Smart Fortwo

Date of manufacture

2014 – now (Three-door hatchback)

2/2016 – now (Convertible)

Platform

Manufacturing locations

Hambach, France

Designer

Kai Sieber

Michael Gebhardt

Car body style

Three-door hatchback

Date of manufacture

2014 – now

Internal designation

W453

Engine size

Convertible

Date of manufacture

2/2016 – now

Internal designation

A453

Engine size

52 kW

66 kW

Brabus 80 kW

Euro NCAP

Technical data

Three-door hatchback

	45 kW	52 kW	52 kW	66 kW	66 kW	Brabus 80 kW
Date of sale	from 2015 to 2017	-	-	-	-	from 2016 to 2018
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	999	999	999	898	898	898
Maximum output / speed [kW/min-1]	45/6000	52/6000	52/6000	66/5500	66/5500	80/5750
Maximum torque [Nm/min-1]	91/2850	91/2850	91/2850	135/2500	135/2500	170/2000
Bore and stroke [mm x mm]	72,2 x 81,3	72,2 x 81,3	72,2 x 81,3	72,2 x 73,1	72,2 x 73,1	72,2 x 73,1
Compression ratio	10,5:1	10,5:1	10,5:1	9,5:1	9,5:1	9,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves	variable timing of intake valves start&stop system	variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	5 gear manual	5 gear manual	6 gear automatic	5 gear manual	6 gear automatic	6 gear automatic
Drive specifications	-	-	dual-clutch automatic gearbox TWINAMIC	-	dual-clutch automatic gearbox TWINAMIC	dual-clutch automatic gearbox TWINAMIC

Top speed [km/h]	151	151	151	155	155	165
Acceleration 0–100 km/h [s]	15.6	14.4	15.1	10.4	11.3	9.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	5.6	5.9-4.9	5.4-4.7	6.3-4.9	6.0-5.0	5.2
Out of town [l]	3.8	4.5-3.7	4.5-3.7	4.6-3.7	4.5-3.6	4.1
Combined [l]	4.5	5.0-4.1	4.8-4.1	5.2-4.2	5.0-4.1	4.5
CO2 emissions [g/km]	104	115-93	111-94	119-97	115-96	102

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	885	890	935	915	940	995
Overall weight [kg]	1145	1150	1180	1170	1195	1195
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	260	260	260	260	260	260
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	624	624	624	624	624	624
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	743	743	743	743	743	743
Height of the open boot door [mm]	1750	1750	1750	1750	1750	1750
Boot opening height [mm]	605	605	605	605	605	605
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	3	3	3	3	3	3
Number of seats	2	2	2	2	2	2
Fuel tank volume [l]	28	28	28	28	28	35
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	integral rear axle	integral rear axle	integral rear axle	integral rear axle	integral rear axle	integral rear axle
Tyre dimensions front	165/65 R15	165/65 R15	165/65 R15	165/65 R15	165/65 R15	185/50 R16
Tyre dimensions rear	185/60 R15	185/60 R15	185/60 R15	185/60 R15	185/60 R15	205/40 R17
Wheel size front	5.0J x 15	5.0J x 15	5.0J x 15	5.0J x 15	5.0J x 15	6.0J x 16
Wheel size rear	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	7.0J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	6.95/7.30	6.95/7.30	6.95/7.30	6.95/7.30	6.95/7.30	6.95/7.30

Overall length [mm]	2695	2695	2695	2695	2695	2740
Overall width without/including mirrors [mm]	1663/1888	1663/1888	1663/1888	1663/1888	1663/1888	1747/-
Overall height [mm]	1555	1555	1555	1555	1555	1543
Wheelbase [mm]	1873	1873	1873	1873	1873	1873
Front wheel track [mm]	1469	1469	1469	1469	1469	1449
Rear wheel track [mm]	1430	1430	1430	1430	1430	1414
Forward overhang [mm]	424	424	424	424	424	-
Rear overhang [mm]	398	398	398	398	398	-
Clearance [mm]	113	113	113	113	113	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	27.8	27.8	27.8	27.8	27.8	-
Approach angle rear [°]	35.9	35.9	35.9	35.9	35.9	-
Transition angle [°]	14.4	14.4	14.4	14.4	14.4	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1009	1009	1009	1009	1009	1009
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	1361/1311	1361/1311	1361/1311	1361/1311	1361/1311	1361/1311
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Convertible

	52 kW	52 kW	66 kW	66 kW	Brabus 80 kW
Date of sale	-	-	-	-	from 2016 to 2018
Engine type	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	999	999	898	898	898
Maximum output / speed [kW/min-1]	52/6000	52/6000	66/5500	66/5500	80/5750
Maximum torque [Nm/min-1]	91/2850	91/2850	135/2500	135/2500	170/2000
Bore and stroke [mm x mm]	72,2 x 81,3	72,2 x 81,3	72,2 x 73,1	72,2 x 73,1	72,2 x 73,1
Compression ratio	10,5:1	10,5:1	9,5:1	9,5:1	9,5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves start&stop system	variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system

Drive axle	Rear	Rear	Rear	Rear	Rear
Gearbox	5 gear manual	6 gear automatic	5 gear manual	6 gear automatic	6 gear automatic
Drive specifications	-	dual-clutch automatic gearbox TWINAMIC	-	dual-clutch automatic gearbox TWINAMIC	dual-clutch automatic gearbox TWINAMIC

Top speed [km/h]	151	151	155	155	165
Acceleration 0–100 km/h [s]	14.9	15.5	10.8	11.7	9.5
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	5.7-5.1	5.5-5.1	6.3-5.0	6.2-4.9	5.2
Out of town [l]	4.7-3.8	5.1-3.8	4.8-3.9	4.9-3.8	4.3
Combined [l]	5.1-4.3	5.2-4.3	5.4-4.3	5.3-4.2	4.6
CO2 emissions [g/km]	115-99	120-99	123-99	122-97	104

Emission standard	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	940	975	960	995	1040
Overall weight [kg]	1175	1205	1195	1225	1225
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	260	260	260	260	260
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-
Boot length [mm]	624	624	624	624	624
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	743	743	743	743	743
Height of the open boot door [mm]	1750	1750	1750	1750	1750
Boot opening height [mm]	605	605	605	605	605
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	2	2	2	2	2
Number of seats	2	2	2	2	2
Fuel tank volume [l]	28	28	28	28	35
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	integral rear axle	integral rear axle	integral rear axle	integral rear axle	integral rear axle
Tyre dimensions front	165/65 R15	165/65 R15	165/65 R15	165/65 R15	185/50 R16
Tyre dimensions rear	185/60 R15	185/60 R15	185/60 R15	185/60 R15	205/40 R17
Wheel size front	5.0J x 15	5.0J x 15	5.0J x 15	5.0J x 15	6.0J x 16
Wheel size rear	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	7.0J x 17
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	6.95/7.30	6.95/7.30	6.95/7.30	6.95/7.30	6.95/7.30

Overall length [mm]	2695	2695	2695	2695	2740
Overall width without/including mirrors [mm]	1663/1888	1663/1888	1663/1888	1663/1888	1747/-
Overall height [mm]	1555	1555	1555	1555	1543
Wheelbase [mm]	1873	1873	1873	1873	1873
Front wheel track [mm]	1469	1469	1469	1469	1449
Rear wheel track [mm]	1430	1430	1430	1430	1414
Forward overhang [mm]	424	424	424	424	-
Rear overhang [mm]	398	398	398	398	-
Clearance [mm]	113	113	113	113	-
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	27.8	27.8	27.8	27.8	-
Approach angle rear [°]	35.9	35.9	35.9	35.9	-
Transition angle [°]	14.4	14.4	14.4	14.4	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1009	1009	1009	1009	1009
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	1361/1311	1361/1311	1361/1311	1361/1311	1361/1311
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
