Mitsubishi Outlander

Date of manufacture

2015 – 2018 (SUV)

Platform

Mitsubishi GS platform

Manufacturing locations

Okazaki, Japan

Sakahogi, Japan

Changsha, People's Republic of China

Kaluga, Russia

Laem Chabang, Thailand

Designer

Car body style

SUV

after upgrade (facelift) (I.)

Date of manufacture

2015 – 2018

Internal designation

Engine size

Petrol

2.0 MIVEC

Petrol + Electric

2.0 MIVEC PHEV

Diesel

2.2 DI-D

Euro NCAP

Test year 2012

pre-facelift version (2012)

pre-facelift version (2013, Outlander PHEV)

Technical data

SUV

	2.0 MIVEC	2.0 MIVEC	2.0 MIVEC PHEV	2.2 DI-D	2.2 DI-D	2.2 DI-D
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol + Electric	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1998	1998	1998	2268	2268	2268
Maximum output / speed [kW/min-1]	110/6000	110/6000	89/4500 combustion 60 el. 60 el. 149 total	110/3500	110/3500	132/3460
Maximum torque [Nm/min-1]	195/4200	195/4200	190/4500 combustion 137 el. 195 el.	380/1750-2500	360/1500-2750	430/2070
Bore and stroke [mm x mm]	86,0 x 86,0	86,0 x 86,0	86,0 x 86,0	86,0 x 97,6	86,0 x 97,6	86,0 x 97,6
Compression ratio	10,5:1	10,5:1	10,5:1	14,9:1	14,9:1	14,9:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable intake valve timing and lift MIVEC start&stop system AS&G	variable intake valve timing and lift MIVEC start&stop system AS&G	Plug‐in Hybrid two electric synchronous motors with permanent magnet variable timing of intake valves MIVEC brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	Front	4x4	4x4	4x4	4x4	4x4
Gearbox	5 gear manual	6 gear automatic	1 gear manual	6 gear manual	6 gear automatic	6 gear manual
Drive specifications	-	all-wheel drive Multi Select automatic gearbox INVECS-III with one variable ratio (6 of virtual gears)	all-wheel drive Twin Motor 4WD (one engine on the front axle and one on the rear) with S‐AWC system constant ratio gearbox	all-wheel drive Multi Select	all-wheel drive Multi Select automatic gearbox	all-wheel drive Multi Select

Top speed [km/h]	190	190	170	200	190	203
Acceleration 0–100 km/h [s]	10.6	12.0	11.0	10.2	11.6	9.1
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	8.4	7.6	-	6.2	6.9	7.6
Out of town [l]	5.7	5.8	-	4.8	5.2	4.8
Combined [l]	6.7	6.4	1.8 [13.4 kWh]	5.3	5.8	5.9
CO2 emissions [g/km]	155	149	42	139	154	154

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	-	-	-	-	-	-
Battery type and capacity	-	-	Lithium-Ionen-Akkumulator, 12 kWh	-	-	-
Range with fully charged battery [km]	-	-	52	-	-	-
Charging time	-	-	to 100%, 5 hodiny, charger 230V/10A to 80%, 0:25 hodiny, charger DC CHAdeMO	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1470	1590	1920	1640	1685	1640
Overall weight [kg]	1985	2070-2170	2340	2260	2260	2260
Maximum trailer weight unbraked/braked [kg]	735/1600	750/1600	750/1500	750/2000	750/2000	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	-	80/-	80/-	80/-

Boot volume [l]	477-591	477-591	477-591	477-591	477-591	477-591
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1608	-/1608	-/1590	-/1608	-/1608	-/1608
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5-7	5-7	5	5-7	5-7	5-7
Fuel tank volume [l]	63	60	45	60	60	60
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.33	0.33	0.33	0.33	0.33	0.33
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar	multilink, coil springs, stabiliser bar
Tyre dimensions front	215/70 R16 100H	215/70 R16 100H	225/55 R18 97H	215/70 R16 100H	225/55 R18 97H	215/70 R16 100H
Tyre dimensions rear	215/70 R16 100H	215/70 R16 100H	225/55 R18 97H	215/70 R16 100H	225/55 R18 97H	215/70 R16 100H
Wheel size front	6.5J x 16 ET38	6.5J x 16 ET38	7.0J x 18 ET38	6.5J x 16 ET38	7.0J x 18 ET38	6.5J x 16 ET38
Wheel size rear	6.5J x 16 ET38	6.5J x 16 ET38	7.0J x 18 ET38	6.5J x 16 ET38	7.0J x 18 ET38	6.5J x 16 ET38
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.6/-	10.6/-	10.6/-	10.6/-	10.6/-	10.6/-

Overall length [mm]	4695	4695	4695	4695	4695	4695
Overall width without/including mirrors [mm]	1810/-	1810/-	1810/-	1810/-	1810/-	1810/-
Overall height [mm]	1680	1680	1710	1680	1680	1680
Wheelbase [mm]	2670	2670	2670	2670	2670	2670
Front wheel track [mm]	1540	1540	1540	1540	1540	1540
Rear wheel track [mm]	1540	1540	1540	1540	1540	1540
Forward overhang [mm]	990	990	990	990	990	990
Rear overhang [mm]	1030	1030	1030	1030	1030	1030
Clearance [mm]	190	190	190	190	190	190
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	21	21	21	21	21	21
Approach angle rear [°]	21	21	22.5	21	21	21
Transition angle [°]	21	21	19	21	21	21
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.2 DI-D
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	2268
Maximum output / speed [kW/min-1]	132/3870
Maximum torque [Nm/min-1]	390/1870
Bore and stroke [mm x mm]	86,0 x 97,6
Compression ratio	14,9:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4
Gearbox	6 gear automatic
Drive specifications	all-wheel drive Multi Select automatic gearbox

Top speed [km/h]	193
Acceleration 0–100 km/h [s]	10.1
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	7.8
Out of town [l]	5.5
Combined [l]	6.3
CO2 emissions [g/km]	167

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1685
Overall weight [kg]	2260
Maximum trailer weight unbraked/braked [kg]	750/2000
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	80/-

Boot volume [l]	477-591
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1608
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5-7
Fuel tank volume [l]	60
AdBlue tank volume [l]	-
Air resistance [Cd]	0.33
Front suspension	MacPherson, coil springs
Rear suspension	multilink, coil springs, stabiliser bar
Tyre dimensions front	225/55 R18 97H
Tyre dimensions rear	225/55 R18 97H
Wheel size front	7.0J x 18 ET38
Wheel size rear	7.0J x 18 ET38
Brake dimensions front	-
Brake dimensions rear	-
Steering	Rack & pinion with electric power steering m
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.6/-

Overall length [mm]	4695
Overall width without/including mirrors [mm]	1810/-
Overall height [mm]	1680
Wheelbase [mm]	2670
Front wheel track [mm]	1540
Rear wheel track [mm]	1540
Forward overhang [mm]	990
Rear overhang [mm]	1030
Clearance [mm]	190
Wading depth [mm]	-
Approach angle front [°]	21
Approach angle rear [°]	21
Transition angle [°]	21
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Mitsubishi Outlander ZJ facelift 2015 interior

Mitsubishi Outlander ZJ facelift 2016 front seats

Mitsubishi Outlander ZJ PHEV facelift 2015 boot
