Peugeot 301

Date of manufacture

2012 – 2017 (Sedan)

Platform

PF1 platform

Manufacturing locations

Vigo, Spain

Wuhan, People's Republic of China

Designer

Car body style

Sedan

Date of manufacture

2012 – 2017

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Sedan

	1.2	1.2 PureTech	1.2 PureTech	1.6	1.6	1.6
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	3/12	3/12	3/12	4/16	4/16	4/16
Engine displacement [cm³]	1199	1199	1199	1587	1587	1587
Maximum output / speed [kW/min-1]	53/5500	60/5750	60/5750	85/6050	85/6050	85/6050
Maximum torque [Nm/min-1]	110/3000	117/2750	117/2750	150/4000	150/4000	150/4000
Bore and stroke [mm x mm]	75,0 x 90,5	75,0 x 90,5	75,0 x 90,5	78,5 x 82,0	78,5 x 82,0	78,5 x 82,0
Compression ratio	11,0:1	-	-	11,1:1	11,1:1	11,1:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing VTi	variable valve timing VTi	variable valve timing VTi start&stop system	variable valve timing VTi	variable valve timing VTi	variable valve timing VTi

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear robotic manual	5 gear manual	4 gear automatic	6 gear automatic
Drive specifications	-	-	robotic gearbox ETG5	-	automatic gearbox	automatic gearbox EAT6

Top speed [km/h]	160	168	169	188	188	180
Acceleration 0–100 km/h [s]	15.9	14.5	17.0	9.4-10.3	11.8	-
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	7.0	6.0	5.0	8.7-8.8	10.0	9.2
Out of town [l]	4.3	4.3	4.0	5.0-5.3	5.6	5.3
Combined [l]	5.3	4.9	4.4	6.4-6.5	7.3	6.8
CO2 emissions [g/km]	124	114	103	148-151	168	157

Emission standard	EU5	EU6	EU6	EU5-EU6	EU5	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1095	1055	1055	1165	1185	1190
Overall weight [kg]	1495	1470	1490	1524	1559	1585
Maximum trailer weight unbraked/braked [kg]	450/720	450/720	450/720	580/1010	600/1010	580/1010
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	506	506	506	506	506	506
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1332	-/1332	-/1332	-/1332	-/1332	-/1332
Boot length [mm]	1091	1091	1091	1091	1091	1091
Boot length with rear seats folded [mm]	1621	1621	1621	1621	1621	1621
Boot width between wheels/max [mm]	-/1032	-/1032	-/1032	-/1032	-/1032	-/1032
Boot height to headliner/ceiling [mm]	-/549	-/549	-/549	-/549	-/549	-/549
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	50	50	50	50	50	50
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T
Tyre dimensions rear	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T	185/65 R15T
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-	-	-	-	-	-

Overall length [mm]	4442	4442	4442	4442	4442	4442
Overall width without/including mirrors [mm]	1748/1953	1748/1953	1748/1953	1748/1953	1748/1953	1748/1953
Overall height [mm]	1466	1466	1466	1466	1466	1466
Wheelbase [mm]	2652	2652	2652	2652	2652	2652
Front wheel track [mm]	1501	1501	1501	1501	1501	1501
Rear wheel track [mm]	1478	1478	1478	1478	1478	1478
Forward overhang [mm]	816	816	816	816	816	816
Rear overhang [mm]	974	974	974	974	974	974
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	892	892	892	892	892	892
Headroom rear [mm]	849	849	849	849	849	849
Front elbow/shoulder width [mm]	1409/1380	1409/1380	1409/1380	1409/1380	1409/1380	1409/1380
Rear elbow/shoulder width [mm]	1359/1032	1359/1032	1359/1032	1359/1032	1359/1032	1359/1032
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.6 HDI	1.6 BlueHDI
Date of sale	from to 2015	from 2015 to
Engine type	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/8	4/8
Engine displacement [cm³]	1560	1560
Maximum output / speed [kW/min-1]	68/4000	73/3750
Maximum torque [Nm/min-1]	230/1750	254/1750
Bore and stroke [mm x mm]	75,0 x 88,3	75,0 x 88,3
Compression ratio	-	-
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection turbo-supercharged particulate filter	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter with AdBlue additive injection particulate filter

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear manual
Drive specifications	-	-

Top speed [km/h]	180	180
Acceleration 0–100 km/h [s]	12.4	11.9
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	4.8	4.6
Out of town [l]	3.7	3.4
Combined [l]	4.1	3.9
CO2 emissions [g/km]	108	101

Emission standard	EU5	EU6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1170	1165
Overall weight [kg]	1548	1585
Maximum trailer weight unbraked/braked [kg]	580/1010	580/1010
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	506	506
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1332	-/1332
Boot length [mm]	1091	1091
Boot length with rear seats folded [mm]	1621	1621
Boot width between wheels/max [mm]	-/1032	-/1032
Boot height to headliner/ceiling [mm]	-/549	-/549
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	4	4
Number of seats	5	5
Fuel tank volume [l]	50	50
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar
Tyre dimensions front	185/65 R15T	185/65 R15T
Tyre dimensions rear	185/65 R15T	185/65 R15T
Wheel size front	-	-
Wheel size rear	-	-
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	-	-

Overall length [mm]	4442	4442
Overall width without/including mirrors [mm]	1748/1953	1748/1953
Overall height [mm]	1466	1466
Wheelbase [mm]	2652	2652
Front wheel track [mm]	1501	1501
Rear wheel track [mm]	1478	1478
Forward overhang [mm]	816	816
Rear overhang [mm]	974	974
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	892	892
Headroom rear [mm]	849	849
Front elbow/shoulder width [mm]	1409/1380	1409/1380
Rear elbow/shoulder width [mm]	1359/1032	1359/1032
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Technical data, specifications and dimensions Peugeot 301 2013

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
