Škoda Fabia

Date of manufacture

7/2021 – to this day (Five-door hatchback)

Platform

Volkswagen Group MQB A0

Manufacturing locations

Mladá Boleslav, Czechia

Designer

Car body style

Five-door hatchback

Date of manufacture

7/2021 – to this day

Internal designation

PJ3

Engine size

1.0 MPI

1.0 TSI 95

1.0 TSI 110

Euro NCAP

Technical data

Five-door hatchback

	1.0 MPI	1.0 MPI	1.0 TSI 95	1.0 TSI 110	1.0 TSI 110
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	999	999	999	999	999
Maximum output / speed [kW/min-1]	48/6300	59/6300	70/5000-5500	81/5500	81/5500
Maximum torque [Nm/min-1]	93/3000-3750	95/3700-3900	175/1600-3500	200/2000-3000	200/2000-3000
Bore and stroke [mm x mm]	74,5 x 76,4	74,5 x 76,4	74,5 x 76,4	74,5 x 76,4	74,5 x 76,4
Compression ratio	12.0:1	12.0:1	11.5:1	11.5:1	11.5:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves start&stop system brake energy recuperation	variable timing of intake valves start&stop system brake energy recuperation	direct injection turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	6 gear manual	7 gear automatic
Drive specifications	-	-	-	-	seven-speed dual-clutch automatic gearbox DSG

Top speed [km/h]	172	179	195	205	193
Acceleration 0–100 km/h [s]	15,9	15,5	10,6	10,0	9,9
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	5,8-5,6	5,8-5,6	6,0	6,2-5,9	6,2-5,8
Out of town [l]	3,9-3,7	4,1-3,7	4,0-3,7	4,0-3,7	4,1-3,9
Combined [l]	4,6-4,4	4,7-4,5	4,8-4,6	4,8-4,5	4,7-4,6
CO2 emissions [g/km]	106-101	107-104	109-104	110-103	108-105

Low speed [l]	6.0	6.3-6.0	6.5	6.7	7.6
Medium speed [l]	4.8	5.1-4.8	4.8	5.1	5.6
High speed [l]	4.4	4.7-4.5	4.3	4.4	4.8
Extra high speed [l]	5.4	5.6-5.3	5.2	5.1	5.5
Combined speed [l]	5.1	5.3-5.0	5.0	5.1-4.9	5.6-5.4
CO2 emissions [g/km]	114	124-114	126-113	127-113	136-124

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1116-1266	1116-1269	1142-1294	1165-1317	1187-1339
Overall weight [kg]	1509-1609	1509-1609	1538-1660	1561-1680	1583-1709
Maximum trailer weight unbraked/braked [kg]	550-560/800	550-570/800	570-580/1000	580-590/1100	590-600/1100
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	75	75	75	75	75
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-	75/-

Boot volume [l]	380	380	380	380	380
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1190	-/1190	-/1190	-/1190	-/1190
Boot length [mm]	751	751	751	751	751
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	1001/-	1001/-	1001/-	1001/-	1001/-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	679	679	679	679	679
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	40	40	40	40	40
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.278-0.315	0.278-0.315	0.278-0.315	0.281-0.313	0.281-0.313
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Wheel size front	5,5J x 15	5,5J x 15	5,5J x 15	5,5J x 15	5,5J x 15
Wheel size rear	5,5J x 15	5,5J x 15	5,5J x 15	5,5J x 15	5,5J x 15
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	10.7/-	10.7/-	10.7/-	10.7/-	10.7/-

Overall length [mm]	4108	4108	4108	4108	4108
Overall width without/including mirrors [mm]	1780/1954	1780/1954	1780/1954	1780/1954	1780/1954
Overall height [mm]	1459	1459	1459	1459	1459
Wheelbase [mm]	2564	2564	2564	2564	2564
Front wheel track [mm]	1525	1525	1525	1525	1525
Rear wheel track [mm]	1509	1509	1509	1509	1509
Forward overhang [mm]	809	809	809	809	809
Rear overhang [mm]	735	735	735	735	735
Clearance [mm]	138	138	138	138	138
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	14.1	14.1	14.1	14.1	14.1
Approach angle rear [°]	17.5	17.5	17.5	17.5	17.5
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1032	1032	1032	1032	1032
Headroom rear [mm]	976	976	976	976	976
Front elbow/shoulder width [mm]	1428/-	1428/-	1428/-	1428/-	1428/-
Rear elbow/shoulder width [mm]	1417/-	1417/-	1417/-	1417/-	1417/-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-
