Nissan Note

Date of manufacture

9/2013 – 2017 (Five-door hatchback)

Platform

Nissan V

Manufacturing locations

Yokosuka, Japan

Kanda, Japan

Sunderland, United Kingdom

Aguascalientes, Mexico

Samut Prakan, Thailand

Designer

Atsushi Maeda

Car body style

Five-door hatchback

Date of manufacture

9/2013 – 2017

Internal designation

E12

Engine size

Petrol

1.2

1.2 DIG-S

Diesel

1.5 dCi

Euro NCAP

Technical data

Five-door hatchback

	1.2	1.2 DIG-S	1.2 DIG-S	1.5 dCi
Date of sale	-	from to 2016	from to 2016	from to 2016
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	3/12	3/12	3/12	4/8
Engine displacement [cm³]	1198	1198	1198	1461
Maximum output / speed [kW/min-1]	59/6000	72/5600	72/5600	66/4000
Maximum torque [Nm/min-1]	110/4000	147/4400	147/4400	200/1750
Bore and stroke [mm x mm]	78,0x83,6	78,0x83,6	78,0x83,6	76,0x80,5
Compression ratio	10,7:1	12,0:1	12,0:1	15,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing CVTC start&stop system	direct injection supercharging by mechanical compressor variable valve timing CVTC start&stop system	direct injection supercharging by mechanical compressor variable valve timing CVTC start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	1 gear manual	5 gear manual
Drive specifications	-	-	automatic gearbox with one variable ratio XTRONIC CVT	-

Top speed [km/h]	170	181	172	179
Acceleration 0–100 km/h [s]	13.7	11.7	12.2	11.9
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5.9	5.2	6.1	4.2
Out of town [l]	4.0	3.7	4.7	3.2
Combined [l]	4.7	4.3	5.2	3.6
CO2 emissions [g/km]	109	99	119	92

Emission standard	EU5-EU6	EU5	EU5	EU5-EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1036	1118	1137	1129
Overall weight [kg]	1510	1565	1585	1615
Maximum trailer weight unbraked/braked [kg]	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-

Boot volume [l]	295-381	295-381	295-381	295-381
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1465	-/1465	-/1465	-/1465
Boot length [mm]	725	725	725	725
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-/1202	-/1202	-/1202	-/1202
Boot height to headliner/ceiling [mm]	-/858	-/858	-/858	-/858
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	41	41	41	41
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.3	0.3	0.3	0.3
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Wheel size front	15x5.5J	15x5.5J	15x5.5J	15x5.5J
Wheel size rear	15x5.5J	15x5.5J	15x5.5J	15x5.5J
Brake dimensions front	260x22	260x22	260x22	260x22
Brake dimensions rear	-	-	-	-
Steering	Electric variable power steering	Electric variable power steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.7/-	10.7/-	10.7/-	10.7/-

Overall length [mm]	4100	4100	4100	4100
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1530	1530	1530	1530
Wheelbase [mm]	2600	2600	2600	2600
Front wheel track [mm]	1480	1480	1480	1480
Rear wheel track [mm]	1485	1485	1485	1485
Forward overhang [mm]	825	825	825	825
Rear overhang [mm]	675	675	675	675
Clearance [mm]	131	131	131	131
Wading depth [mm]	-	-	-	-
Approach angle front [°]	19	19	19	19
Approach angle rear [°]	31	31	31	31
Transition angle [°]	15.8	15.8	15.8	15.8
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
