Renault Koleos

Date of manufacture

2016 – 2019 (Medium SUV)

Platform

CMF-CD

Manufacturing locations

Busan (Pusan), South Korea

Wuhan, People's Republic of China

Designer

Alexis Martot

Car body style

Medium SUV

Date of manufacture

2016 – 2019

Internal designation

Engine size

Energy dCi 130

Energy dCi 175

Euro NCAP

Technical data

Medium SUV

	Energy dCi 130	Energy dCi 130	Energy dCi 175	Energy dCi 175	Energy dCi 175
Date of sale	from to 2018	from to 2018	-	-	-
Engine type	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1598	1598	1995	1995	1995
Maximum output / speed [kW/min-1]	96/4000	96/4000	130/3750	130/3750	130/3750
Maximum torque [Nm/min-1]	320/2000	320/2000	380/2000	380/2000	380/2000
Bore and stroke [mm x mm]	80,0 x 79,5	80,0 x 79,5	84.0 x 90.0	84.0 x 90.0	84.0 x 90.0
Compression ratio	15,1:1	15,4:1	16.0:1	16.0:1	16.0:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry start&stop system brake energy recuperation

Drive axle	Front	Front	Front	4x4	4x4
Gearbox	6 gear manual	1 gear automatic	1 gear automatic	6 gear manual	1 gear automatic
Drive specifications	-	automatic gearbox X-Tronic with one variable ratio (7 of virtual gears)	automatic gearbox X-Tronic with one variable ratio (7 of virtual gears)	automatically controlled all-wheel drive All Mode 4×4-i	automatically controlled all-wheel drive All Mode 4×4-i automatic gearbox X-Tronic with one variable ratio (7 of virtual gears)

Top speed [km/h]	185	165	202	202	201
Acceleration 0–100 km/h [s]	11.4	13.3	9.3	10.7	9.6
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	8.6 (4th gear)	11.3	7.5	7.0 (4th gear)	7.9

City [l]	5.1	5.7	5.8	6.0	6.1
Out of town [l]	4.2	5.3	5.2	4.9	5.7
Combined [l]	4.6	5.5	5.4	5.3	5.8
CO2 emissions [g/km]	120	142	143	140	156

Emission standard	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1540	1599	1643	1660	1696
Overall weight [kg]	2149	2168	2225	2230	2273
Maximum trailer weight unbraked/braked [kg]	750/2000	750/1650	750/1650	750/2000	750/1650
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	498	498	498	498	498
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1706	-/1706	-/1706	-/1706	-/1706
Boot length [mm]	974	974	974	974	974
Boot length with rear seats folded [mm]	1889	1889	1889	1889	1889
Boot width between wheels/max [mm]	1066/-	1066/-	1066/-	1066/-	1066/-
Boot height to headliner/ceiling [mm]	366/-	366/-	366/-	366/-	366/-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	902/1091	902/1091	902/1091	902/1091	902/1091

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	225/65 R17 102H	225/65 R17 102H	225/60R18 100H	225/60R18 100H	225/60R18 100H
Tyre dimensions rear	225/65 R17 102H	225/65 R17 102H	225/60R18 100H	225/60R18 100H	225/60R18 100H
Wheel size front	-	-	-	-	-
Wheel size rear	-	-	-	-	-
Brake dimensions front	296 x 26	296 x 26	320 x 28	320 x 28	320 x 28
Brake dimensions rear	292 x 16	292 x 16	292 x 16	292 x 16	292 x 16
Steering	Electric variable power steering	Electric variable power steering	Electric variable power steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	11.4/12.1	11.4/12.1	11.4/12.1	11.4/12.1	11.4/12.1

Overall length [mm]	4673	4673	4673	4673	4673
Overall width without/including mirrors [mm]	1843/2063	1843/2063	1843/2063	1843/2063	1843/2063
Overall height [mm]	1678	1678	1678	1678	1678
Wheelbase [mm]	2705	2705	2705	2705	2705
Front wheel track [mm]	1591	1591	1591	1591	1591
Rear wheel track [mm]	1586	1586	1586	1586	1586
Forward overhang [mm]	930	930	930	930	930
Rear overhang [mm]	1038	1038	1038	1038	1038
Clearance [mm]	210	210	210	210	210
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	953	953	953	953	953
Headroom rear [mm]	911	911	911	911	911
Front elbow/shoulder width [mm]	1483/1449	1483/1449	1483/1449	1483/1449	1483/1449
Rear elbow/shoulder width [mm]	1456/1419	1456/1419	1456/1419	1456/1419	1456/1419
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	289/-	289/-	289/-	289/-	289/-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
