Smart Forfour

Date of manufacture

2014 – 2019 (Five-door hatchback)

Platform

Manufacturing locations

Novo Mesto, Slovenia

Designer

Kai Sieber

Michael Gebhardt

Car body style

Five-door hatchback

Date of manufacture

2014 – 2019

Internal designation

W453

Engine size

Euro NCAP

Technical data

Five-door hatchback

	45 kW	52 kW	52 kW	66 kW	66 kW	Brabus
Date of sale	from 2015 to 2017	-	-	-	-	from 2016 to 2018
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	999	999	999	898	898	898
Maximum output / speed [kW/min-1]	45/6000	52/6000	52/6000	66/5500	66/5500	80/5750
Maximum torque [Nm/min-1]	91/2850	91/2850	91/2850	135/2500	135/2500	170/2000
Bore and stroke [mm x mm]	72,2 x 81,3	72,2 x 81,3	72,2 x 81,3	72,2 x 73,1	72,2 x 73,1	72,2 x 73,1
Compression ratio	10,5:1	10,5:1	10,5:1	9,5:1	9,5:1	9,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves	variable timing of intake valves start&stop system	variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system	turbo-supercharged variable timing of intake valves start&stop system

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	5 gear manual	5 gear manual	6 gear automatic	5 gear manual	6 gear automatic	6 gear automatic
Drive specifications	-	-	dual-clutch automatic gearbox TWINAMIC	-	dual-clutch automatic gearbox TWINAMIC	dual-clutch automatic gearbox TWINAMIC

Top speed [km/h]	151	151	151	165	165	180
Acceleration 0–100 km/h [s]	16.7	15.9	16.9	11.2	11.9	10.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	5.8	6.0-4.8	5.6-5.0	6.7-5.1	6.1-5.2	5.4
Out of town [l]	4.0	4.7-3.8	4.6-3.6	4.7-3.9	4.6-3.6	4.2
Combined [l]	4.7	5.2-4.2	5.0-4.2	5.4-4.3	5.2-4.2	4.6
CO2 emissions [g/km]	108	118-97	113-96	123-99	118-98	123

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	970	975	1005	995	1025	1095
Overall weight [kg]	1390	1400	1435	1420	1450	1460
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	185	185	185	185	185	185
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/975	-/975	-/975	-/975	-/975	-/975
Boot length [mm]	575	575	575	575	575	575
Boot length with rear seats folded [mm]	1285	1285	1285	1285	1285	1285
Boot width between wheels/max [mm]	-/996	-/996	-/996	-/996	-/996	-/996
Boot height to headliner/ceiling [mm]	-/613	-/613	-/613	-/613	-/613	-/613
Loading edge height [mm]	753	753	753	753	753	753
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	613	613	613	613	613	613
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	4	4	4	4	4	4
Fuel tank volume [l]	28	28	28	28	28	35
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	integral rear axle	integral rear axle	integral rear axle	integral rear axle	integral rear axle	integral rear axle
Tyre dimensions front	165/65 R15	165/65 R15	165/65 R15	165/65 R15	165/65 R15	185/45 R17
Tyre dimensions rear	185/60 R15	185/60 R15	185/60 R15	185/60 R15	185/60 R15	205/40 R17
Wheel size front	5.0J x 15	5.0J x 15	5.0J x 15	5.0J x 15	5.0J x 15	6.0J x 17
Wheel size rear	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	5.5J x 15	7.0J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	8.65/8.95	8.65/8.95	8.65/8.95	8.65/8.95	8.65/8.95	8.65/8.95

Overall length [mm]	3495	3495	3495	3495	3495	3525
Overall width without/including mirrors [mm]	1665/1875	1665/1875	1665/1875	1665/1875	1665/1875	1665/1875
Overall height [mm]	1554	1554	1554	1554	1554	1543
Wheelbase [mm]	2494	2494	2494	2494	2494	2494
Front wheel track [mm]	1467	1467	1467	1467	1467	1455
Rear wheel track [mm]	1429	1429	1429	1429	1429	1414
Forward overhang [mm]	528	528	528	528	528	-
Rear overhang [mm]	473	473	473	473	473	-
Clearance [mm]	108	108	108	108	108	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	22	22	22	22	22	-
Approach angle rear [°]	33.1	33.1	33.1	33.1	33.1	-
Transition angle [°]	10.2	10.2	10.2	10.2	10.2	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1023	1023	1023	1023	1023	1023
Headroom rear [mm]	952	952	952	952	952	952
Front elbow/shoulder width [mm]	1339/1308	1339/1308	1339/1308	1339/1308	1339/1308	1339/1308
Rear elbow/shoulder width [mm]	1337/1279	1337/1279	1337/1279	1337/1279	1337/1279	1337/1279
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-
