Porsche Macan

Date of manufacture

2/2014 – 2018 (SUV)

Platform

VW Group MLB

Manufacturing locations

Leipzig, Germany

Designer

Michael Mauer

Car body style

SUV

Date of manufacture

2/2014 – 2018

Internal designation

95B

Engine size

Petrol

Macan Turbo Performance Paket

Diesel

Macan S Diesel

Euro NCAP

Technical data

SUV

	Macan	Macan S	Macan GTS	Macan Turbo
Date of sale	-	-	from 2015 to	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	6/24	6/24	6/24
Engine displacement [cm³]	1984	2997	2997	3604
Maximum output / speed [kW/min-1]	185/5000-6800	250/5500-6500	265/6000	294/6000
Maximum torque [Nm/min-1]	370/1600-4500	460/1450-5000	500/1650-4000	550/1350-4500
Bore and stroke [mm x mm]	82,5 x 92,8	96,0 x 69,0	96,0 x 69,0	96,0 x 83,0
Compression ratio	9,6:1	9,8:1	9,8:1	10,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection DFI turbo-supercharged variable timing of intake and exhaust valves VarioCam start&stop system brake energy recuperation	direct injection DFI supercharging by twin turbochargers variable timing of intake valves VarioCam Plus variable exhaust valve timing start&stop system brake energy recuperation	direct injection DFI supercharging by twin turbochargers variable timing of intake valves VarioCam Plus variable exhaust valve timing start&stop system brake energy recuperation	direct injection DFI supercharging by twin turbochargers variable timing of intake valves VarioCam Plus variable exhaust valve timing start&stop system brake energy recuperation

Drive axle	4x4	4x4	4x4	4x4
Gearbox	7 gear automatic	7 gear automatic	7 gear automatic	7 gear automatic
Drive specifications	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK

Top speed [km/h]	229	254	256	266
Acceleration 0–100 km/h [s]	6.7 [6.5 Sport Chrono Paket]	5.4 [5.2 Sport Chrono Paket]	5.2 [5.0 Sport Chrono Paket]	4.8 [4.6 Sport Chrono Paket]
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.4-8.6	11.3-11.6	11.4-11.8	11.5-11.8
Out of town [l]	6.4-6.6	7.3-7.6	7.4-7.8	7.5-7.8
Combined [l]	7.2-7.4	8.7-9.0	8.8-9.2	8.9-9.2
CO2 emissions [g/km]	167-172	204-212	207-215	208-216

Emission standard	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1845	1940	1970	2000
Overall weight [kg]	2445	2550	2550	2550
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2400	750/2400	750/2400
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-

Boot volume [l]	500	500	500	500
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1500	-/1500	-/1500	-/1500
Boot length [mm]	957	957	957	957
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-/1050	-/1050	-/1050	-/1050
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	65	65	65	75
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.36	0.36	0.36	0.37
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	235/60 R18	235/60 R18 103W	265/45 R20 104Y	235/55 R19 101Y
Tyre dimensions rear	255/55 R18	255/55 R18 105W	295/40 R20 106Y	255/50 R19 103Y
Wheel size front	8.0J x 18	8.0J x 18	9.0J x 20	8.0J x 19
Wheel size rear	9.0J x 18	9.0J x 18	10.0J x 20	9.0J x 19
Brake dimensions front	345 x 30	350 x 34	360 x 36	360 x 36
Brake dimensions rear	330 x 22	330 x 22	330 x 22	356 x 28
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	-	-	-	-

Overall length [mm]	4697	4697	4692	4699
Overall width without/including mirrors [mm]	1923/2098	1923/2098	1926/2098	1923/2098
Overall height [mm]	1624	1624	1609	1624
Wheelbase [mm]	2807	2807	2807	2807
Front wheel track [mm]	1655	1655	1650	1655
Rear wheel track [mm]	1651	1651	1658	1651
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	185	185	190	205
Wading depth [mm]	-	-	-	-
Approach angle front [°]	17.9	17.9	23.3	24.8
Approach angle rear [°]	23.3	23.6	22.7	23.6
Transition angle [°]	15.3	15.3	16.5	17.1
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

	Macan Turbo Performance Paket	Macan S Diesel
Date of sale	-	-
Engine type	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	6/24	6/24
Engine displacement [cm³]	3604	2967
Maximum output / speed [kW/min-1]	324/6000	190/4000-4250
Maximum torque [Nm/min-1]	600/1500-4500	580/1750-2500
Bore and stroke [mm x mm]	96,0 x 83,0	83,0 x 91,4
Compression ratio	10,5:1	16,8:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection DFI supercharging by twin turbochargers variable timing of intake valves VarioCam Plus variable exhaust valve timing start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	4x4	4x4
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK	automatically controlled all-wheel drive PTM dual-clutch automatic gearbox PDK

Top speed [km/h]	272	230
Acceleration 0–100 km/h [s]	4.4	6.3 [6.1 Sport Chrono Paket]
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	12.3-12.6	6.7-6.9
Out of town [l]	7.7-8.0	5.7-5.9
Combined [l]	9.4-9.7	6.1-6.3
CO2 emissions [g/km]	217-224	159-164

Emission standard	EU6	EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	2000	1955
Overall weight [kg]	2550	2575
Maximum trailer weight unbraked/braked [kg]	750/2400	750/2400
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	75/-	75/-

Boot volume [l]	500	500
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1500	-/1500
Boot length [mm]	957	957
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-/1050	-/1050
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	5	5
Fuel tank volume [l]	75	60
AdBlue tank volume [l]	-	23.3
Air resistance [Cd]	0.37	0.35
Front suspension	double wishbone	double wishbone
Rear suspension	multilink	multilink
Tyre dimensions front	235/55 R19 101Y	235/60 R18 103W
Tyre dimensions rear	255/50 R19 103Y	255/55 R18 105W
Wheel size front	8.0J x 19	8.0J x 18
Wheel size rear	9.0J x 19	9.0J x 18
Brake dimensions front	390 x 38	350 x 34
Brake dimensions rear	356 x 28	330 x 22
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4699	4697
Overall width without/including mirrors [mm]	1923/2098	1923/2098
Overall height [mm]	1609	1624
Wheelbase [mm]	2807	2807
Front wheel track [mm]	1655	1655
Rear wheel track [mm]	1651	1651
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	190	185
Wading depth [mm]	-	-
Approach angle front [°]	23.3	17.9
Approach angle rear [°]	22.6	23.6
Transition angle [°]	15.9	15.3
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
