Opel Crossland

Date of manufacture

2020 – to this day (Small SUV)

Platform

PSA PF1

Manufacturing locations

Zaragoza, Spain

Designer

Car body style

Small SUV

after upgrade (facelift)

Date of manufacture

2020 – to this day

Internal designation

Engine size

Petrol

1.2

1.2 TURBO S/S

Diesel

1.5 CDTI

Euro NCAP

Test year 2017

pre-facelift version (2017)

Technical data

Small SUV

	1.2	1.2 TURBO S/S	1.2 TURBO S/S	1.2 TURBO S/S	1.5 CDTI	1.5 CDTI
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	4/16	4/16
Engine displacement [cm³]	1199	1199	1199	1199	1499	1499
Maximum output / speed [kW/min-1]	61/5750	81/5500	96/5500	96/5500	81/3750	88/3750
Maximum torque [Nm/min-1]	118/2750	205/1750	230/1750	230/1750	250/1750	300/1750
Bore and stroke [mm x mm]	75,0 x 90,5	75,0 x 90,5	75,0 x 90,5	75,0 x 90,5	75.0 x 84,8	75.0 x 84,8
Compression ratio	11,0:1	10,5:1	10,5:1	10,5:1	16.5:1	16.5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing VTi	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter BlueInjection with AdBlue additive injection start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter BlueInjection with AdBlue additive injection start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	6 gear manual	6 gear manual	6 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	-	-	six-speed automatic gearbox	-	-

Top speed [km/h]	170	187	201	198	185	183
Acceleration 0–100 km/h [s]	14,5	10,9	9,9	10,2	11,8	11,5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	5,6-5,4	5,9-5,8	5,7	5,9	4,2	4,4-4,3
Out of town [l]	4,2-4,1	4,2-4,1	4,2-4,1	4,4	3,3-3,2	3,7-3,6
Combined [l]	4,7-4,6	4,8-4,7	4,8-4,7	5,0-4,9	3,6	3,9
CO2 emissions [g/km]	107-106	109-108	109-107	113-112	95-94	104-102

Low speed [l]	-	-	-	-	-	-
Medium speed [l]	-	-	-	-	-	-
High speed [l]	-	-	-	-	-	-
Extra high speed [l]	-	-	-	-	-	-
Combined speed [l]	6,3-5,8	6,1-5,7	6,0-5,7	6,3-6,0	4,9-4,6	5,2-5,0
CO2 emissions [g/km]	142-131	138-130	137-129	143-136	127-120	138-130

Emission standard	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1165	1254	1263	1280	1280	1350
Overall weight [kg]	1705	1795	1805	1835	1835	1860
Maximum trailer weight unbraked/braked [kg]	560/650	600/840	600/840	600/840	620/840	650/870
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	65	65	65	65	65	65
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-	50/-	50/-

Boot volume [l]	410-520	410-520	410-520	410-520	410-520	410-520
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	810/1255	810/1255	810/1255	810/1255	810/1255	810/1255
Boot length [mm]	793	793	793	793	793	793
Boot length with rear seats folded [mm]	1483	1483	1483	1483	1483	1483
Boot width between wheels/max [mm]	1000/947	1000/947	1000/947	1000/947	1000/947	1000/947
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	728	728	728	728	728	728
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	712	712	712	712	712	712
Boot opening width min/max [mm]	950/1002	950/1002	950/1002	950/1002	950/1002	950/1002

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	45	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	15	15
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	195/65 R15	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Tyre dimensions rear	195/65 R15	205/60 R16	205/60 R16	205/60 R16	205/60 R16	205/60 R16
Wheel size front	6.5J x 15	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Wheel size rear	6.5J x 15	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16	6.5J x 16
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.7/11.2	10.7/11.2	10.7/11.2	10.7/11.2	10.7/11.2	10.7/11.2

Overall length [mm]	4217	4217	4217	4217	4217	4217
Overall width without/including mirrors [mm]	1765/1976	1765/1976	1765/1976	1765/1976	1765/1976	1765/1976
Overall height [mm]	1605	1605	1605	1605	1605	1605
Wheelbase [mm]	2604	2604	2604	2604	2604	2604
Front wheel track [mm]	1518	1518	1518	1518	1518	1518
Rear wheel track [mm]	1491	1491	1491	1491	1491	1491
Forward overhang [mm]	901	901	901	901	901	901
Rear overhang [mm]	712	712	712	712	712	712
Clearance [mm]	153	153	153	153	153	153
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
