Porsche Cayman

Date of manufacture

2012 – 2016 (Coupé)

Platform

Manufacturing locations

Osnabrück, Germany

Stuttgart, Germany

Designer

Tony Hatter

Car body style

Coupé

Date of manufacture

2012 – 2016

Internal designation

981C

Engine size

Cayman

Cayman S

Cayman GTS

Technical data

Coupé

	Cayman	Cayman	Cayman S	Cayman S	Cayman GTS	Cayman GTS
Date of sale	-	-	-	-	from 2014 to	from 2014 to
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	6/24	6/24	6/24	6/24	6/24	6/24
Engine displacement [cm³]	2706	2706	3436	3436	3436	3436
Maximum output / speed [kW/min-1]	202/7400	202/7400	239/7400	239/7400	250/7400	250/7400
Maximum torque [Nm/min-1]	290/4500-6500	290/4500-6500	370/4500-5800	370/4500-5800	380/4750-5800	380/4750-5800
Bore and stroke [mm x mm]	89,0 x 72,5	89,0 x 72,5	97,0 x 77,5	97,0 x 77,5	97,0 x 77,5	97,0 x 77,5
Compression ratio	12,5:1	12,5:1	12,5:1	12,5:1	12,5:1	12,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation	direct injection DFI variable timing of intake valves VarioCam Plus start&stop system brake energy recuperation

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	6 gear manual	7 gear automatic	6 gear manual	7 gear automatic	6 gear manual	7 gear automatic
Drive specifications	-	dual-clutch automatic gearbox PDK	-	dual-clutch automatic gearbox PDK	-	dual-clutch automatic gearbox PDK

Top speed [km/h]	266	264	283	281	285	283
Acceleration 0–100 km/h [s]	5.7	5.6 [5.4 Sport Chrono Paket]	5.0	4.9 [4.7 Sport Chrono Paket]	4.9	4.8 [4.6 Sport Chrono Paket]
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	11.4-11.8	10.6-10.9	12.2-12.7	11.2-11.4	12.7	11.4
Out of town [l]	6.3-6.4	5.9-6.2	6.9-7.1	6.2-6.3	7.1	6.3
Combined [l]	8.2-8.4	7.7-7.9	8.8-9.0	8.0-8.2	9.0	8.2
CO2 emissions [g/km]	192-195	180-183	206-211	188-190	211	190

Emission standard	EU5-EU6	EU5-EU6	EU5-EU6	EU5-EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1385-1405	1415-1435	1395-1415	1425-1445	1420	1450
Overall weight [kg]	1655	1685	1665	1695	1665	1695
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	150+275	150+275	150+275	150+275	150+275	150+275
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	3	3	3	3	3	3
Number of seats	2	2	2	2	2	2
Fuel tank volume [l]	64	64	64	64	64	64
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.3	0.3	0.3	0.3	0.31	0.31
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Tyre dimensions front	235/45 ZR18	235/45 ZR18	235/40 ZR19	235/40 ZR19	235/35 ZR20	235/35 ZR20
Tyre dimensions rear	265/45 ZR18	265/45 ZR18	265/40 ZR19	265/40 ZR19	265/35 ZR20	265/35 ZR20
Wheel size front	8.0J x 18 ET57	8.0J x 18 ET57	8.0J x 19 ET57	8.0J x 19 ET57	8.0J x 20 ET57	8.0J x 20 ET57
Wheel size rear	9.0J x 18 ET47	9.0J x 18 ET47	9.5J x 19 ET45	9.5J x 19 ET45	9.5J x 20 ET45	9.5J x 20 ET45
Brake dimensions front	315 x 28	315 x 28	330 x 28	330 x 28	330 x 28	330 x 28
Brake dimensions rear	299 x 20	299 x 20	299 x 20	299 x 20	299 x 20	299 x 20
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.98/-	10.98/-	10.98/-	10.98/-	10.98/-	10.98/-

Overall length [mm]	4380	4380	4380	4380	4404	4404
Overall width without/including mirrors [mm]	1801/-	1801/-	1801/-	1801/-	1801/-	1801/-
Overall height [mm]	1294	1294	1294	1294	1284	1284
Wheelbase [mm]	2475	2475	2475	2475	2475	2475
Front wheel track [mm]	-	-	-	-	-	-
Rear wheel track [mm]	-	-	-	-	-	-
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
