbraked/braked [kg]	650/1500	650/1200	650/1400	650/1200
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-

Boot volume [l]	380	380	380	380
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1270	-/1270	-/1270	-/1270
Boot length [mm]	815	815	815	815
Boot length with rear seats folded [mm]	1880	1880	1880	1880
Boot width between wheels/max [mm]	1065/1340	1065/1340	1065/1340	1065/1340
Boot height to headliner/ceiling [mm]	-/765-810	-/765-810	-/765-810	-/765-810
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	55	55	55	55
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs
Tyre dimensions front	195/65 R15	195/65 R15	205/55 R16	205/55 R16
Tyre dimensions rear	195/65 R15	195/65 R15	205/55 R16	205/55 R16
Wheel size front	6J x 15	6J x 15	6,5J x 16	6,5J x 16
Wheel size rear	6J x 15	6J x 15	6,5J x 16	6,5J x 16
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	-/11.4	-/11.4	-/11.4	-/11.4

Overall length [mm]	4420	4420	4420	4420
Overall width without/including mirrors [mm]	1740/-	1740/-	1740/-	1740/-
Overall height [mm]	1465	1465	1465	1465
Wheelbase [mm]	2645	2645	2645	2645
Front wheel track [mm]	1510	1510	1510	1510
Rear wheel track [mm]	1515	1515	1515	1515
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	145	145	145	145
Wading depth [mm]	-	-	-	-
Approach angle front [°]	13.7	13.7	13.6	13.6
Approach angle rear [°]	21.9	21.9	22.0	22.0
Transition angle [°]	14.5	14.5	14.6	14.6
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	1010	1010	1010	1010
Headroom rear [mm]	957	957	957	957
Front elbow/shoulder width [mm]	1412/-	1412/-	1412/-	1412/-
Rear elbow/shoulder width [mm]	1377/-	1377/-	1377/-	1377/-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Subaru Impreza GJ facelift 2016 interior

Subaru Impreza GJ facelift 2016 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
