Mercedes-Benz GLS

Date of manufacture

11/2015 – 4/2019 (SUV)

Platform

Manufacturing locations

Tuscaloosa, Alabama, USA

Pune, India

Samut Prakan, Thailand

Designer

Car body style

SUV

after upgrade (facelift)

Date of manufacture

11/2015 – 4/2019

Internal designation

X166

Engine size

Petrol

Diesel

Technical data

SUV

	GLS 400 4MATIC	GLS 500 4MATIC	GLS 63 AMG 4MATIC	GLS 350 d 4MATIC
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/32	8/32	6/24
Engine displacement [cm³]	2996	4663	5461	2987
Maximum output / speed [kW/min-1]	245/5250-6000	335/5250-5500	430/5500	190/3600
Maximum torque [Nm/min-1]	480/1600-4000	700/1800-4000	760/1750-5250	620/1600-2400
Bore and stroke [mm x mm]	88,0 x 82,1	92,6 x 86,0	98,0 x 90,5	83,0 x 92,0
Compression ratio	10,5:1	10,5:1	10,0:1	15,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection variable timing of intake and exhaust valves supercharging by twin turbochargers start&stop system	direct injection Common Rail turbo-supercharged particulate filter start&stop system SCR catalytic converter with AdBlue additive injection

Drive axle	4x4	4x4	4x4	4x4
Gearbox	9 gear automatic	9 gear automatic	7 gear automatic	9 gear automatic
Drive specifications	permanent all-wheel drive 4MATIC automatic gearbox 9G‐TRONIC	permanent all-wheel drive 4MATIC automatic gearbox 9G‐TRONIC	permanent all-wheel drive 4MATIC automatic gearbox AMG SPEEDSHIFT PLUS 7G‐TRONIC	permanent all-wheel drive 4MATIC automatic gearbox 9G‐TRONIC

Top speed [km/h]	240	250	250	222
Acceleration 0–100 km/h [s]	6.6	5.3	4.6	7.8
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	11.1-11.7	14.6-14.9	15.8	7.6-8.2
Out of town [l]	7.5-8.0	8.8-9.2	10.3	6.7-7.2
Combined [l]	8.9-9.4	10.9-11.3	12.3	7.1-7.6
CO2 emissions [g/km]	206-218	255-264	288	185-199

Emission standard	EU6	EU5-EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	2435	2445	2580	2455
Overall weight [kg]	3250	3250	3290	3250
Maximum trailer weight unbraked/braked [kg]	750/3500	750/3500	750/3500	750/3500
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-

Boot volume [l]	680	680	680	680
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2300	-/2300	-/2300	-/2300
Boot volume, third row of seats [l]	-	-	-	-
Boot volume, third row seats folded [l]	-	-	-	-
Boot length [mm]	500	500	500	500
Boot length with rear seats folded [mm]	2124	2124	2124	2124
Boot width between wheels/max [mm]	-/1027	-/1027	-/1027	-/1027
Boot height to headliner/ceiling [mm]	-/891	-/891	-/891	-/891
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	7	7	7	7
Fuel tank volume [l]	100	100	100	100
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.36	0.37	0.37	0.36
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	265/60 R18	275/55 R19	295/40 ZR21	265/60 R18
Tyre dimensions rear	265/60 R18	275/55 R19	295/40 ZR21	265/60 R18
Wheel size front	8.0J x 18 ET56.5	8.5J x 19 ET62	10.0J x 21 ET46	8.0J x 18 ET56.5
Wheel size rear	8.0J x 18 ET56.5	8.5J x 19 ET62	10.0J x 21 ET46	8.0J x 18 ET56.5
Brake dimensions front	-	-	390 x 36	-
Brake dimensions rear	-	-	345 x 26	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	12.4/-	12.4/-	12.4/-	12.4/-

Overall length [mm]	5130	5130	5162	5130
Overall width without/including mirrors [mm]	1934/-	1934/-	1982/-	1934/-
Overall height [mm]	1850	1850	1850	1850
Wheelbase [mm]	3075	3075	3075	3075
Front wheel track [mm]	1655	1645	1676	1655
Rear wheel track [mm]	1675	1665	1696	1675
Forward overhang [mm]	890	890	-	890
Rear overhang [mm]	1165	1165	-	1165
Clearance [mm]	276	276	-	276
Wading depth [mm]	500	500	-	500
Approach angle front [°]	30	30	-	30
Approach angle rear [°]	25	25	-	25
Transition angle [°]	20	20	-	20
Climbing rate [°]	80	80	-	80
Maximum side tilt [°]	35	35	-	35

Headroom front [mm]	1046	1046	1046	1046
Headroom rear [mm]	1015	1015	1015	1015
Front elbow/shoulder width [mm]	1485/1540	1485/1540	1485/1540	1485/1540
Rear elbow/shoulder width [mm]	1482/1529	1482/1529	1482/1529	1482/1529
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-
Third row of seats, headroom [mm]	988	988	988	988
Third row elbow/shoulder width [mm]	1282/1295	1282/1295	1282/1295	1282/1295

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
