Basic information Technical Specifications Gallery

Porsche Boxster

Date of manufacture

2008 – 2012 (Roadster)

Platform

Manufacturing locations

Uusikaupunki, Finland

Stuttgart, Germany

Designer

Pinky Lai

Car body style

Roadster

after upgrade (facelift)

Date of manufacture

2008 – 2012

Internal designation

987.2

Engine size

Boxster

Boxster S

Boxster Spyder

Technical data

Roadster

	Boxster	Boxster	Boxster S	Boxster S	Boxster Spyder	Boxster Spyder
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	6/24	6/24	6/24	6/24	6/24	6/24
Engine displacement [cm³]	2893	2893	3436	3436	3436	3436
Maximum output / speed [kW/min-1]	188/6400	188/6400	228/6400	228/6400	235/7200	235/7200
Maximum torque [Nm/min-1]	290/4400-6000	290/4400-6000	360/4400-5500	360/4400-5500	370/4750	370/4750
Bore and stroke [mm x mm]	88,0 x 77,5	88,0 x 77,5	97,0 x 77,5	97,0 x 77,5	97,0 x 77,5	97,0 x 77,5
Compression ratio	11,5:1	11,5:1	12,5:1	12,5:1	12,5:1	12,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves VarioCam Plus	variable timing of intake valves VarioCam Plus	direct injection DFI variable timing of intake valves VarioCam Plus	direct injection DFI variable timing of intake valves VarioCam Plus	direct injection DFI variable timing of intake valves VarioCam Plus	direct injection DFI variable timing of intake valves VarioCam Plus

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	6 gear manual	7 gear automatic	6 gear manual	7 gear automatic	6 gear manual	7 gear automatic
Drive specifications	-	dual-clutch automatic gearbox PDK	-	dual-clutch automatic gearbox PDK	-	dual-clutch automatic gearbox PDK

Top speed [km/h]	263	261	274	272	267	265
Acceleration 0–100 km/h [s]	5.9	5.8 [5.6 Sport Plus]	5.3	5.2 [5.0 Sport Plus]	5.1	5.0 [4.8 Sport Plus]
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	13.8	13.6	14.4	14.1	14.2	14.0
Out of town [l]	6.9	6.5	7.2	6.6	7.1	6.6
Combined [l]	9.4	9.1	9.8	9.4	9.7	9.3
CO2 emissions [g/km]	221	214	230	221	228	218

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1410	1440	1430	1455	1350	1375
Overall weight [kg]	1635	1670	1645	1675	-	-
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	150+130	150+130	150+130	150+130	-	-
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	2	2	2	2	2	2
Number of seats	2	2	2	2	2	2
Fuel tank volume [l]	64	64	64	64	54	54
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.29	0.3	0.3	0.31	0.29	0.3
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Tyre dimensions front	205/55 ZR17	205/55 ZR17	235/40 ZR18	235/40 ZR18	235/35 ZR19	235/35 ZR19
Tyre dimensions rear	235/50 ZR17	235/50 ZR17	265/40 ZR18	265/40 ZR18	265/35 ZR19	265/35 ZR19
Wheel size front	7.0J x 17	7.0J x 17	8.0J x 18	8.0J x 18	8.5J x 19 ET55	8.5J x 19 ET55
Wheel size rear	8.5J x 17	8.5J x 17	9.0J x 18	9.0J x 18	10.0J x 19 ET42	10.0J x 19 ET42
Brake dimensions front	318	318	318	318	-	-
Brake dimensions rear	299	299	299	299	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.1/-	11.1/-	11.1/-	11.1/-	-	-

Overall length [mm]	4342	4342	4342	4342	-	-
Overall width without/including mirrors [mm]	1801/1978	1801/1978	1801/1978	1801/1978	-	-
Overall height [mm]	1292	1292	1294	1294	-	-
Wheelbase [mm]	2415	2415	2415	2415	-	-
Front wheel track [mm]	-	-	-	-	-	-
Rear wheel track [mm]	-	-	-	-	-	-
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
