Mercedes-Benz M

Date of manufacture

7/2011 – 2015 (SUV)

Platform

Manufacturing locations

Tuscaloosa, Alabama, USA

Pune, India

Samut Prakan, Thailand

Designer

Emiel Burki

Car body style

SUV

Date of manufacture

7/2011 – 2015

Internal designation

W166

Engine size

Petrol

ML 350 BlueEFFICIENCY 4MATIC

ML 400 4MATIC

ML 500 4MATIC

ML 63 AMG 4MATIC

ML 63 AMG 4MATIC Performance

Diesel

ML 250 BlueTEC 4MATIC

ML 350 BlueTEC 4MATIC

Euro NCAP

Technical data

SUV

	ML 350 BlueEFFICIENCY 4MATIC	ML 400 4MATIC	ML 500 4MATIC	ML 63 AMG 4MATIC	ML 63 AMG 4MATIC Performance	ML 250 BlueTEC 4MATIC
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	6/24	6/24	8/32	8/32	8/32	4/16
Engine displacement [cm³]	3498	2996	4663	5461	5461	2143
Maximum output / speed [kW/min-1]	225/6500	245/5250-6000	300/5000-5750	386/5250-5750	410/5250-5750	150/3800
Maximum torque [Nm/min-1]	370/3500-5250	480/1600-4000	600/1600-4750	700/1750-5000	760/2000-5000	500/1600-1800
Bore and stroke [mm x mm]	92,9 x 86,0	88,0 x 82,1	92,6 x 86,0	98,0 x 90,5	98,0 x 90,5	83,9 x 99,0
Compression ratio	12,0:1	10,5:1	10,5:1	10,0:1	10,0:1	16,2:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection variable timing of intake and exhaust valves start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection Common Rail supercharging by twin turbochargers particulate filter start&stop system SCR catalytic converter with AdBlue additive injection

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	7 gear automatic	7 gear automatic	7 gear automatic	7 gear automatic	7 gear automatic	7 gear automatic
Drive specifications	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox AMG SPEEDSHIFT 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox AMG SPEEDSHIFT 7G‐TRONIC PLUS	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS

Top speed [km/h]	235	247	250	250	250	210
Acceleration 0–100 km/h [s]	7.6	6.1	5.6	4.8	4.7	9.0
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	10.9-11.3	11.2-11.5	14.7-15.2	15.7	15.7	6.7-7.1
Out of town [l]	7.1-7.4	7.6-7.8	8.9-9.5	9.6	9.6	5.3-5.7
Combined [l]	8.5-8.8	8.8-9.2	11.0-11.5	11.8	11.8	5.8-6.2
CO2 emissions [g/km]	199-206	209-215	258-269	276	276	154-163

Emission standard	EU5	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	2130	2130	2235	2345	2345	2150
Overall weight [kg]	2900	2900	2950	3050	3050	2950
Maximum trailer weight unbraked/braked [kg]	750/3500	750/3500	750/3500	750/3500	750/3500	750/2950
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	690	690	690	690	690	690
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2010	-/2010	-/2010	-/2010	-/2010	-/2010
Boot length [mm]	1046	1046	1046	1046	1046	1046
Boot length with rear seats folded [mm]	1833	1833	1833	1833	1833	1833
Boot width between wheels/max [mm]	-/1034	-/1034	-/1034	-/1034	-/1034	-/1034
Boot height to headliner/ceiling [mm]	-/902	-/902	-/902	-/902	-/902	-/902
Loading edge height [mm]	761	761	761	761	761	761
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	839	839	839	839	839	839
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	78	93	93	93	93	93
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.35	0.35	0.36	0.38	0.38	0.34
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	255/55 R18	255/55 R18	255/50 R19	265/45 R20	265/45 R20	235/65 R17
Tyre dimensions rear	255/55 R18	255/55 R18	255/50 R19	265/45 R20	265/45 R20	235/65 R17
Wheel size front	8.0J x 18 ET56	8.0J x 18 ET56	8.0J x 19 ET56	9.0J x 20 ET41	9.0J x 20 ET41	7.5J x 17 ET53
Wheel size rear	8.0J x 18 ET56	8.0J x 18 ET56	8.0J x 19 ET56	9.0J x 20 ET41	9.0J x 20 ET41	7.5J x 17 ET53
Brake dimensions front	-	-	-	390 x 36	390 x 36	-
Brake dimensions rear	-	-	-	345 x 26	345 x 26	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.8/-	11.8/-	11.8/-	11.8/-	11.8/-	11.8/-

Overall length [mm]	4804	4804	4804	4817	4817	4804
Overall width without/including mirrors [mm]	1926/2141	1926/2141	1926/2141	1940/2141	1940/2141	1926/2141
Overall height [mm]	1796	1796	1796	1796	1796	1796
Wheelbase [mm]	2915	2915	2915	2915	2915	2915
Front wheel track [mm]	1642	1642	1642	1685	1685	1653
Rear wheel track [mm]	1657	1657	1657	1664	1664	1667
Forward overhang [mm]	880	880	880	880	880	880
Rear overhang [mm]	1009	1009	1009	1009	1009	1009
Clearance [mm]	202	202	255	255	255	191
Wading depth [mm]	500	500	500	500	500	500
Approach angle front [°]	26	26	30	30	30	26
Approach angle rear [°]	25	25	28	28	28	25
Transition angle [°]	17	17	20	20	20	17
Climbing rate [°]	80	80	80	80	80	80
Maximum side tilt [°]	35	35	35	35	35	35

Headroom front [mm]	1059	1059	1059	1059	1059	1059
Headroom rear [mm]	992	992	992	992	992	992
Front elbow/shoulder width [mm]	1485/1540	1485/1540	1485/1540	1485/1540	1485/1540	1485/1540
Rear elbow/shoulder width [mm]	1482/1525	1482/1525	1482/1525	1482/1525	1482/1525	1482/1525
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	ML 350 BlueTEC 4MATIC
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	6/24
Engine displacement [cm³]	2987
Maximum output / speed [kW/min-1]	190/3600
Maximum torque [Nm/min-1]	620/1600-2400
Bore and stroke [mm x mm]	83,0 x 92,0
Compression ratio	15,5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbo-supercharged particulate filter start&stop system SCR catalytic converter with AdBlue additive injection

Drive axle	4x4
Gearbox	7 gear automatic
Drive specifications	permanent all-wheel drive 4MATIC automatic gearbox 7G‐TRONIC PLUS

Top speed [km/h]	224
Acceleration 0–100 km/h [s]	7.4
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	7.8-8.1
Out of town [l]	6.3-6.7
Combined [l]	6.8-7.2
CO2 emissions [g/km]	179-189

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	2175
Overall weight [kg]	2950
Maximum trailer weight unbraked/braked [kg]	750/3500
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	100/-

Boot volume [l]	690
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2010
Boot length [mm]	1046
Boot length with rear seats folded [mm]	1833
Boot width between wheels/max [mm]	-/1034
Boot height to headliner/ceiling [mm]	-/902
Loading edge height [mm]	761
Height of the open boot door [mm]	-
Boot opening height [mm]	839
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	93
AdBlue tank volume [l]	-
Air resistance [Cd]	0.35
Front suspension	double wishbone
Rear suspension	multilink
Tyre dimensions front	235/65 R17
Tyre dimensions rear	235/65 R17
Wheel size front	7.5J x 17 ET53
Wheel size rear	7.5J x 17 ET53
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	11.8/-

Overall length [mm]	4804
Overall width without/including mirrors [mm]	1926/2141
Overall height [mm]	1796
Wheelbase [mm]	2915
Front wheel track [mm]	1653
Rear wheel track [mm]	1667
Forward overhang [mm]	880
Rear overhang [mm]	1009
Clearance [mm]	202
Wading depth [mm]	500
Approach angle front [°]	26
Approach angle rear [°]	25
Transition angle [°]	17
Climbing rate [°]	80
Maximum side tilt [°]	35

Headroom front [mm]	1059
Headroom rear [mm]	992
Front elbow/shoulder width [mm]	1485/1540
Rear elbow/shoulder width [mm]	1482/1525
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Mercedes-Benz ML W166 2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
