SsangYong Rexton
Date of manufacture
2017 – 2020 (Large SUV)
Platform
-
Manufacturing locations
Pyeongtaek, South Korea
Designer
-
Tags
Large SUV
Korean cars
The SsangYong Rexton is a large SUV produced by the South Korean automaker since 2017. The engine range includes only diesel engines, the most powerful of which is the DIESEL 2.2 E-XDI 7-seater with a maximum power of 133.1 kW and a maximum speed of 184 km/h. The most economical version of the DIESEL 2.2 E-XDI 5-seater has a fuel consumption of 7.6 l/100 km and CO2 emissions of 198 g/km. The car offers a luggage space of 1051 liters.
Car body style
Large SUV
Date of manufacture
2017 – 2020Internal designation
Y400Technical data
Large SUV
| Diesel 2.2 5 seats | Diesel 2.2 7 seats | Diesel 2.2 5 seats | Diesel 2.2 7 seats | Diesel 2.2 5 seats | Diesel 2.2 7 seats | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2157 | 2157 | 2157 | 2157 | 2157 | 2157 |
| Maximum output / speed [kW/min-1] | 133,1/4000 | 133,1/4000 | 133,1/4000 | 133,1/4000 | 133,1/4000 | 133,1/4000 |
| Maximum torque [Nm/min-1] | 400/1400-2800 | 400/1400-2800 | 420/1600-2600 | 420/1600-2600 | 400/1400-2800 | 400/1400-2800 |
| Bore and stroke [mm x mm] | 86,2 x 92,4 | 86,2 x 92,4 | 86,2 x 92,4 | 86,2 x 92,4 | 86,2 x 92,4 | 86,2 x 92,4 |
| Compression ratio | 15,5:1 | 15,5:1 | 15,5:1 | 15,5:1 | 15,5:1 | 15,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear manual | 7 gear automatic | 7 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications | - | - |
|
|
|
|
| Top speed [km/h] | 184 | 184 | 181 | 181 | 184 | 184 |
| Acceleration 0–100 km/h [s] | 11,3 | 11,3 | 11,97 | 11,97 | 11,3 | 11,3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9,5-10,0 | 9,5-10,0 | 10,1 | 10,1 | 9,8-10,0 | 9,8-10,0 |
| Out of town [l] | 6,3-6,6 | 6,3-6,6 | 6,8 | 6,8 | 6,5-6,6 | 6,5-6,6 |
| Combined [l] | 7,5-7,8 | 7,5-7,8 | 8,0 | 8,0 | 7,7-7,9 | 7,7-7,9 |
| CO2 emissions [g/km] | 197-207 | 197-207 | 206-210 | 207-211 | 203-207 | 203-207 |
| Low speed [l] | 9,2 | 9,4 | - | - | 9,8 | 10,1 |
| Medium speed [l] | 6,7 | 6,9 | - | - | 7,2 | 7,4 |
| High speed [l] | 6,4 | 6,5 | - | - | 6,7 | 6,9 |
| Extra high speed [l] | 8,2 | 8,2 | - | - | 8,3 | 8,3 |
| Combined speed [l] | 7,6 | 7,7 | - | - | 7,8 | 7,9 |
| CO2 emissions [g/km] | 198 | 200 | - | - | 204 | 207 |
| Emission standard | Euro 6d-Temp | Euro 6d-Temp | Euro 6d-Temp | Euro 6d-Temp | Euro 6d-Temp | Euro 6d-Temp |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1995-2065 | 2020-2092 | 2005-2106 | 2030-133 | 2095-2165 | 2120-2192 |
| Overall weight [kg] | 2750 | 2850 | 2750 | 2850 | 2860 | 2960 |
| Maximum trailer weight unbraked/braked [kg] | 750/2700 | 750/2700 | 750/2700 | 750/2700 | 750/2700 | 750/2700 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 1051 | 240 | 1051 | 240 | 1051 | 240 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 1652/1977 | 1029/1806 | 1652/1977 | 1029/1806 | 1652/1977 | 1029/1806 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 7 | 5 | 7 | 5 | 7 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 |
| Tyre dimensions rear | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 | 235/70 R17 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- |
| Overall length [mm] | 4850 | 4850 | 4850 | 4850 | 4850 | 4850 |
| Overall width without/including mirrors [mm] | 1960/- | 1960/- | 1960/- | 1960/- | 1960/- | 1960/- |
| Overall height [mm] | 1825 | 1825 | 1825 | 1825 | 1825 | 1825 |
| Wheelbase [mm] | 2865 | 2865 | 2865 | 2865 | 2865 | 2865 |
| Front wheel track [mm] | 1640 | 1640 | 1640 | 1640 | 1640 | 1640 |
| Rear wheel track [mm] | 1640 | 1640 | 1640 | 1640 | 1640 | 1640 |
| Forward overhang [mm] | 895 | 895 | 895 | 895 | 895 | 895 |
| Rear overhang [mm] | 1090 | 1090 | 1090 | 1090 | 1090 | 1090 |
| Clearance [mm] | 203-224 | 203-224 | 203-224 | 203-224 | 203-224 | 203-224 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 20,5 | 20,5 | 20,5 | 20,5 | 20,5 | 20,5 |
| Approach angle rear [°] | 22,0 | 22,0 | 22,0 | 22,0 | 22,0 | 22,0 |
| Transition angle [°] | 20,0 | 20,0 | 20,0 | 20,0 | 20,0 | 20,0 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Diesel 2.2 5 seats | Diesel 2.2 7 seats | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 2157 | 2157 | ||||
| Maximum output / speed [kW/min-1] | 133,1/4000 | 133,1/4000 | ||||
| Maximum torque [Nm/min-1] | 420/1600-2600 | 420/1600-2600 | ||||
| Bore and stroke [mm x mm] | 86,2 x 92,4 | 86,2 x 92,4 | ||||
| Compression ratio | 15,5:1 | 15,5:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | 4x4 | ||||
| Gearbox | 7 gear automatic | 7 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 181 | 181 | ||||
| Acceleration 0–100 km/h [s] | 11,97 | 11,97 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 10,2-10,4 | 10,2-10,4 | ||||
| Out of town [l] | 6,8-6,9 | 6,8-6,9 | ||||
| Combined [l] | 8,0-8,2 | 8,0-8,2 | ||||
| CO2 emissions [g/km] | 213-217 | 213-217 | ||||
| Low speed [l] | - | 11,7 | ||||
| Medium speed [l] | - | 8,1 | ||||
| High speed [l] | - | 7,1 | ||||
| Extra high speed [l] | - | 8,3 | ||||
| Combined speed [l] | - | 8,4 | ||||
| CO2 emissions [g/km] | - | 220 | ||||
| Emission standard | Euro 6d-Temp | Euro 6d-Temp | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 2105-2206 | 2130-2233 | ||||
| Overall weight [kg] | 2860 | 2960 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/3000 | 750/3000 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | - | - | ||||
| Maximum load on roof/carrier [kg] | - | - | ||||
| Boot volume [l] | 1051 | 240 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | 1652/1977 | 1029/1806 | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 7 | ||||
| Fuel tank volume [l] | 70 | 70 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | - | - | ||||
| Front suspension | double wishbone | double wishbone | ||||
| Rear suspension | five-link | five-link | ||||
| Tyre dimensions front | 235/70 R17 | 235/70 R17 | ||||
| Tyre dimensions rear | 235/70 R17 | 235/70 R17 | ||||
| Wheel size front | - | - | ||||
| Wheel size rear | - | - | ||||
| Brake dimensions front | - | - | ||||
| Brake dimensions rear | - | - | ||||
| Steering | Hydraulic power steering | Hydraulic power steering | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 11,0/- | 11,0/- | ||||
| Overall length [mm] | 4850 | 4850 | ||||
| Overall width without/including mirrors [mm] | 1960/- | 1960/- | ||||
| Overall height [mm] | 1825 | 1825 | ||||
| Wheelbase [mm] | 2865 | 2865 | ||||
| Front wheel track [mm] | 1640 | 1640 | ||||
| Rear wheel track [mm] | 1640 | 1640 | ||||
| Forward overhang [mm] | 895 | 895 | ||||
| Rear overhang [mm] | 1090 | 1090 | ||||
| Clearance [mm] | 203-224 | 203-224 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | 20,5 | 20,5 | ||||
| Approach angle rear [°] | 22,0 | 22,0 | ||||
| Transition angle [°] | 20,0 | 20,0 | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | - | - | ||||
| Headroom rear [mm] | - | - | ||||
| Front elbow/shoulder width [mm] | - | - | ||||
| Rear elbow/shoulder width [mm] | - | - | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
