	1.0 Twinport	1.0	1.0	1.2 Twinport	1.2 Twinport	1.2
Date of sale	from to 2010	from 2010 to	from 2010 to	from to 2010	from to 2010	from 2010 to
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	3/12	3/12	3/12	4/16	4/16	4/16
Engine displacement [cm³]	996	996	996	1242	1242	1242
Maximum output / speed [kW/min-1]	48/6000	50/6000	50/6000	63/5500	63/5500	69/6000
Maximum torque [Nm/min-1]	90/4800	90/4800	90/4800	114/4400	114/4400	118/4800
Bore and stroke [mm x mm]	73,0 x 79,4	73,0 x 79,4	73,0 x 79,4	73,0 x 74,2	73,0 x 74,2	73,0 x 74,2
Compression ratio	11.0:1	11.0:1	11.0:1	11.0:1	11.0:1	11.0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	-	start&stop system	-	-	start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	4 gear automatic	5 gear manual
Drive specifications	-	-	-	-	automatic gearbox	-

Top speed [km/h]	160	160	160	175	170	175
Acceleration 0–100 km/h [s]	14.7	14.7	14.7	12.3	14.8	12.0
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	5.9	5.6	5.3	6.9	7.8	5.9
Out of town [l]	4.4	4.2	4.2	4.7	4.9	4.5
Combined [l]	5.0	4.7	4.6	5.5	5.9	5.0
CO2 emissions [g/km]	120	109	106	131	142	115

Emission standard	EU4	EU5	EU5	EU4	EU4	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1040	1050	1050	1040	1040	1065
Overall weight [kg]	1435	1485	1485	1435	1435	1485
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	800/800	800/800	-	-	800/800
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	35/-	35/-	35/-	35/-	35/-	35/-

Boot volume [l]	225	225	225	225	225	225
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1050	-/1050	-/1050	-/1050	-/1050	-/1050
Boot length [mm]	610	610	610	610	610	610
Boot length with rear seats folded [mm]	1250	1250	1250	1250	1250	1250
Boot width between wheels/max [mm]	-/1004	-/1004	-/1004	-/1004	-/1004	-/1004
Boot height to headliner/ceiling [mm]	-/703	-/703	-/703	-/703	-/703	-/703
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	45	45	45	45	45	45
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	165/70 R14	165/70 R14	165/70 R14	185/60 R15	185/60 R15	185/60 R15
Tyre dimensions rear	165/70 R14	165/70 R14	165/70 R14	185/60 R15	185/60 R15	185/60 R15
Wheel size front	4.5J x 14	4.5J x 14	4.5J x 14	5.5J x 15	5.5J x 15	5.5J x 15
Wheel size rear	4.5J x 14	4.5J x 14	4.5J x 14	5.5J x 15	5.5J x 15	5.5J x 15
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	9.6/10.0	9.6/10.0	9.6/10.0	9.6/10.0	9.6/10.0	9.6/10.0

Overall length [mm]	3740	3740	3740	3740	3740	3740
Overall width without/including mirrors [mm]	1680/1932	1680/1932	1680/1932	1680/1932	1680/1932	1680/1932
Overall height [mm]	1590	1590	1590	1590	1590	1590
Wheelbase [mm]	2360	2360	2360	2360	2360	2360
Front wheel track [mm]	1470	1470	1470	1470	1470	1470
Rear wheel track [mm]	1480	1480	1480	1480	1480	1480
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.2	1.3 CDTI
Date of sale	from 2010 to	from to 2010
Engine type	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	1242	1248
Maximum output / speed [kW/min-1]	69/6000	55/4000
Maximum torque [Nm/min-1]	118/4800	190/1750
Bore and stroke [mm x mm]	73,0 x 74,2	69,6 x 82,0
Compression ratio	11.0:1	17,6:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	-	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front
Gearbox	4 gear automatic	5 gear manual
Drive specifications	automatic gearbox	-

Top speed [km/h]	170	165
Acceleration 0–100 km/h [s]	14.0	13.9
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	6.9	5.5
Out of town [l]	5.0	4.0
Combined [l]	5.7	4.5
CO2 emissions [g/km]	131	120

Emission standard	EU5	EU4
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1065	1040
Overall weight [kg]	1485	1435
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	800/800	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	35/-	35/-

Boot volume [l]	225	225
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1050	-/1050
Boot length [mm]	610	610
Boot length with rear seats folded [mm]	1250	1250
Boot width between wheels/max [mm]	-/1004	-/1004
Boot height to headliner/ceiling [mm]	-/703	-/703
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	5	5
Fuel tank volume [l]	45	45
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/60 R15	185/60 R15
Tyre dimensions rear	185/60 R15	185/60 R15
Wheel size front	5.5J x 15	5.5J x 15
Wheel size rear	5.5J x 15	5.5J x 15
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	9.6/10.0	9.6/10.0

Overall length [mm]	3740	3740
Overall width without/including mirrors [mm]	1680/1932	1680/1932
Overall height [mm]	1590	1590
Wheelbase [mm]	2360	2360
Front wheel track [mm]	1470	1470
Rear wheel track [mm]	1480	1480
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
