Nissan X-Trail
Date of manufacture
2017 – to this day (Medium SUV)
Platform
Nissan CMF-C/D
Manufacturing locations
Kanda, Japan
Saint Petersburg, Russia
Dalian, People's Republic of China
Busan (Pusan), South Korea
Samut Prakan, Thailand
Smyrna, USA
Designer
Keisuke Otsuki
Tags
Compact SUV
Japanese cars
The Nissan X-Trail is available in a mid-size SUV body style. The car has been produced since 2017 and is manufactured in Japan, Russia, China, South Korea, Thailand and the USA. The car is built on the Nissan CMF-C/D platform. The engine range consists of petrol and diesel engines. The most powerful car is the 2.0 dCi All Mode 4x4-i with a power output of 130 kW. The highest speed is achieved by the 2.0 dCi All Mode 4x4-i with 204 km/h. The most fuel efficient model is the 1.6 dCi with a combined fuel consumption of 4.9 l/100 km and CO2 emissions of 129 g/km. The luggage compartment offers 550 l. During the EURONCAP safety tests, the car received a rating of 5 out of 5. Tested according to the 2014 methodology.
Car body style
Medium SUV
after upgrade (facelift)
Date of manufacture
2017 – to this dayInternal designation
T32
Technical data
Medium SUV
| DIG-T 160 | 1.6 DIG-T | 1.6 dCi | 1.6 dCi | 1.6 dCi All Mode 4x4‐i | dCi 150 | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | from to 2018 | from to 2018 | from to 2018 | from to 2018 | from 2018 to 2020 |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1332 | 1618 | 1598 | 1598 | 1598 | 1749 |
| Maximum output / speed [kW/min-1] | 117/5500 | 120/5600 | 96/4000 | 96/4000 | 96/4000 | 110/3500 |
| Maximum torque [Nm/min-1] | 270/1800-3250 | 240/2000-4000 | 320/1750 | 320/1750 | 320/1750 | 340/1750-2750 |
| Bore and stroke [mm x mm] | 72.2 x 81.35 | 79,7 x 81,1 | 80,0 x 79,5 | 80,0 x 79,5 | 80,0 x 79,5 | 80.0 x 87.0 |
| Compression ratio | 10.5:1 | 10,5:1 | 15,4:1 | 15,4:1 | 15,4:1 | 15.3:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | 4x4 | Front |
| Gearbox | 7 gear automatic | 6 gear manual | 6 gear manual | 1 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications |
| - | - |
|
| - |
| Top speed [km/h] | 198 | 200 | 188 | 180 | 186 | 194 |
| Acceleration 0–100 km/h [s] | 11.5 | 9.7 | 10.5 | 11.4 | 11.0 | 10.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | 7.9 | 5.7 | 5.8 | 6.2 | - |
| Out of town [l] | - | 5.3 | 4.5 | 4.7 | 4.8 | - |
| Combined [l] | - | 6.2 | 4.9 | 5.1 | 5.3 | - |
| CO2 emissions [g/km] | - | 145 | 129 | 135 | 139 | - |
| Low speed [l] | 10,1-9,8 | - | - | - | - | 7,6-7,3 |
| Medium speed [l] | 8,1-7,6 | - | - | - | - | 6,5-6,2 |
| High speed [l] | 7,3-7,0 | - | - | - | - | 5,9-5,6 |
| Extra high speed [l] | 9,2-8,8 | - | - | - | - | 7,5-7,2 |
| Combined speed [l] | 8,5-8,1 | - | - | - | - | 6,8-6,5 |
| CO2 emissions [g/km] | 193-184 | - | - | - | - | 179-171 |
| Emission standard | Euro 6d-TEMP | Euro 6 | Euro 6 | Euro 6 | Euro 6 | Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1485-1581 | 1460-1570 | 1505-1620 | 1565-1670 | 1580-1685 | 1580-1689 |
| Overall weight [kg] | 1985-2180 | 2050-2210 | 2090-2260 | 2140-2310 | 2160-2320 | 2110-2295 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1800 | 750/2000 | 750/1500 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | 1020-1030/1010-1190 | 1035/1090 | 1080/1075 | 1135/1075 | 1110/1115 | 1115-1120/1045-1230 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 100 | 75 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 565 | 550 | 550 | 550 | 550 | 565 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1996 | -/1982 | -/1982 | -/1982 | -/1982 | -/1996 |
| Boot length [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | -/1142 | -/1142 | -/1142 | -/1142 | -/1142 | -/1142 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | - | - | - | - | - | 17 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Tyre dimensions rear | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric variable power steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Electric variable power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- |
| Overall length [mm] | 4690 | 4690 | 4690 | 4690 | 4690 | 4690 |
| Overall width without/including mirrors [mm] | 1820/- | 1820/- | 1820/- | 1820/- | 1820/- | 1820/- |
| Overall height [mm] | 1700 | 1710 | 1710 | 1710 | 1710 | 1700 |
| Wheelbase [mm] | 2706 | 2706 | 2706 | 2706 | 2706 | 2706 |
| Front wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1575 | 1575 |
| Rear wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1575 | 1575 |
| Forward overhang [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Rear overhang [mm] | 1140 | 1140 | 1140 | 1140 | 1140 | 1140 |
| Clearance [mm] | 204 | 210 | 210 | 210 | 210 | 204 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 18.5 | 18.1 | 18.1 | 18.1 | 18.1 | 18.5 |
| Approach angle rear [°] | 26.0 | 26.5 | 26.5 | 26.5 | 26.5 | 26.0 |
| Transition angle [°] | 21 | 20 | 20 | 20 | 20 | 21 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | 30 | 30 | 30 | 30 | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| dCi 150 | dCi 150 ALL MODE 4x4i | dCi 150 ALL MODE 4x4i | 2.0 dCi | 2.0 dCi All Mode 4x4-i | 2.0 dCi All Mode 4x4-i | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to 2020 | from 2018 to 2020 | from 2018 to 2020 | from to 2018 | from to 2018 | from to 2018 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1749 | 1749 | 1749 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 110/3500 | 110/3500 | 110/3500 | 130/3750 | 130/3750 | 130/3750 |
| Maximum torque [Nm/min-1] | 340/1750-2750 | 340/1750-2750 | 340/1750-2750 | 380/2000 | 380/2000 | 380/2000 |
| Bore and stroke [mm x mm] | 80.0 x 87.0 | 76,0 x 80,5 | 76,0 x 80,5 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 15.3:1 | 15.3:1 | 15.3:1 | 15,6:1 | 15,6:1 | 15,6:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | 4x4 | 4x4 | Front | 4x4 | 4x4 |
| Gearbox | 1 gear automatic | 6 gear manual | 1 gear automatic | 1 gear automatic | 6 gear manual | 1 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 190 | 194 | 190 | 199 | 204 | 196 |
| Acceleration 0–100 km/h [s] | 12.7 | 10.7 | 12.7 | 9.6 | 9.4 | 10.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | - | - | 6.2 | 6.3 | 6.6 |
| Out of town [l] | - | - | - | 5.3 | 5.2 | 5.6 |
| Combined [l] | - | - | - | 5.6 | 5.6 | 6.0 |
| CO2 emissions [g/km] | - | - | - | 148 | 149 | 158 |
| Low speed [l] | 8,8-8,2 | 7,9-7,5 | 9,5-9,1 | - | - | - |
| Medium speed [l] | 7,1-6,5 | 6,8-6.5 | 7,6-7,2 | - | - | - |
| High speed [l] | 6,5-5,9 | 6,2-5,9 | 6,8-6,4 | - | - | - |
| Extra high speed [l] | 8,0-7,5 | 7,6-7,3 | 8,4-8,0 | - | - | - |
| Combined speed [l] | 7,5-6,9 | 7,1-6,7 | 7,9-7,5 | - | - | - |
| CO2 emissions [g/km] | 196-182 | 185-177 | 208-194 | - | - | - |
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6 | Euro 6 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1640-1742 | 1670-1754 | 1670-1802 | 1620-1700 | 1625-1720 | 1675-1770 |
| Overall weight [kg] | 2150-2345 | 2175-2360 | 2175-2400 | 2170-2330 | 2190-2350 | 2240-2400 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/2000 | 750/1500 | 750/1650 | 750/2000 | 750/1650 |
| Maximum front/rear axle load [kg] | 1155-1165/1050-1230 | 1140-1145/1085-1250 | 1140-1190/1085-1250 | 1190/1230 | 1180/1260 | 1230/1260 |
| Maximum vertical load on the tow bar [kg] | 75 | 100 | 75 | 75 | 100 | 75 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 565 | 565 | 565 | 550 | 550 | 550 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1996 | -/1996 | -/1996 | -/1982 | -/1982 | -/1982 |
| Boot length [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | -/1142 | -/1142 | -/1142 | -/1142 | -/1142 | -/1142 |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 | 5 or 7 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | 17 | 17 | 17 | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Tyre dimensions rear | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 | 225/65 R17 |
| Wheel size front | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Wheel size rear | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 | 7.0J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- | 11.2/- |
| Overall length [mm] | 4690 | 4690 | 4690 | 4690 | 4690 | 4690 |
| Overall width without/including mirrors [mm] | 1820/- | 1820/- | 1820/- | 1820/- | 1820/- | 1820/- |
| Overall height [mm] | 1700 | 1700 | 1700 | 1710 | 1710 | 1710 |
| Wheelbase [mm] | 2706 | 2706 | 2706 | 2706 | 2706 | 2706 |
| Front wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1575 | 1575 |
| Rear wheel track [mm] | 1575 | 1575 | 1575 | 1575 | 1575 | 1575 |
| Forward overhang [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Rear overhang [mm] | 1140 | 1140 | 1140 | 1140 | 1140 | 1140 |
| Clearance [mm] | 204 | 204 | 204 | 210 | 210 | 210 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 18.5 | 18.5 | 18.5 | 18.1 | 18.1 | 18.1 |
| Approach angle rear [°] | 26.0 | 26.0 | 26.0 | 26.5 | 26.5 | 26.5 |
| Transition angle [°] | 21 | 21 | 21 | 20 | 20 | 20 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | 30 | 30 | 30 |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
