Mini One & Cooper Clubman
Date of manufacture
2019 – to this day (Estate)
Platform
-
Manufacturing locations
Oxford, United Kingdom
Designer
-
Tags
A-segment
The new body style of the Mini One & Cooper Clubman has been manufactured in the United Kingdom since 2019. The engine range includes petrol and diesel engines, the most powerful variant being the John Cooper Work Clubman with 225 kW and a top speed of 250 km/h. It accelerates from 0-100 km/h in 4.9 seconds. The most economical variant is the One D, which has a fuel consumption of 4.2 l/100 km and CO2 emissions of 110 g/km. The boot has a capacity of 360 l. In 2015, the Mini underwent EURONCAP safety tests and received a rating of 4 out of 5.
Car body style
Estate
after upgrade (facelift)
Date of manufacture
2019 – to this dayInternal designation
F54Technical data
Estate
One | One | Cooper | Cooper | |
---|---|---|---|---|
Date of sale | - | - | - | - |
Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 |
Engine displacement [cm³] | 1499 | 1499 | 1499 | 1499 |
Maximum output / speed [kW/min-1] | 75/3900-6500 | 75/3900-6500 | 100/4500-6500 | 100/4500-6500 |
Maximum torque [Nm/min-1] | 190/1380-3600 | 190/1380-3600 | 220/1500-4100 | 220/1500-4100 |
Bore and stroke [mm x mm] | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 |
Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 |
Oil volume [l] | 4.25 | 4.25 | 4.25 | 4.25 |
Coolant volume [l] | - | - | - | - |
Technical specifications |
|
|
|
|
Drive axle | Front | Front | Front | Front |
Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
Drive specifications | - |
| - |
|
Top speed [km/h] | 188 | 188 | 206 | 206 |
Acceleration 0–100 km/h [s] | 11.3 | 11.3 | 9.2 | 9.2 |
Acceleration 0–80 km/h [s] | - | - | - | - |
Acceleration 80–120 km/h [s] | 13.3 (5th gear) | - | 10.4 (5th gear) | - |
City [l] | 7.5-7.0 | 6.7 | 7.3-7.0 | 6.8-6.6 |
Out of town [l] | 4.8-4.6 | 4.9-4.8 | 4.8 | 4.7-4.5 |
Combined [l] | 5.8-5.5 | 5.6-5.5 | 5.7-5.6 | 5.5-5.3 |
CO2 emissions [g/km] | 132-125 | 127-124 | 131-127 | 125-120 |
Low speed [l] | - | - | - | - |
Medium speed [l] | - | - | - | - |
High speed [l] | - | - | - | - |
Extra high speed [l] | - | - | - | - |
Combined speed [l] | 6.3-5.0 | 6.4-6.0 | 6.5-6.0 | 6.5-5.9 |
CO2 emissions [g/km] | 143-135 | 145-137 | 148-136 | 147-135 |
Emission standard | EU6d-TEMP - EU6d | EU6d-TEMP - EU6d | EU6d-TEMP - EU6d | EU6d-TEMP - EU6d |
Standard for fuel consumption measurement | - | - | - | - |
Energy class | - | - | - | - |
Stationary vehicle noise [dB] | - | - | - | - |
Driving noise [dB] | - | - | - | - |
Standby weight [kg] | 1405 | 1435 | 1410 | 1435 |
Overall weight [kg] | 1875 | 1900 | 1875 | 1890 |
Maximum trailer weight unbraked/braked [kg] | 680/1100 | 680/1100 | 680/1300 | 680/1300 |
Maximum front/rear axle load [kg] | 960/955 | 985/950 | 960/955 | 990/950 |
Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 |
Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- |
Boot volume [l] | 360 | 360 | 360 | 360 |
Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1250 | -/1250 | -/1250 | -/1250 |
Boot length [mm] | - | - | - | - |
Boot length with rear seats folded [mm] | - | - | - | - |
Boot width between wheels/max [mm] | - | - | - | - |
Boot height to headliner/ceiling [mm] | - | - | - | - |
Loading edge height [mm] | - | - | - | - |
Height of the open boot door [mm] | - | - | - | - |
Boot opening height [mm] | - | - | - | - |
Boot opening width min/max [mm] | - | - | - | - |
Number of doors | 5 | 5 | 5 | 5 |
Number of seats | 5 | 5 | 5 | 5 |
Fuel tank volume [l] | 48 | 48 | 48 | 48 |
AdBlue tank volume [l] | - | - | - | - |
Air resistance [Cd] | 0.32 | 0.33 | 0.32 | 0.33 |
Front suspension | MacPherson | MacPherson | MacPherson | MacPherson |
Rear suspension | multilink | multilink | multilink | multilink |
Tyre dimensions front | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W |
Tyre dimensions rear | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W |
Wheel size front | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 |
Wheel size rear | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 |
Brake dimensions front | - | - | - | - |
Brake dimensions rear | - | - | - | - |
Steering | - | - | - | - |
Number of steering wheel turns | - | - | - | - |
Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 11.3/- | 11.3/- |
Overall length [mm] | 4253 | 4253 | 4253 | 4253 |
Overall width without/including mirrors [mm] | 1800/- | 1800/- | 1800/- | 1800/- |
Overall height [mm] | 1441 | 1441 | 1441 | 1441 |
Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 |
Front wheel track [mm] | 1564 | 1564 | 1564 | 1564 |
Rear wheel track [mm] | 1565 | 1565 | 1565 | 1565 |
Forward overhang [mm] | 788 | 788 | 788 | 788 |
Rear overhang [mm] | 795 | 795 | 795 | 795 |
Clearance [mm] | 141 | 141 | 141 | 141 |
Wading depth [mm] | - | - | - | - |
Approach angle front [°] | - | - | - | - |
Approach angle rear [°] | - | - | - | - |
Transition angle [°] | - | - | - | - |
Climbing rate [°] | - | - | - | - |
Maximum side tilt [°] | - | - | - | - |
Headroom front [mm] | - | - | - | - |
Headroom rear [mm] | - | - | - | - |
Front elbow/shoulder width [mm] | - | - | - | - |
Rear elbow/shoulder width [mm] | - | - | - | - |
Legroom front knees/total [mm] | - | - | - | - |
Legroom rear knees/total [mm] | - | - | - | - |
Cooper S | Cooper S | Cooper S ALL4 | Cooper S | |
---|---|---|---|---|
Date of sale | - | - | - | from to 2020 |
Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 |
Engine displacement [cm³] | 1998 | 1998 | 1998 | 1998 |
Maximum output / speed [kW/min-1] | 120/5000-5500 | 131/5000-6000 | 131/5000-6000 | 141/5000-6000 |
Maximum torque [Nm/min-1] | 280/1350-4200 | 280/1350-4200 | 280/1350-4200 | 280/1350-4600 |
Bore and stroke [mm x mm] | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 |
Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 |
Oil volume [l] | 5.25 | 5.25 | 5.25 | 5.25 |
Coolant volume [l] | - | - | - | - |
Technical specifications |
|
|
|
|
Drive axle | Front | Front | 4x4 | Front |
Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual |
Drive specifications | - |
|
| - |
Top speed [km/h] | 218 | 228 | 228 | 228 |
Acceleration 0–100 km/h [s] | 7.3 | 7.1 | 7.1 | 7.3 |
Acceleration 0–80 km/h [s] | - | - | - | - |
Acceleration 80–120 km/h [s] | 7.8 (5th gear) | - | - | - |
City [l] | - | - | - | 8.9-8.8 |
Out of town [l] | - | - | - | 5.3-5.0 |
Combined [l] | - | - | - | 6.6-6.4 |
CO2 emissions [g/km] | - | - | - | 149-145 |
Low speed [l] | - | - | - | - |
Medium speed [l] | - | - | - | - |
High speed [l] | - | - | - | - |
Extra high speed [l] | - | - | - | - |
Combined speed [l] | 7.1-6.7 | 6.7-6.2 | 7.2-6.8 | - |
CO2 emissions [g/km] | 161-152 | 152-142 | 154-163 | - |
Emission standard | EU6d | EU6d | EU6d | EU6d-TEMP |
Standard for fuel consumption measurement | - | - | - | - |
Energy class | - | - | - | - |
Stationary vehicle noise [dB] | - | - | - | - |
Driving noise [dB] | - | - | - | - |
Standby weight [kg] | 1475 | 1490 | 1575 | - |
Overall weight [kg] | 1920 | 1945 | 2040 | - |
Maximum trailer weight unbraked/braked [kg] | 715/1300 | 720/1300 | 750/1500 | 715/1300 |
Maximum front/rear axle load [kg] | 1000/965 | 1020/960 | 1060/1020 | - |
Maximum vertical load on the tow bar [kg] | 75 | 75 | - | 75 |
Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- |
Boot volume [l] | 360 | 360 | 360 | 360 |
Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1250 | -/1250 | -/1250 | -/1250 |
Boot length [mm] | - | - | - | - |
Boot length with rear seats folded [mm] | - | - | - | - |
Boot width between wheels/max [mm] | - | - | - | - |
Boot height to headliner/ceiling [mm] | - | - | - | - |
Loading edge height [mm] | - | - | - | - |
Height of the open boot door [mm] | - | - | - | - |
Boot opening height [mm] | - | - | - | - |
Boot opening width min/max [mm] | - | - | - | - |
Number of doors | 5 | 5 | 5 | 5 |
Number of seats | 5 | 5 | 5 | 5 |
Fuel tank volume [l] | 48 | 48 | 48 | 48 |
AdBlue tank volume [l] | - | - | - | - |
Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.34 |
Front suspension | MacPherson | MacPherson | MacPherson | MacPherson |
Rear suspension | multilink | multilink | multilink | multilink |
Tyre dimensions front | 225/45 R17 94Y XL | 225/45 R17 94Y XL | 225/45 R17 94Y XL | 225/45 R17 94W XL |
Tyre dimensions rear | 225/45 R17 94Y XL | 225/45 R17 94Y XL | 225/45 R17 94Y XL | 225/45 R17 94W XL |
Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
Brake dimensions front | - | - | - | - |
Brake dimensions rear | - | - | - | - |
Steering | - | - | - | - |
Number of steering wheel turns | - | - | - | - |
Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 11.3/- | 11.3/- |
Overall length [mm] | 4253 | 4253 | 4253 | 4253 |
Overall width without/including mirrors [mm] | 1800/- | 1800/- | 1800/- | 1800/- |
Overall height [mm] | 1441 | 1441 | 1441 | 1441 |
Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 |
Front wheel track [mm] | 1560 | 1560 | 1560 | 1560 |
Rear wheel track [mm] | 1561 | 1561 | 1561 | 1561 |
Forward overhang [mm] | 788 | 788 | 788 | 788 |
Rear overhang [mm] | 795 | 795 | 795 | 795 |
Clearance [mm] | 141 | 141 | 141 | 141 |
Wading depth [mm] | - | - | - | - |
Approach angle front [°] | - | - | - | - |
Approach angle rear [°] | - | - | - | - |
Transition angle [°] | - | - | - | - |
Climbing rate [°] | - | - | - | - |
Maximum side tilt [°] | - | - | - | - |
Headroom front [mm] | - | - | - | - |
Headroom rear [mm] | - | - | - | - |
Front elbow/shoulder width [mm] | - | - | - | - |
Rear elbow/shoulder width [mm] | - | - | - | - |
Legroom front knees/total [mm] | - | - | - | - |
Legroom rear knees/total [mm] | - | - | - | - |
Cooper S | Cooper S ALL4 | John Cooper Work Clubman | One D | |
---|---|---|---|---|
Date of sale | from to 2020 | from to 2020 | - | - |
Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged |
Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 3/12 |
Engine displacement [cm³] | 1998 | 1998 | 1998 | 1496 |
Maximum output / speed [kW/min-1] | 141/5000-6000 | 141/5000-600 | 225/5000-6250 | 85/4000 |
Maximum torque [Nm/min-1] | 280/1350-4600 | 280/1350-4600 | 450/1800-4500 | 270/1750-2250 |
Bore and stroke [mm x mm] | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 | 84,0 x 90,0 |
Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 16,5:1 |
Oil volume [l] | 5.25 | 5.25 | - | 4.8 |
Coolant volume [l] | - | - | - | - |
Technical specifications |
|
|
|
|
Drive axle | Front | 4x4 | 4x4 | Front |
Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual |
Drive specifications |
|
|
| - |
Top speed [km/h] | 228 | 225 | 250 | 192 |
Acceleration 0–100 km/h [s] | 7.2 | 6.9 | 4.9 | 10.8 |
Acceleration 0–80 km/h [s] | - | - | - | - |
Acceleration 80–120 km/h [s] | - | - | - | - |
City [l] | 6.7-6.6 | 7.5-7.4 | - | 4.9-4.8 |
Out of town [l] | 5.0-4.9 | 5.6-5.4 | - | 3.9-3.7 |
Combined [l] | 5.7-5.5 | 6.3-6.1 | - | 4.3-4.1 |
CO2 emissions [g/km] | 129-125 | 143-139 | - | 112-107 |
Low speed [l] | - | - | - | - |
Medium speed [l] | - | - | - | - |
High speed [l] | - | - | - | - |
Extra high speed [l] | - | - | - | - |
Combined speed [l] | - | - | 7.9-7.4 | - |
CO2 emissions [g/km] | - | - | 180-169 | - |
Emission standard | EU6d-TEMP | EU6d-TEMP | EU6d | EU6d-TEMP |
Standard for fuel consumption measurement | - | - | - | - |
Energy class | - | - | - | - |
Stationary vehicle noise [dB] | - | - | - | - |
Driving noise [dB] | - | - | - | - |
Standby weight [kg] | - | - | 1630 | - |
Overall weight [kg] | - | - | 2040 | - |
Maximum trailer weight unbraked/braked [kg] | 720/1300 | 750/1500 | - | 695/1200 |
Maximum front/rear axle load [kg] | - | - | 1090/1025 | - |
Maximum vertical load on the tow bar [kg] | 75 | - | - | 75 |
Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- |
Boot volume [l] | 360 | 360 | 360 | 360 |
Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1250 | -/1250 | -/1250 | -/1250 |
Boot length [mm] | - | - | - | - |
Boot length with rear seats folded [mm] | - | - | - | - |
Boot width between wheels/max [mm] | - | - | - | - |
Boot height to headliner/ceiling [mm] | - | - | - | - |
Loading edge height [mm] | - | - | - | - |
Height of the open boot door [mm] | - | - | - | - |
Boot opening height [mm] | - | - | - | - |
Boot opening width min/max [mm] | - | - | - | - |
Number of doors | 5 | 5 | 5 | 5 |
Number of seats | 5 | 5 | 5 | 5 |
Fuel tank volume [l] | 48 | 48 | 48 | 48 |
AdBlue tank volume [l] | - | - | - | - |
Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.31 |
Front suspension | MacPherson | MacPherson | MacPherson | MacPherson |
Rear suspension | multilink | multilink | multilink | multilink |
Tyre dimensions front | 225/45 R17 94W XL | 225/45 R17 94W XL | 225/40 ZR18 92Y XL | 205/55 R16 91W |
Tyre dimensions rear | 225/45 R17 94W XL | 225/45 R17 94W XL | 225/40 ZR18 92Y XL | 205/55 R16 91W |
Wheel size front | 7.5J x 17 | 7.5J x 17 | 8.0J x 18 | 7.0J x 16 |
Wheel size rear | 7.5J x 17 | 7.5J x 17 | 8.0J x 18 | 7.0J x 16 |
Brake dimensions front | - | - | - | - |
Brake dimensions rear | - | - | - | - |
Steering | - | - | - | - |
Number of steering wheel turns | - | - | - | - |
Turning diameter track/circumference [m] | 11.3/- | 11.3/- | - | 11.3/- |
Overall length [mm] | 4253 | 4253 | 4253 | 4253 |
Overall width without/including mirrors [mm] | 1800/- | 1800/- | 1800/- | 1800/- |
Overall height [mm] | 1441 | 1441 | 1441 | 1441 |
Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 |
Front wheel track [mm] | 1560 | 1560 | 1560 | 1564 |
Rear wheel track [mm] | 1561 | 1561 | 1561 | 1565 |
Forward overhang [mm] | 788 | 788 | 788 | 788 |
Rear overhang [mm] | 795 | 795 | 795 | 795 |
Clearance [mm] | 141 | 141 | 141 | 141 |
Wading depth [mm] | - | - | - | - |
Approach angle front [°] | - | - | - | - |
Approach angle rear [°] | - | - | - | - |
Transition angle [°] | - | - | - | - |
Climbing rate [°] | - | - | - | - |
Maximum side tilt [°] | - | - | - | - |
Headroom front [mm] | - | - | - | - |
Headroom rear [mm] | - | - | - | - |
Front elbow/shoulder width [mm] | - | - | - | - |
Rear elbow/shoulder width [mm] | - | - | - | - |
Legroom front knees/total [mm] | - | - | - | - |
Legroom rear knees/total [mm] | - | - | - | - |
One D | Cooper D | Cooper D | Cooper SD | |
---|---|---|---|---|
Date of sale | - | - | - | from to 2020 |
Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 |
Engine displacement [cm³] | 1496 | 1995 | 1995 | 1995 |
Maximum output / speed [kW/min-1] | 85/4000 | 110/4000 | 110/4000 | 140/4000 |
Maximum torque [Nm/min-1] | 270/1750-2250 | 350/1750-2500 | 350/1750-2500 | 400/1750-2500 |
Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 |
Compression ratio | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 |
Oil volume [l] | 4.8 | 5.5 | 5.5 | 5.5 |
Coolant volume [l] | - | - | - | - |
Technical specifications |
|
|
|
|
Drive axle | Front | Front | Front | Front |
Gearbox | 6 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic |
Drive specifications |
| - |
|
|
Top speed [km/h] | 192 | 212 | 212 | 225 |
Acceleration 0–100 km/h [s] | 10.8 | 8.9 | 8.6 | 7.6 |
Acceleration 0–80 km/h [s] | - | - | - | - |
Acceleration 80–120 km/h [s] | - | 8.6 (5th gear) | - | - |
City [l] | 4.6-4.4 | 5.1-5.0 | 4.9-4.7 | 4.9-4.8 |
Out of town [l] | 3.9-3.8 | 4.1-3.8 | 4.2-4.0 | 4.1-4.0 |
Combined [l] | 4.2-4.0 | 4.4-4.3 | 4.4-4.2 | 4.5-4.3 |
CO2 emissions [g/km] | 110-105 | 116-113 | 116-111 | 116-113 |
Low speed [l] | - | - | - | - |
Medium speed [l] | - | - | - | - |
High speed [l] | - | - | - | - |
Extra high speed [l] | - | - | - | - |
Combined speed [l] | - | 5.4-4.9 | 5.6-5.2 | - |
CO2 emissions [g/km] | - | 140-129 | 145-136 | - |
Emission standard | EU6d-TEMP | EU6d-TEMP - EU6d | EU6d-TEMP - EU6d | EU6d-TEMP |
Standard for fuel consumption measurement | - | - | - | - |
Energy class | - | - | - | - |
Stationary vehicle noise [dB] | - | - | - | - |
Driving noise [dB] | - | - | - | - |
Standby weight [kg] | - | 1500 | 1545 | - |
Overall weight [kg] | - | 1975 | 2010 | - |
Maximum trailer weight unbraked/braked [kg] | 700/1200 | 695/1300 | 695/1300 | 720/1300 |
Maximum front/rear axle load [kg] | - | 1025/985 | 1070/980 | - |
Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 |
Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- |
Boot volume [l] | 360 | 360 | 360 | 360 |
Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1250 | -/1250 | -/1250 | -/1250 |
Boot length [mm] | - | - | - | - |
Boot length with rear seats folded [mm] | - | - | - | - |
Boot width between wheels/max [mm] | - | - | - | - |
Boot height to headliner/ceiling [mm] | - | - | - | - |
Loading edge height [mm] | - | - | - | - |
Height of the open boot door [mm] | - | - | - | - |
Boot opening height [mm] | - | - | - | - |
Boot opening width min/max [mm] | - | - | - | - |
Number of doors | 5 | 5 | 5 | 5 |
Number of seats | 5 | 5 | 5 | 5 |
Fuel tank volume [l] | 48 | 48 | 48 | 48 |
AdBlue tank volume [l] | - | - | - | - |
Air resistance [Cd] | 0,31-0,32 | 0.31 | 0.31 | 0.33 |
Front suspension | MacPherson | MacPherson | MacPherson | MacPherson |
Rear suspension | multilink | multilink | multilink | multilink |
Tyre dimensions front | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 225/45 R17 94W XL |
Tyre dimensions rear | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 225/45 R17 94W XL |
Wheel size front | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 | 7.5J x 17 |
Wheel size rear | 7.0J x 16 | 7.0J x 16 | 7.0J x 16 | 7.5J x 17 |
Brake dimensions front | - | - | - | - |
Brake dimensions rear | - | - | - | - |
Steering | - | - | - | - |
Number of steering wheel turns | - | - | - | - |
Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 11.3/- | 11.3/- |
Overall length [mm] | 4253 | 4253 | 4253 | 4253 |
Overall width without/including mirrors [mm] | 1800/- | 1800/- | 1800/- | 1800/- |
Overall height [mm] | 1441 | 1441 | 1441 | 1441 |
Wheelbase [mm] | 2670 | 2670 | 2670 | 2670 |
Front wheel track [mm] | 1564 | 1564 | 1564 | 1560 |
Rear wheel track [mm] | 1565 | 1565 | 1565 | 1561 |
Forward overhang [mm] | 788 | 788 | 788 | 788 |
Rear overhang [mm] | 795 | 795 | 795 | 795 |
Clearance [mm] | 141 | 141 | 141 | 141 |
Wading depth [mm] | - | - | - | - |
Approach angle front [°] | - | - | - | - |
Approach angle rear [°] | - | - | - | - |
Transition angle [°] | - | - | - | - |
Climbing rate [°] | - | - | - | - |
Maximum side tilt [°] | - | - | - | - |
Headroom front [mm] | - | - | - | - |
Headroom rear [mm] | - | - | - | - |
Front elbow/shoulder width [mm] | - | - | - | - |
Rear elbow/shoulder width [mm] | - | - | - | - |
Legroom front knees/total [mm] | - | - | - | - |
Legroom rear knees/total [mm] | - | - | - | - |
Cooper SD ALL4 | ||||
---|---|---|---|---|
Date of sale | from to 2020 | |||
Engine type | Diesel supercharged | |||
Number of cylinders/valves | 4/16 | |||
Engine displacement [cm³] | 1995 | |||
Maximum output / speed [kW/min-1] | 140/4000 | |||
Maximum torque [Nm/min-1] | 400/1750-2500 | |||
Bore and stroke [mm x mm] | 84,0 x 90,0 | |||
Compression ratio | 16,5:1 | |||
Oil volume [l] | 5.5 | |||
Coolant volume [l] | - | |||
Technical specifications |
| |||
Drive axle | 4x4 | |||
Gearbox | 8 gear automatic | |||
Drive specifications |
| |||
Top speed [km/h] | 222 | |||
Acceleration 0–100 km/h [s] | 7.4 | |||
Acceleration 0–80 km/h [s] | - | |||
Acceleration 80–120 km/h [s] | - | |||
City [l] | 5.3-5.1 | |||
Out of town [l] | 4.4-4.3 | |||
Combined [l] | 4.7-4.6 | |||
CO2 emissions [g/km] | 124-121 | |||
Emission standard | EU6d-TEMP | |||
Standard for fuel consumption measurement | - | |||
Energy class | - | |||
Stationary vehicle noise [dB] | - | |||
Driving noise [dB] | - | |||
Standby weight [kg] | - | |||
Overall weight [kg] | - | |||
Maximum trailer weight unbraked/braked [kg] | 750/1500 | |||
Maximum front/rear axle load [kg] | - | |||
Maximum vertical load on the tow bar [kg] | 75 | |||
Maximum load on roof/carrier [kg] | 75/- | |||
Boot volume [l] | 360 | |||
Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1250 | |||
Boot length [mm] | - | |||
Boot length with rear seats folded [mm] | - | |||
Boot width between wheels/max [mm] | - | |||
Boot height to headliner/ceiling [mm] | - | |||
Loading edge height [mm] | - | |||
Height of the open boot door [mm] | - | |||
Boot opening height [mm] | - | |||
Boot opening width min/max [mm] | - | |||
Number of doors | 5 | |||
Number of seats | 5 | |||
Fuel tank volume [l] | 48 | |||
AdBlue tank volume [l] | - | |||
Air resistance [Cd] | 0.33 | |||
Front suspension | MacPherson | |||
Rear suspension | multilink | |||
Tyre dimensions front | 225/45 R17 94W XL | |||
Tyre dimensions rear | 225/45 R17 94W XL | |||
Wheel size front | 7.5J x 17 | |||
Wheel size rear | 7.5J x 17 | |||
Brake dimensions front | - | |||
Brake dimensions rear | - | |||
Steering | - | |||
Number of steering wheel turns | - | |||
Turning diameter track/circumference [m] | 11.3/- | |||
Overall length [mm] | 4253 | |||
Overall width without/including mirrors [mm] | 1800/- | |||
Overall height [mm] | 1441 | |||
Wheelbase [mm] | 2670 | |||
Front wheel track [mm] | 1560 | |||
Rear wheel track [mm] | 1561 | |||
Forward overhang [mm] | 788 | |||
Rear overhang [mm] | 795 | |||
Clearance [mm] | 141 | |||
Wading depth [mm] | - | |||
Approach angle front [°] | - | |||
Approach angle rear [°] | - | |||
Transition angle [°] | - | |||
Climbing rate [°] | - | |||
Maximum side tilt [°] | - | |||
Headroom front [mm] | - | |||
Headroom rear [mm] | - | |||
Front elbow/shoulder width [mm] | - | |||
Rear elbow/shoulder width [mm] | - | |||
Legroom front knees/total [mm] | - | |||
Legroom rear knees/total [mm] | - |
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
