Mercedes-Benz SL
Date of manufacture
2012 – 2015 (Roadster)
Platform
-
Manufacturing locations
Bremen, Germany
Designer
Frank Pfisterer
Mark Fetherston
Tags
S-segment
Convertible
German cars
The Mercedes-Benz SL has been available as a roadster since 2012. The exclusively petrol-powered vehicle is manufactured in Germany and offers the most power in the SL 65 AMG version, which has 463 kW. This allows it to reach a maximum speed of 250 km/h and 0-100 km/h in just 4 seconds. The most economical version is the SL 350 BlueEFFICIENCY, which consumes 6.8 l/100 km and has emissions of 159 g/km. The luggage compartment ranges from 364 to 504 liters.
Car body style
Roadster
Date of manufacture
2012 – 2015Internal designation
R231Technical data
Roadster
| SL 350 BlueEFFICIENCY | SL 400 | SL 500 BlueEFFICIENCY | SL 63 AMG | SL 63 AMG Performance | SL 63 AMG | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 8/32 | 8/32 | 8/32 | 8/32 |
| Engine displacement [cm³] | 3498 | 2996 | 4663 | 5461 | 5461 | 5461 |
| Maximum output / speed [kW/min-1] | 225/6500 | 245/5250-6000 | 320/5250 | 395/5500 | 415/5500 | 430/5500 |
| Maximum torque [Nm/min-1] | 370/3500-5250 | 480/1600-4000 | 700/1800-3500 | 800/2000-4500 | 900/2250-3750 | 900/2250-3750 |
| Bore and stroke [mm x mm] | 92,9 x 86,0 | 88,0 x 82,1 | 92,6 x 86,0 | 98,0 x 90,5 | 98,0 x 90,5 | 98,0 x 90,5 |
| Compression ratio | 12,0:1 | 10,5:1 | 10,5:1 | 10,0:1 | 10,0:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 5.9 | 5.2 | 4.6 | 4.3 | 4.2 | 4.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.3-9.9 | 9.8-10.2 | 12.7-12.8 | 13.9 | 13.9 | 13.9 |
| Out of town [l] | 5.4-6.1 | 5.9-6.2 | 7.0-7.1 | 7.6 | 7.6 | 7.6 |
| Combined [l] | 6.8-7.5 | 7.3-7.7 | 9.1-9.2 | 9.9 | 9.9 | 9.9 |
| CO2 emissions [g/km] | 159-176 | 172-179 | 212-214 | 231 | 231 | 231 |
| Emission standard | EU5 | EU6 | EU5-EU6 | EU5 | EU5 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1685 | 1730 | 1785 | 1845 | 1845 | 1845 |
| Overall weight [kg] | 2065 | 2110 | 2165 | 2180 | 2180 | 2180 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 364–504 | 364–504 | 364–504 | 364–504 | 364–504 | 364–504 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 2 | 2 | 2 | 2 | 2 | 2 |
| Fuel tank volume [l] | 65 | 65 | 65 | 75 | 75 | 75 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.27 | 0.29 | 0.3 | 0.32 | 0.31 | 0.31 |
| Front suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 255/45 R17 | 255/45 R17 | 255/40 R18 | 255/35 R19 | 255/35 R19 | 255/35 R19 |
| Tyre dimensions rear | 255/45 R17 | 255/45 R17 | 285/35 R18 | 285/30 R19 | 285/30 R19 | 285/30 R19 |
| Wheel size front | 8.5J x 17 ET30 | 8.5J x 17 ET30 | 8.5J x 18 ET35.5 | 9.0J x 19 ET27 | 9.0J x 19 ET27 | 9.0J x 19 ET27 |
| Wheel size rear | 8.5J x 17 ET30 | 8.5J x 17 ET30 | 9.5J x 18 ET47.5 | 10.0J x 19 ET48 | 10.0J x 19 ET48 | 10.0J x 19 ET48 |
| Brake dimensions front | 342 x 32 | 342 x 32 | 360 x 36 | 390 x 36 | 390 x 36 | 390 x 36 |
| Brake dimensions rear | 320 x 24 | 320 x 24 | 320 x 24 | 360 x 26 | 360 x 26 | 360 x 26 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.04/- | 11.04/- | 11.04/- | 11.10/- | 11.10/- | 11.10/- |
| Overall length [mm] | 4617 | 4617 | 4617 | 4633 | 4633 | 4633 |
| Overall width without/including mirrors [mm] | 1877/2099 | 1877/2099 | 1877/2099 | 1877/2099 | 1877/2099 | 1877/2099 |
| Overall height [mm] | 1315 | 1315 | 1315 | 1300 | 1300 | 1300 |
| Wheelbase [mm] | 2585 | 2585 | 2585 | 2585 | 2585 | 2585 |
| Front wheel track [mm] | 1600 | 1600 | 1597 | 1621 | 1621 | 1621 |
| Rear wheel track [mm] | 1604 | 1604 | 1600 | 1604 | 1604 | 1604 |
| Forward overhang [mm] | 998 | 998 | 998 | 998 | - | - |
| Rear overhang [mm] | 1029 | 1029 | 1029 | 1029 | - | - |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 958 | 958 | 958 | 958 | 958 | 958 |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1409/1472 | 1409/1472 | 1409/1472 | 1409/1472 | 1409/1472 | 1409/1472 |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| SL 65 AMG | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Ignition supercharged | |||||
| Number of cylinders/valves | 12/36 | |||||
| Engine displacement [cm³] | 5980 | |||||
| Maximum output / speed [kW/min-1] | 463/4800 | |||||
| Maximum torque [Nm/min-1] | 1000/2300-4300 | |||||
| Bore and stroke [mm x mm] | 82,6 x 93,0 | |||||
| Compression ratio | 9,0:1 | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Rear | |||||
| Gearbox | 7 gear automatic | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 250 | |||||
| Acceleration 0–100 km/h [s] | 4.0 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | 17.0 | |||||
| Out of town [l] | 8.4 | |||||
| Combined [l] | 11.6 | |||||
| CO2 emissions [g/km] | 270 | |||||
| Emission standard | EU5-EU6 | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| Standby weight [kg] | 1950 | |||||
| Overall weight [kg] | 2210 | |||||
| Maximum trailer weight unbraked/braked [kg] | - | |||||
| Maximum front/rear axle load [kg] | - | |||||
| Maximum vertical load on the tow bar [kg] | - | |||||
| Maximum load on roof/carrier [kg] | - | |||||
| Boot volume [l] | 364–504 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | |||||
| Boot length [mm] | - | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | - | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 2 | |||||
| Number of seats | 2 | |||||
| Fuel tank volume [l] | 75 | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | 0.32 | |||||
| Front suspension | multilink | |||||
| Rear suspension | multilink | |||||
| Tyre dimensions front | 255/35 R19 | |||||
| Tyre dimensions rear | 285/30 R19 | |||||
| Wheel size front | 9.0J x 19 ET27 | |||||
| Wheel size rear | 10.0J x 19 ET48 | |||||
| Brake dimensions front | 390 x 36 | |||||
| Brake dimensions rear | 360 x 26 | |||||
| Steering | - | |||||
| Number of steering wheel turns | - | |||||
| Turning diameter track/circumference [m] | 11.10/- | |||||
| Overall length [mm] | 4633 | |||||
| Overall width without/including mirrors [mm] | 1877/2099 | |||||
| Overall height [mm] | 1300 | |||||
| Wheelbase [mm] | 2585 | |||||
| Front wheel track [mm] | 1621 | |||||
| Rear wheel track [mm] | 1604 | |||||
| Forward overhang [mm] | - | |||||
| Rear overhang [mm] | - | |||||
| Clearance [mm] | - | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | 958 | |||||
| Headroom rear [mm] | - | |||||
| Front elbow/shoulder width [mm] | 1409/1472 | |||||
| Rear elbow/shoulder width [mm] | - | |||||
| Legroom front knees/total [mm] | - | |||||
| Legroom rear knees/total [mm] | - |
Gallery
