Nissan Note

Date of manufacture

1/2006 – 2008 (MPV)

Platform

Nissan B

Manufacturing locations

Sunderland, United Kingdom

Yokosuka, Japan

Designer

Car body style

MPV

Date of manufacture

1/2006 – 2008

Internal designation

E11

Engine size

Petrol

1.4

1.6

Diesel

1.5 dCi

Euro NCAP

Technical data

MPV

	1.4	1.6	1.6	1.5 dCi	1.5 dCi
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/8	4/8
Engine displacement [cm³]	1386	1598	1598	1461	1461
Maximum output / speed [kW/min-1]	65/5200	81/6000	81/6000	63/3750	76/4000
Maximum torque [Nm/min-1]	128/3200	153/4400	153/4400	200/1900	240/2000
Bore and stroke [mm x mm]	73,0 x 82,8	78,0 x 83,6	78,0 x 83,6	76,0 x 80,5	76,0 x 80,5
Compression ratio	-	-	-	15,2:1	15,2:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	-	variable valve timing CVTC	variable valve timing CVTC	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged particulate filter

Drive axle	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	4 gear automatic	5 gear manual	6 gear manual
Drive specifications	-	-	automatic gearbox	-	-

Top speed [km/h]	165	183	174	168	180
Acceleration 0–100 km/h [s]	13.1	10.7	11.7	13.0	11.1
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	7.9	8.5	9.1	5.7	5.9
Out of town [l]	5.3	5.5	5.4	4.5	4.8
Combined [l]	6.3	6.6	6.8	4.9	5.1
CO2 emissions [g/km]	150	156	159	129	136

Emission standard	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1092	1107	1131	1165	1203
Overall weight [kg]	1546	1560	1580	1610	1641
Maximum trailer weight unbraked/braked [kg]	510/945	510/1000	510/750	510/900	510/900
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-	50/-

Boot volume [l]	280-437	280-437	280-437	280-437	280-437
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1332	-/1332	-/1332	-/1332	-/1332
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	46	46	46	46	46
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	175/65 R15	175/65 R15	175/65 R15	175/65 R15	175/65 R15
Tyre dimensions rear	175/65 R15	175/65 R15	175/65 R15	175/65 R15	175/65 R15
Wheel size front	5.5 x 15	5.5 x 15	5.5 x 15	5.5 x 15	5.5 x 15
Wheel size rear	5.5 x 15	5.5 x 15	5.5 x 15	5.5 x 15	5.5 x 15
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	11.0/-	11.0/-	11.0/-	11.0/-	11.0/-

Overall length [mm]	4083	4083	4083	4083	4083
Overall width without/including mirrors [mm]	1691/-	1691/-	1691/-	1691/-	1690/-
Overall height [mm]	1550	1550	1550	1550	1550
Wheelbase [mm]	2600	2600	2600	2600	2600
Front wheel track [mm]	1470	1470	1470	1470	1470
Rear wheel track [mm]	1460	1460	1460	1460	1460
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
