Basic information Technical Specifications Gallery

Seat Arona

Date of manufacture

7/2021 – to this day (Small SUV)

Platform

Volkswagen Group MQB A0

Manufacturing locations

Martorell, Spain

Designer

Alejandro Mesonero-Romanos

Car body style

Small SUV

after upgrade (facelift)

Date of manufacture

7/2021 – to this day

Internal designation

KJ7

Engine size

Euro NCAP

Test year 2017

pre-facelift version (2017)

Technical data

Small SUV

	1.0 TSI 95	1.0 TSI 110	1.0 TSI 110	1.5 TSI 150
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	4/16
Engine displacement [cm³]	999	999	999	1498
Maximum output / speed [kW/min-1]	70/5000-5500	81/5500	81/5500	110/5000-6000
Maximum torque [Nm/min-1]	175/2000-3500	200/2000-3500	200/2000-3500	250/1500-3500
Bore and stroke [mm x mm]	74,5 x 76,4	74,5 x 76,4	74,5 x 76,4	74,5 x 85,9
Compression ratio	11.5:1	11.5:1	11.5:1	10,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection operation of engine in the Miller cycle turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection operation of engine in the Miller cycle turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection operation of engine in the Miller cycle turbocharger with variable blade geometry variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged technology ACT (shuts down two cylinders if necessary) variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	7 gear automatic	6 gear manual
Drive specifications	-	-	seven-speed dual-clutch automatic gearbox DSG	-

Top speed [km/h]	182	190	190	210
Acceleration 0–100 km/h [s]	11,5	10,3	10,1	8,2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5,8	6,0	5,7	5,8
Out of town [l]	4,4	4,4	4,5	4,6
Combined [l]	4,9	5,0	4,9	5,0
CO2 emissions [g/km]	113	114	113	115

Low speed [l]	-	6.7	7.3	8.3
Medium speed [l]	-	5.1	5.8	6.0
High speed [l]	-	4.5	5.2	5.3
Extra high speed [l]	-	5.6	6.1	6.2
Combined speed [l]	5,4-5,7	5,7-5,3	6,2-5,9	6.3-6,2
CO2 emissions [g/km]	123-129	129-119	141-133	144-140

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1185	1216	1233	1268
Overall weight [kg]	1710	1730	1740	1770
Maximum trailer weight unbraked/braked [kg]	590/1000	600/1100	610/1100	630/1200
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	55	55	55	55
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-

Boot volume [l]	400	400	400	400
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1280	-/1280	-/1280	-/1280
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	40	40	40	40
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H
Tyre dimensions rear	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H	205/60 R16 92H
Wheel size front	6J x 16 ET45	6J x 16 ET45	6J x 16 ET45	6J x 16 ET45
Wheel size rear	6J x 16 ET45	6J x 16 ET45	6J x 16 ET45	6J x 16 ET45
Brake dimensions front	276 x 24	276 x 24	276 x 24	276 x 24
Brake dimensions rear	228 x 42 drum	230 x 9	230 x 9	230 x 9
Steering	Rack & pinion with electro-mechanical power steering C-EPS	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering	Rack & pinion with electro-mechanical power steering C-EPS
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.6/-	10.6/-	10.6/-	10.6/-

Overall length [mm]	4153	4153	4153	4153
Overall width without/including mirrors [mm]	1780/1942	1780/1942	1780/1942	1780/1942
Overall height [mm]	1537	1537	1537	1537
Wheelbase [mm]	2566	2566	2566	2566
Front wheel track [mm]	1513	1513	1513	1513
Rear wheel track [mm]	1495	1495	1495	1495
Forward overhang [mm]	809	809	809	809
Rear overhang [mm]	778	778	778	778
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	1059	1059	1059	1059
Headroom rear [mm]	990	990	990	990
Front elbow/shoulder width [mm]	1425/-	1425/-	1425/-	1425/-
Rear elbow/shoulder width [mm]	1403/-	1403/-	1403/-	1403/-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

	1.0 TGI 90
Date of sale	-
Engine type	Ignition supercharged
Number of cylinders/valves	3/12
Engine displacement [cm³]	999
Maximum output / speed [kW/min-1]	66/4500-5500
Maximum torque [Nm/min-1]	160/1800-3800
Bore and stroke [mm x mm]	74,5 x 76,4
Compression ratio	10,5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	combustion of petrol or CNG direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system brake energy recuperation

Drive axle	Front
Gearbox	6 gear manual
Drive specifications	-

Top speed [km/h]	178
Acceleration 0–100 km/h [s]	13.2
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	4.3 kg
Out of town [l]	3.1 kg
Combined [l]	3.5 kg
CO2 emissions [g/km]	96

Low speed [l]	4.7 kg
Medium speed [l]	3.6 kg
High speed [l]	3.3 kg
Extra high speed [l]	4.0 kg
Combined speed [l]	4.0-3.8 kg
CO2 emissions [g/km]	107-103

Emission standard	Euro 6d
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1311
Overall weight [kg]	1720
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	75/-

Boot volume [l]	282
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1162
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	9 [13.8 kg]
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson, lower triangular arms, torsion stabiliser
Rear suspension	twist beam axle with trailing arms
Tyre dimensions front	205/60 R16 92H
Tyre dimensions rear	205/60 R16 92H
Wheel size front	6J x 16 ET45
Wheel size rear	6J x 16 ET45
Brake dimensions front	276 x 24
Brake dimensions rear	228 x 42 drum
Steering	Rack & pinion with electro-mechanical power steering C-EPS
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.6/-

Overall length [mm]	4153
Overall width without/including mirrors [mm]	1780/1942
Overall height [mm]	1537
Wheelbase [mm]	2566
Front wheel track [mm]	1513
Rear wheel track [mm]	1495
Forward overhang [mm]	809
Rear overhang [mm]	778
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	1059
Headroom rear [mm]	990
Front elbow/shoulder width [mm]	1425/-
Rear elbow/shoulder width [mm]	1403/-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Seat Arona KJ7 facelift 2021 front seats

Seat Arona KJ7 facelift 2022 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
