Porsche 918 Spyder

Date of manufacture

9/2013 – 6/2015 (Roadster)

Platform

Manufacturing locations

Stuttgart, Germany

Designer

Michael Mauer

Car body style

Roadster

Date of manufacture

9/2013 – 6/2015

Internal designation

Engine size

918 Spyder

Technical data

Roadster

	918 Spyder
Date of sale	-
Engine type	Petrol + Electric
Number of cylinders/valves	8/32
Engine displacement [cm³]	4593
Maximum output / speed [kW/min-1]	447/8700 combustion 95 el. 115 el. 652/8500 total
Maximum torque [Nm/min-1]	917-1280/800-5000
Bore and stroke [mm x mm]	-
Compression ratio	-
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	Plug‐in Hybrid direct injection DFI variable timing of intake and exhaust valves two electric synchronous motors start&stop system brake energy recuperation

Drive axle	4x4
Gearbox	7 gear automatic
Drive specifications	Separate electric motor on front and rear axle dual-clutch automatic gearbox PDK

Top speed [km/h]	345 [150 el.]
Acceleration 0–100 km/h [s]	2.6 [6.2 el.]
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	-
Out of town [l]	-
Combined [l]	3.1 [12.7 kWh]
CO2 emissions [g/km]	72

Emission standard	-
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	-
Battery type and capacity	Lithium-Ionen-Akkumulator, 6.8 kWh
Range with fully charged battery [km]	16-31
Charging time	-
Number of modules/cells	-
Battery weight [kg]	-
Charger	-

Standby weight [kg]	1760
Overall weight [kg]	1899
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	107
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	2
Number of seats	2
Fuel tank volume [l]	70
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	double wishbone
Rear suspension	multilink
Tyre dimensions front	235/35 ZR20
Tyre dimensions rear	325/30 ZR21
Wheel size front	9.5J x 20
Wheel size rear	12.5J x 21
Brake dimensions front	410 x 36
Brake dimensions rear	390 x 32
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	-

Overall length [mm]	4643
Overall width without/including mirrors [mm]	1940/-
Overall height [mm]	1167
Wheelbase [mm]	2730
Front wheel track [mm]	1664
Rear wheel track [mm]	1612
Forward overhang [mm]	-
Rear overhang [mm]	-
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-
