Subaru Forester

Date of manufacture

2012 – 2015 (SUV)

Platform

Manufacturing locations

Ōta, Japan

Designer

Car body style

SUV

Date of manufacture

2012 – 2015

Internal designation

Engine size

Petrol

2.0

2.0 XT

Diesel

2.0D

Euro NCAP

Technical data

SUV

	2.0	2.0	2.0 XT	2.0D	2.0D
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1995	1995	1998	1998	1998
Maximum output / speed [kW/min-1]	110/6200	110/6200	177/5600	108/3600	108/3600
Maximum torque [Nm/min-1]	198/4200	198/4200	350/2400-3600	350/1600-2400	350/1600-2400
Bore and stroke [mm x mm]	84,0 x 90,0	84,0 x 90,0	86,0 x 86,0	86,0 x 86,0	86,0 x 86,0
Compression ratio	10,5:1	10,5:1	10,6:1	16,0:1	16,0:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system	Boxer engine type variable timing of intake and exhaust valves Dual AVCS start&stop system	Boxer engine type direct injection Hitachi turbo-supercharged variable timing of intake and exhaust valves Dual AVCS	Boxer engine type direct injection Common Rail Denso turbocharger with variable blade geometry particulate filter	Boxer engine type direct injection Common Rail Denso turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4	4x4	4x4	4x4
Gearbox	6 gear manual	1 gear automatic	1 gear automatic	6 gear manual	1 gear automatic
Drive specifications	all-wheel drive with inter-axle viscous coupling Symmetrical AWD	all-wheel drive Symmetrical AWD with active torque distribution system automatic gearbox CVT Lineartronic with one variable ratio	all-wheel drive Symmetrical AWD with active torque distribution system automatic gearbox CVT Lineartronic with one variable ratio	all-wheel drive with inter-axle viscous coupling Symmetrical AWD	all-wheel drive Symmetrical AWD with active torque distribution system automatic gearbox CVT Lineartronic with one variable ratio

Top speed [km/h]	190	192	221	190	188
Acceleration 0–100 km/h [s]	10.6	11.8	7.5	9.9	9.9
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	8.5	8.1	11.2	7.1	7.3
Out of town [l]	6.0	5.5	7.0	4.9	5.4
Combined [l]	6.9	6.5	8.5	5.7	6.1
CO2 emissions [g/km]	160	150	197	148	158

Emission standard	EU5-EU6	EU5-EU6	EU5-EU6	EU5-EU6	EU5-EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	79.0	79.0	74.9	75.5	75.5
Driving noise [dB]	71	70	68.2	69.9	69.9

Standby weight [kg]	1477-1496	1507-1539	1615-1638	1552-1584	1615-1659
Overall weight [kg]	2015	2015	2110	2080	2080
Maximum trailer weight unbraked/braked [kg]	750/1800	750/2000	750/2000	750/2000	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	80	80	80	80	80
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-	80/-

Boot volume [l]	505	505	488	505	505
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1592	-/1592	-/1573	-/1592	-/1592
Boot length [mm]	940	940	940	940	940
Boot length with rear seats folded [mm]	1583	1583	1583	1583	1583
Boot width between wheels/max [mm]	1073/1583	1073/1583	1073/1583	1073/1583	1073/1583
Boot height to headliner/ceiling [mm]	-/884	-/884	-/884	-/884	-/884
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs
Tyre dimensions front	225/60R17 99H	225/60R17 99H	225/55R18 98V	225/60R17 99H	225/60R17 99H
Tyre dimensions rear	225/60R17 99H	225/60R17 99H	225/55R18 98V	225/60R17 99H	225/60R17 99H
Wheel size front	7.0J x 17 ET48	7.0J x 17 ET48	7.0J x 18 ET48	7.0J x 17 ET48	7.0J x 17 ET48
Wheel size rear	7.0J x 17 ET48	7.0J x 17 ET48	7.0J x 18 ET48	7.0J x 17 ET48	7.0J x 17 ET48
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	10.6/11.4	10.6/11.4	10.6/11.4	10.6/11.4	10.6/11.4

Overall length [mm]	4595	4595	4595	4595	4595
Overall width without/including mirrors [mm]	1795/-	1795/-	1795/-	1795/-	1795/-
Overall height [mm]	1735	1735	1735	1735	1735
Wheelbase [mm]	2640	2640	2640	2640	2640
Front wheel track [mm]	1545	1545	1545	1545	1545
Rear wheel track [mm]	1550	1550	1550	1550	1550
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	220	220	220	220	220
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	25	25	25	25	25
Approach angle rear [°]	26	26	26	26	26
Transition angle [°]	23	23	23	23	23
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1060	1060	1060	1060	1060
Headroom rear [mm]	1020	1020	1020	1020	1020
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Subaru Forester SJ 2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
