Subaru BRZ

Date of manufacture

3/2012 – 2017 (Coupé)

Platform

Manufacturing locations

Ōta, Japan

Designer

Tetsuya Tada

Kenji Kido

Car body style

Coupé

Date of manufacture

3/2012 – 2017

Internal designation

ZC6

Engine size

2.0i

2.0i Sport

Technical data

Coupé

	2.0i	2.0i	2.0i Sport	2.0i Sport
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1998	1998	1998	1998
Maximum output / speed [kW/min-1]	147/7000	147/7000	147/7000	147/7000
Maximum torque [Nm/min-1]	205/6400-6000	205/6400-6000	205/6400-6000	205/6400-6000
Bore and stroke [mm x mm]	86,0 x 86,0	86,0 x 86,0	86,0 x 86,0	86,0 x 86,0
Compression ratio	12,5:1	12,5:1	12,5:1	12,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	Boxer engine type direct and indirect injection system variable timing of intake and exhaust valves Dual AVCS	Boxer engine type direct and indirect injection system variable timing of intake and exhaust valves Dual AVCS	Boxer engine type direct and indirect injection system variable timing of intake and exhaust valves Dual AVCS	Boxer engine type direct and indirect injection system variable timing of intake and exhaust valves Dual AVCS

Drive axle	Rear	Rear	Rear	Rear
Gearbox	6 gear manual	6 gear automatic	6 gear manual	6 gear automatic
Drive specifications	dry single-disc clutch with single flywheel	six-speed automatic gearbox	dry single-disc clutch with single flywheel	six-speed automatic gearbox with steering wheel controls

Top speed [km/h]	230	210	226	210
Acceleration 0–100 km/h [s]	7.6	8.2	7.6	8.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	9.0	9.4	10.4	9.6
Out of town [l]	5.7	5.5	6.4	5.7
Combined [l]	6.9	6.9	7.8	7.1
CO2 emissions [g/km]	158	159	181	164

Emission standard	EU5B	EU5B	EU5B-EU6B	EU5B-EU6B
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	72.5	73.4	72.5	73.4

Standby weight [kg]	1277-1312	1299-1334	1305-1341	1328-1364
Overall weight [kg]	1670	1700	1670	1700
Maximum trailer weight unbraked/braked [kg]	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	243	243	243	243
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/330	-/330	-/330	-/330
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	2	2	2	2
Number of seats	4	4	4	4
Fuel tank volume [l]	50	50	50	50
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.27	0.27	0.27	0.27
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs	double wishbone, coil springs
Tyre dimensions front	205/55 R16 91V	205/55 R16 91V	215/45 R17 87W	215/45 R17 87W
Tyre dimensions rear	205/55 R16 91V	205/55 R16 91V	215/45 R17 87W	215/45 R17 87W
Wheel size front	6.5JJ x 16 ET48	6.5JJ x 16 ET48	7J x 17 ET48	7J x 17 ET48
Wheel size rear	6.5JJ x 16 ET48	6.5JJ x 16 ET48	7J x 17 ET48	7J x 17 ET48
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.8/-	10.8/-	10.8/-	10.8/-

Overall length [mm]	4240	4240	4240	4240
Overall width without/including mirrors [mm]	1775/-	1775/-	1775/-	1775/-
Overall height [mm]	1285	1285	1285	1285
Wheelbase [mm]	2570	2570	2570	2570
Front wheel track [mm]	1520	1520	1520	1520
Rear wheel track [mm]	1520	1520	1520	1520
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	130	130	120	120
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	935	935	935	935
Headroom rear [mm]	855	855	855	855
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
