Nissan X-Trail

Date of manufacture

2013 – 2017 (SUV)

Platform

Nissan CMF-C/D

Manufacturing locations

Kanda, Japan

Saint Petersburg, Russia

Dalian, People's Republic of China

Busan (Pusan), South Korea

Samut Prakan, Thailand

Smyrna, USA

Designer

Keisuke Otsuki

Car body style

SUV

Date of manufacture

2013 – 2017

Internal designation

T32

Engine size

Petrol

1.6 DIG-T

Diesel

1.6 dCi

1.6 dCi All Mode 4x4‐i

2.0 dCi

2.0 dCi All Mode 4x4-i

Euro NCAP

Technical data

SUV

	1.6 DIG-T	1.6 dCi	1.6 dCi	1.6 dCi All Mode 4x4‐i	2.0 dCi	2.0 dCi All Mode 4x4-i
Date of sale	-	-	-	-	from 2016 to	from 2016 to
Engine type	Ignition supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1618	1598	1598	1598	1995	1995
Maximum output / speed [kW/min-1]	120/5600	96/4000	96/4000	96/4000	130/3750	130/3750
Maximum torque [Nm/min-1]	240/2000-4000	320/1750	320/1750	320/1750	380/2000	380/2000
Bore and stroke [mm x mm]	79,7 x 81,1	80,0 x 79,5	80,0 x 79,5	80,0 x 79,5	84.0 x 90.0	84.0 x 90.0
Compression ratio	10,5:1	15,4:1	15,4:1	15,4:1	15,6:1	15,6:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake and exhaust valves CVTC start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system

Drive axle	Front	Front	Front	4x4	Front	4x4
Gearbox	6 gear manual	6 gear manual	1 gear automatic	6 gear manual	1 gear automatic	6 gear manual
Drive specifications	-	-	automatic gearbox Xtronic with one variable ratio	automatically controlled all-wheel drive All Mode 4x4‐i	automatic gearbox Xtronic with one variable ratio	automatically controlled all-wheel drive All Mode 4x4-i

Top speed [km/h]	200	188	180	186	199	204
Acceleration 0–100 km/h [s]	9.7	10.5	11.4	11.0	9.6	9.4
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	7.9	5.7	5.8	6.2	6.2	6.3
Out of town [l]	5.3	4.5	4.7	4.8	5.3	5.2
Combined [l]	6.2	4.9	5.1	5.3	5.6	5.6
CO2 emissions [g/km]	145	129	135	139	148	149

Emission standard	EU6	EU5-EU6	EU5-EU6	EU5-EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1430-1447	1500-1550	1540-1600	1580-1615	1620-1700	1625-1720
Overall weight [kg]	2050-2210	2085-2260	2135-2310	2150-2320	2170-2330	2190-2350
Maximum trailer weight unbraked/braked [kg]	750/1800	750/2000	750/1500	750/2000	750/1650	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	1190/1230	1180/1260
Maximum vertical load on the tow bar [kg]	75	100	75	100	75	100
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	550	550	550	550	550	550
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1982	-/1982	-/1982	-/1982	-/1982	-/1982
Boot length [mm]	935	935	935	935	935	935
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-/1142	-/1142	-/1142	-/1142	-/1142	-/1142
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5 or 7	5 or 7	5 or 7	5 or 7	5 or 7	5 or 7
Fuel tank volume [l]	60	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17
Tyre dimensions rear	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17
Wheel size front	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Wheel size rear	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.2/-	11.2/-	11.2/-	11.2/-	11.2/-	11.2/-

Overall length [mm]	4643	4643	4643	4643	4643	4643
Overall width without/including mirrors [mm]	1820/-	1820/-	1820/-	1820/-	1820/-	1820/-
Overall height [mm]	1695	1695	1695	1695	1695	1695
Wheelbase [mm]	2706	2706	2706	2706	2706	2706
Front wheel track [mm]	1575	1575	1575	1575	1575	1575
Rear wheel track [mm]	1575	1575	1575	1575	1575	1575
Forward overhang [mm]	940	940	940	940	940	940
Rear overhang [mm]	995	995	995	995	995	995
Clearance [mm]	210	210	210	210	210	210
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	18.1	18.1	18.1	18.1	18.1	18.1
Approach angle rear [°]	26.5	26.5	26.5	26.5	26.5	26.5
Transition angle [°]	20	20	20	20	20	20
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	30	30	30	30	30	30

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.0 dCi All Mode 4x4-i
Date of sale	from 2016 to
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	1995
Maximum output / speed [kW/min-1]	130/3750
Maximum torque [Nm/min-1]	380/2000
Bore and stroke [mm x mm]	84.0 x 90.0
Compression ratio	15,6:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbo-supercharged particulate filter start&stop system

Drive axle	4x4
Gearbox	1 gear automatic
Drive specifications	automatically controlled all-wheel drive All Mode 4x4-i automatic gearbox Xtronic with one variable ratio

Top speed [km/h]	196
Acceleration 0–100 km/h [s]	10.0
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	6.6
Out of town [l]	5.6
Combined [l]	6.0
CO2 emissions [g/km]	158

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1460-1570
Overall weight [kg]	2050-2210
Maximum trailer weight unbraked/braked [kg]	750/1650
Maximum front/rear axle load [kg]	1035/1090
Maximum vertical load on the tow bar [kg]	75
Maximum load on roof/carrier [kg]	100/-

Boot volume [l]	550
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1982
Boot length [mm]	935
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-/1142
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5 or 7
Fuel tank volume [l]	60
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	multilink
Tyre dimensions front	225/65 R17
Tyre dimensions rear	225/65 R17
Wheel size front	7.0J x 17
Wheel size rear	7.0J x 17
Brake dimensions front	-
Brake dimensions rear	-
Steering	Rack & pinion with electric power steering m
Number of steering wheel turns	-
Turning diameter track/circumference [m]	11.2/-

Overall length [mm]	4643
Overall width without/including mirrors [mm]	1820/-
Overall height [mm]	1695
Wheelbase [mm]	2706
Front wheel track [mm]	1575
Rear wheel track [mm]	1575
Forward overhang [mm]	940
Rear overhang [mm]	995
Clearance [mm]	210
Wading depth [mm]	-
Approach angle front [°]	18.1
Approach angle rear [°]	26.5
Transition angle [°]	20
Climbing rate [°]	-
Maximum side tilt [°]	30

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Nissan X-Trail T32 2016 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
