Saab 9-3X
Date of manufacture
2009 – 2012 (Estate)
Platform
GM Epsilon
Manufacturing locations
Trollhättan, Sweden
Designer
-
Tags
D-segment
Swedish cars
The Saab 9-3X is a wagon produced since 2009 in Sweden. It was built on the GM Epsilon platform and offers petrol and diesel engines. The most powerful variant is the 2.0T Biopower XWD with 162 kW of power, the fastest version reaches speeds of up to 235 km/h. The most economical model is the 1.9 TTiD with a consumption of 5.1 l/100 km and emissions of 135 g/km CO2. The car has a luggage compartment size of 477 l.
Car body style
Estate
Date of manufacture
2009 – 2012Internal designation
Technical data
Estate
| 2.0T XWD | 2.0T XWD | 2.0T Biopower XWD | 2.0T XWD | 2.0T Biopower XWD | 2.0T XWD | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1998 | 1998 | 1998 | 1998 | 1998 | 1998 |
| Maximum output / speed [kW/min-1] | 154/5300 | 154/5300 | 154/5300 | 162/5300 | 162/5300 | 162/5300 |
| Maximum torque [Nm/min-1] | 300/2500-4000 | 300/2500-4000 | 300/2500-4000 | 350/2000-4000 | 350/2000-4000 | 350/2000-4000 |
| Bore and stroke [mm x mm] | 86,0 x 86,0 | 86,0 x 86,0 | 86,0 x 86,0 | 86,0 x 86,0 | 86,0 x 86,0 | 86,0 x 86,0 |
| Compression ratio | 9,5:1 | 9,5:1 | 9,5:1 | 9,5:1 | 9,5:1 | 9,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 230 | 220 | 230 | 235 | 235 | 225 |
| Acceleration 0–100 km/h [s] | 8.8 | 9.6 | 8.8 | 6.9 | 6.9 | 9.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 10.9 | 14.5 | 10.9 | 11.8 | 11.8 | 12.6 |
| Out of town [l] | 6.4 | 7.3 | 6.4 | 6.4 | 6.4 | 6.9 |
| Combined [l] | 8.1 | 10.0 | 8.1 | 8.4 | 8.4 | 9.0 |
| CO2 emissions [g/km] | 186 | 229 | 186 | 195 | 195 | 209 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1605-1840 | 1605-1840 | 1605-1840 | 1605-1840 | 1605-1840 | 1605-1840 |
| Overall weight [kg] | 2090-2220 | 2090-2220 | 2090-2220 | 2090-2220 | 2090-2220 | 2090-2220 |
| Maximum trailer weight unbraked/braked [kg] | 750/1600 | 750/1600 | 750/1600 | 750/1600 | 750/1600 | 750/1600 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 477 | 477 | 477 | 477 | 477 | 477 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1331 | -/1331 | -/1331 | -/1331 | -/1331 | -/1331 |
| Boot length [mm] | 1010 | 1010 | 1010 | 1010 | 1010 | 1010 |
| Boot length with rear seats folded [mm] | 1777 | 1777 | 1777 | 1777 | 1777 | 1777 |
| Boot width between wheels/max [mm] | -/993 | -/993 | -/993 | -/993 | -/993 | -/993 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 61 | 61 | 61 | 61 | 61 | 61 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar |
| Tyre dimensions front | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 |
| Tyre dimensions rear | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 | 225/50 R17 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Brake dimensions front | 314 | 314 | 314 | 314 | 314 | 314 |
| Brake dimensions rear | 292 | 292 | 292 | 292 | 292 | 292 |
| Steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.7/12.2 | 11.7/12.2 | 11.7/12.2 | 11.7/12.2 | 11.7/12.2 | 11.7/12.2 |
| Overall length [mm] | 4690 | 4690 | 4690 | 4690 | 4690 | 4690 |
| Overall width without/including mirrors [mm] | 1802/- | 1802/- | 1802/- | 1802/- | 1802/- | 1802/- |
| Overall height [mm] | 1529 | 1529 | 1529 | 1529 | 1529 | 1529 |
| Wheelbase [mm] | 2675 | 2675 | 2675 | 2675 | 2675 | 2675 |
| Front wheel track [mm] | 1524 | 1524 | 1524 | 1524 | 1524 | 1524 |
| Rear wheel track [mm] | 1506 | 1506 | 1506 | 1506 | 1506 | 1506 |
| Forward overhang [mm] | 985 | 985 | 985 | 985 | 985 | 985 |
| Rear overhang [mm] | 1030 | 1030 | 1030 | 1030 | 1030 | 1030 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 995 | 995 | 995 | 995 | 995 | 995 |
| Headroom rear [mm] | 987 | 987 | 987 | 987 | 987 | 987 |
| Front elbow/shoulder width [mm] | 1456/1414 | 1456/1414 | 1456/1414 | 1456/1414 | 1456/1414 | 1456/1414 |
| Rear elbow/shoulder width [mm] | 1458/1400 | 1458/1400 | 1458/1400 | 1458/1400 | 1458/1400 | 1458/1400 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.0T Biopower XWD | 1.9 TTiD | 1.9 TTiD | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1998 | 1910 | 1910 | |||
| Maximum output / speed [kW/min-1] | 162/5300 | 132/4000 | 132/4000 | |||
| Maximum torque [Nm/min-1] | 350/2000-4000 | 400/1850-2750 | 400/1850-2750 | |||
| Bore and stroke [mm x mm] | 86,0 x 86,0 | 82,0 x 90,4 | 82,0 x 90,4 | |||
| Compression ratio | 9,5:1 | 16,5:1 | 16,5:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | 4x4 | Front | Front | |||
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | |||
| Drive specifications |
| - |
| |||
| Top speed [km/h] | 225 | 225 | 215 | |||
| Acceleration 0–100 km/h [s] | 9.1 | 8.7 | 8.9 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 12.6 | 6.4 | 7.9 | |||
| Out of town [l] | 6.9 | 4.4 | 5.0 | |||
| Combined [l] | 9.0 | 5.1 | 6.0 | |||
| CO2 emissions [g/km] | 209 | 135 | 159 | |||
| Emission standard | EU5 | EU5 | EU5 | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1605-1840 | 1605-1840 | 1605-1840 | |||
| Overall weight [kg] | 2090-2220 | 2090-2220 | 2090-2220 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/1600 | 750/1600 | 750/1600 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | |||
| Boot volume [l] | 477 | 477 | 477 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1331 | -/1331 | -/1331 | |||
| Boot length [mm] | 1010 | 1010 | 1010 | |||
| Boot length with rear seats folded [mm] | 1777 | 1777 | 1777 | |||
| Boot width between wheels/max [mm] | -/993 | -/993 | -/993 | |||
| Boot height to headliner/ceiling [mm] | - | - | - | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 61 | 58 | 58 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | independent multipoint wheel suspension with torsion bar | |||
| Tyre dimensions front | 225/50 R17 | 225/50 R17 | 225/50 R17 | |||
| Tyre dimensions rear | 225/50 R17 | 225/50 R17 | 225/50 R17 | |||
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | |||
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | |||
| Brake dimensions front | 314 | 302 | 302 | |||
| Brake dimensions rear | 292 | 292 | 292 | |||
| Steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 11.7/12.2 | 11.7/12.2 | 11.7/12.2 | |||
| Overall length [mm] | 4690 | 4690 | 4690 | |||
| Overall width without/including mirrors [mm] | 1802/- | 1802/- | 1802/- | |||
| Overall height [mm] | 1529 | 1527 | 1527 | |||
| Wheelbase [mm] | 2675 | 2675 | 2675 | |||
| Front wheel track [mm] | 1524 | 1524 | 1524 | |||
| Rear wheel track [mm] | 1506 | 1506 | 1506 | |||
| Forward overhang [mm] | 985 | 985 | 985 | |||
| Rear overhang [mm] | 1030 | 1030 | 1030 | |||
| Clearance [mm] | - | - | - | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 995 | 995 | 995 | |||
| Headroom rear [mm] | 987 | 987 | 987 | |||
| Front elbow/shoulder width [mm] | 1456/1414 | 1456/1414 | 1456/1414 | |||
| Rear elbow/shoulder width [mm] | 1458/1400 | 1458/1400 | 1458/1400 | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - |
Gallery
