Nissan Qashqai

Date of manufacture

6/2021 – to this day (Medium SUV)

Platform

Nissan CMF-C

Manufacturing locations

Sunderland, United Kingdom

Designer

Car body style

Medium SUV

Date of manufacture

6/2021 – to this day

Internal designation

J12

Engine size

DIG-T 140

DIG-T 158

DIG-T 158 4WD

Euro NCAP

Technical data

Medium SUV

	DIG-T 140	DIG-T 158	DIG-T 158	DIG-T 158 4WD
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1332	1332	1332	1332
Maximum output / speed [kW/min-1]	103/5000	116/5500	116/5500	116/5500
Maximum torque [Nm/min-1]	240/1650-4000 6 el.	260/1800-4000 6 el.	270/1800-3750 6 el.	270/1800-3750 6 el.
Bore and stroke [mm x mm]	72.2 x 81.35	72.2 x 81.35	72.2 x 81.35	72.2 x 81.35
Compression ratio	10.5:1	10.5:1	10.5:1	10.5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	Mild Hybrid direct injection turbo-supercharged variable valve timing CVTC Gasoline Particulate Filter start&stop system	Mild Hybrid direct injection turbo-supercharged variable valve timing CVTC Gasoline Particulate Filter start&stop system	Mild Hybrid direct injection turbo-supercharged variable valve timing CVTC Gasoline Particulate Filter start&stop system	Mild Hybrid direct injection turbo-supercharged variable valve timing CVTC Gasoline Particulate Filter start&stop system

Drive axle	Front	Front	Front	4x4
Gearbox	6 gear manual	6 gear manual	1 gear automatic	1 gear automatic
Drive specifications	-	-	automatic gearbox Xtronic with one variable ratio	automatically controlled all-wheel drive automatic gearbox Xtronic with one variable ratio

Top speed [km/h]	196	206	199	198
Acceleration 0–100 km/h [s]	10.2	9.5	9.2	9.9
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	7.0	6.9	6.4	7.3
Out of town [l]	5.0	4.9	4.9	5.5
Combined [l]	5.8	5.6	5.5	6.2
CO2 emissions [g/km]	131	128	125	140

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

System voltage [V]	12	12	12	12
Battery type and capacity	Lithium-Ionen-Akkumulator, - kWh	Lithium-Ionen-Akkumulator, - kWh	Lithium-Ionen-Akkumulator, - kWh	Lithium-Ionen-Akkumulator, - kWh
Range with fully charged battery [km]	-	-	-	-
Charging time	-	-	-	-
Number of modules/cells	-	-	-	-
Battery weight [kg]	-	-	-	-
Charger	-	-	-	-

Standby weight [kg]	1405-1534	1422-1541	1468-1586	1577-1645
Overall weight [kg]	1935	1935	1985	2040
Maximum trailer weight unbraked/braked [kg]	700/1400	700/1650	725/1800	750/1800
Maximum front/rear axle load [kg]	1030/1060	1030/1060	1080/1060	1090/1070
Maximum vertical load on the tow bar [kg]	100	100	100	100
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-

Boot volume [l]	461	461	461	461
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1593	-/1593	-/1593	-/1593
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	55	55	55	55
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	multilink
Tyre dimensions front	215/65 R17	215/65 R17	215/65 R17	215/65 R17
Tyre dimensions rear	215/65 R17	215/65 R17	215/65 R17	215/65 R17
Wheel size front	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Wheel size rear	7.0J x 17	7.0J x 17	7.0J x 17	7.0J x 17
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Electric variable power steering	Electric variable power steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	11.1/-	11.1/-	11.1/-	11.1/-

Overall length [mm]	4425	4425	4425	4425
Overall width without/including mirrors [mm]	1835/2084	1835/2084	1835/2084	1835/2084
Overall height [mm]	1625	1625	1625	1625
Wheelbase [mm]	2665	2665	2665	2665
Front wheel track [mm]	1580	1580	1580	1580
Rear wheel track [mm]	1580	1580	1580	1580
Forward overhang [mm]	918	918	918	918
Rear overhang [mm]	845	845	845	845
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Nissan Qashqai J12 2022 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
